  • Page 1 Orion ™ Users Guide Version 20230418 • Part #1441 Permanent Jewelry Training Video Watch this video for permanent jewelry training, setup recommendations, time-saving tips and tricks, and more!
  • Page 2 ING LLC PRODUCT OR ANY THIRD PARTY PRODUCTS THAT ARE USED IN OR WITH THE SUNSTONE ENGINEERING LLC PRODUCT, OR LOSS OF USE OF THE SUNSTONE ENGINEERING LLC PRODUCT OR ANY THIRD PARTY PRODUCTS THAT ARE USED IN OR WITH THE SUNSTONE ENGINEERING LLC PRODUCT, EVEN IF SUNSTONE ENGINEERING LLC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
  • Page 3: Table Of Contents

    e Micro Welder Experts Contents Welder Setup & Assembly ....................... 1 How to Connect All Cables ....................1 Microscope Arm Mounting Options ................2 How to Adjust Microscope Focus .................. 5 How to Place the Welding Stylus ................... 5 Electrode Setup ........................6 Electrode Care ........................
  • Page 4 Orion PJ with basic ADL. Orion PJ with upgraded ADL. Orion PJ with Optics Permanent Jewelry Training Video Watch this video for permanent jewelry training, setup recommendations, time-saving tips and tricks, and more! Pulse Arc Welding Workbook and Safety Guide Download this document to access advanced welding techniques and safety information.
  • Page 5: Welder Setup & Assembly

    Plug the female end of the power cable into the AC Power port (A) on the back of the power supply. Then connect the male end into an AC power supply. The Orion PJ has an internal switching power supply that can accept both 120 and 240VAC.
  • Page 6: Microscope Arm Mounting Options

    Turn clockwise for a lighter shade and count- er-clockwise for darker shade. Microscope Arm Mounting Options If you purchased the Orion PJ with a microscope, care- fully follow these instructions. Mounting Option 1 - Clamp to Table Figure 2.2. Upgraded Auto Darkening Lens (Left) and Regular Auto Darkening Lens (Right).
  • Page 7 e Micro Welder Experts hex screws. See Figure 2.4. For thicker tables, attach the clamp mechanism (D) to the two lower holes in the Angled Bracket (C). • Adjust the knob on the Clamp Mechanism (D) until the gap is sufficient for the thickness of your tabletop.
  • Page 8 Orion PJ User Manual ™ Turn the Adjustment knob (J) clockwise to tighten the plate to the underside of the table. See Figure 4.1. Mounting Option 3 - Screw to Table (vertical surface) Required hardware from Box 2: Figure 4.1. Turn the Adjustment knob (J) clockwise to tighten the plate to the table.
  • Page 9: How To Adjust Microscope Focus

    RJ45 Shutter Cable to connect the welder to the back and How to Adjust Microscope Focus bottom of the microscope head. The other end of the cable connects to the (F) port in the back of the Orion PJ. (See • Twist the knob on the microscope forward and Figure 2.1)
  • Page 10: Electrode Setup

    Now securely tighten the Welding Stylus in place by tightening the thumb screw on the bottom of the stylus holder. • Connect the Stylus Cord to the back of the Orion PJ to the stylus port as seen in Figure 2.1. Electrode Setup Stylus Components Figure 6.1...
  • Page 11: Electrode Care

    e Micro Welder Experts Stylus Hull (E) against the Collet Cap (C), then make sure the Electrode (D) extends as indi- cated. See Figure 6.3. • There should be between 0.6 - 0.7 inch (1.5 – 2cm) of the Electrode (D) protruding from the Stylus Shaft (A).
  • Page 12 Figure 8.2. Use a rotary tool to sharpen the electrode. Note: As a rule of thumb, Sunstone recommends a sharpened electrode anytime a new workpiece is being welded.
  • Page 13: Shield Gas Setup

    • Right-sized tank fits almost anywhere! 658-0015 or scan the QR code • Premium argon gas for your Orion PJ! above. Always secure the pressurized gas tank to a fixed location (such as a sturdy table leg). If the pressurized...
  • Page 14: Microscope Tips

    SHIELDING GAS TANK AND REGULATOR SETUP The following instructions are specific for a Sunstone argon regulator. Other regulators may operate differently. Consult instructions that may have come with other regulators.
  • Page 15: Microscope Lcd Filter Shutter System

    The Microscope LCD Filter Shutter System provides an unobstructed working view before welding and com- pletely protects your eyes during the welding process. The Orion PJ’s internal computer verifies the Microscope LCD Filter Shutter System has been closed before allowing the weld to take place. Should the shutter not close, the microscope lens is equipped with >UV 16 and >IR 16 for maximum eye protection.
  • Page 16: How To Use The Touchscreen Interface

    The Orion PJ touch screen interface is very user friendly. Users have access to every welding parameter with one touch. Below is an explanation of the various buttons and options found on the Orion PJ interface. *Orion touch screens are resistive touch screens. This means they respond best to a little bit of pressure. The end of your fingernail or the tip of the alligator clip works best when touching the screen.
  • Page 17 Weld On/Off Button When the Orion PJ is initially powered on, the Weld On/Off Button (F) will be in the off mode (the power symbol is gray). The welder will not operate while in the off mode. To operate the welder, tap once on the Weld On/Off Button to switch to the on mode (the power symbol turns orange).
  • Page 18: How To Make A Weld

    How to Make a Weld If you’ve never used the Orion PJ or other Orion pulse arc welder, you should practice first on the provided weld- ing plate. After careful setup and familiarization of how the welder operates, follow these instructions using the welding plate.
  • Page 19: Permanent Jewelry Instructions

    Micro Welder Experts Note: Sloped, Sustained, and Negative Rows are not applicable to the Orion PJ, so ignore the labels and focus on the row labeled “None”. Create lower-powered practice welds on the left and higher powered welds as you move right (maximizing at 15J).
  • Page 20: Recommended Welder Settings & Welder Specifications

    Orion PJ User Manual ™ Weld Settings for Chain Below are energy settings for Sunstone’s chains. Ella Aria • Rose Gold Filled (5J) • Yellow Gold Filled (3J) • Yellow Gold Filled (5J) • Sterling Silver (3J) • Sterling Silver (5J)
  • Page 21 e Micro Welder Experts Product Specifications WELD MODES PEAK POWER (J) 15 J ENERGY (J) 1-15 J ENERGY SETTINGS WELDS/SECOND WELD SPOT DIAMETER 0.5 - 1.0mm DISPLAY 11cm Touchscreen (272 x 480 pixels) LCD INPUT POWER 100/230 VAC (Auto Detect) FOOTPRINT (LXWXH) 15.24 x 10.16 x 15.24cm WEIGHT...
  • Page 22 3-30 Joules 1-15 Joules 0.75-1.5 mm Spot Size 0.5-1.0 mm Spot Size 1 weld every 2 seconds 1 weld per second ©2023 Sunstone Engineering LLC. Sunstone and Orion are trademarks of Sunstone Engineering LLC. All rights reserved.
  • Page 23 e Micro Welder Experts Pulse Arc Welders Orion 100c Orion 100s Orion 200i When you need a bit more The world’s bestselling pulse arc For large shops who value power, a bit more energy welder! Most of the features and production efficiencies—or control, try the 100c! power you’ll need.
  • Page 24 1693 American Way Ste 5 • Payson UT 84651 USA Tel. +1-801-658-0015 wwww.sunstonewelders.com PART #1441 ©2023 Sunstone Engineering LLC. Safety information subject to change. Sunstone and Orion are trademarks of Sunstone Engineering LLC. 20230418•...
