MX Series
RRFB BACKPLATE KIT INSTALL GUIDE
LEVEL 4
Black Powder Coat
Black Powder Coat with
Retroreflective Tape
1. Remove four light bar cover screws and set aside. Slide cover off as shown.
90711REVA
Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 |
customersupport@carmanah.com
|
carmanah.com
Advertisement
Table of Contents
Related Manuals for Carmanah MX Series
Summary of Contents for Carmanah MX Series
- Page 1 Black Powder Coat Black Powder Coat with Retroreflective Tape 1. Remove four light bar cover screws and set aside. Slide cover off as shown. 90711REVA Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
- Page 2 4. Pull backplate forward over light bar cover. Align holes in backplate, light bar cover and captive nuts on chassis underneath. Install all four screws loosely before tightening. NOTE: READ ALL INCLUDED INSTALL GUIDES BEFORE SYSTEM INSTALLATION Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
