Carmanah R247 Owner's Manual

Solar led roadway light / 24-hour hazard flasher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
Solar LED Roadway Light /
24-Hour Hazard Flasher - Model R247
"The world's most advanced 24-hour solar LED hazard flasher"
No external wiring or bulb replacement.
No maintenance for five years!
© November 7, 2006, Carmanah Technologies Corp.
www.carmanah.com
Technical Support:
customerservice@carmanah.com
Toll Free in North America: 1 (877) 722-8877
International: + (250) 380-0052 | Fax: + (250) 389-0040
R247 - 37224

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R247 and is the answer not in the manual?

Questions and answers

Related Manuals for Carmanah R247

Summary of Contents for Carmanah R247

  • Page 1 OWNER’S MANUAL Solar LED Roadway Light / 24-Hour Hazard Flasher - Model R247 “The world’s most advanced 24-hour solar LED hazard flasher” No external wiring or bulb replacement. No maintenance for five years! © November 7, 2006, Carmanah Technologies Corp.

  • Page 3: Table Of Contents

    MAINTENANCE AND PRODUCT CARE ............10 TROUBLESHOOTING ..................11 SERVICE AND ADDITIONAL PRODUCTS .............11 ..................11 USTOMER ERVICE ...................12 DDITIONAL RODUCTS SPECIFICATIONS ...................12 APPENDIX A: R247 COMPONENTS...............14 Carmanah Technologies Corp. Copyright © 2006 Document number: MAN_ROAD R247 Owner's Manual 37224_vE Last revised: November 7, 2006...

  • Page 4: Introduction

    Installation time can be budgeted at approximately ten minutes in the shop plus one hour in the field per R247 system. This time budget is assuming that a pole is already in place in the field to mount the unit on. No trenching, external cabling, traffic disruption or site remediation is required.

  • Page 5: Attaching The Mounting Post

    2. Place the flange of the top arm pipe into the mounting bracket and ensure that the cabling is not pinched – make sure it does not obscure the mounting hole. See Figure Carmanah Technologies Corp. Copyright © 2006 Document number: MAN_ROAD R247 Owner's Manual 37224_vE Last revised: November 7, 2006...

  • Page 6: Install And Connect The Batteries

    3. Fasten the top arm pipe to the mounting bracket using the hardware described in Drawing R247-A01_02 found at the end of these instructions. 4. Remove the large locking nut on the top arm and pass the LED harness into the top hole of the LED array.

  • Page 7: Final Adjustments

    Final Adjustments As the Carmanah Model R247 is a solar-powered device, it is critical to position the unit in relation to the optimum angle of the sun in order to achieve maximum solar power generation. Note: To do this, angle the top of the main housing unit towards the equator (south if installed in the northern hemisphere, and north if installed in the southern hemisphere) and tip it upwards at an angle equal to your latitude plus 5 degrees.

  • Page 8: Configuration / Operating Instructions

    Unplug the battery cable from the circuit board to turn the unit off. 3.1.2 Configuration Options The R247 offers four (4) customer-configurable options using a set of switches located on the circuit board: Daytime Brightness Levels: 124, 250 or 400 candela for MUTCD setting.

  • Page 9: Switch Function And Options

    The R247 has several user-configurable options that are accessed by DIP switches mounted on the circuit board. These options are read by the R247 only on power-up, so the power must be disconnected and reconnected after any change is made.

  • Page 10: Maintenance And Product Care

    Note: Pressure washers should not be used (water forced up into the louvers may soak internal components). Following the check list below will assist in ensuring that the R247 is will perform optimally 1. Clean the solar panels more frequently during drier months, as they may become soiled more quickly.

  • Page 11: Troubleshooting

    5.0 Troubleshooting The Light is not Flashing There are two faults that may occur with the R247 that will prevent the light from flashing: 1. Check the battery connection and the LED array connection to ensure that the connectors are fully inserted. As the light is designed to function as soon as the battery is plugged in, this should be fairly simple to diagnose.

  • Page 12: Additional Products

    Additional Products Carmanah offers a variety of solar-powered and energy efficient LED lighting products. For roadway applications, Carmanah also manufactures solar LED pedestrian crosswalk flashing beacon and school zone flashers, as well as LED internally illuminated street-name signs and traffic signs.
  • Page 13 Storage Temperature ............20° C +/- 5° C (68° F +/- 5° F) Housing Head and Support Structure ..........Powder coated aluminum Signal Housing ..............Injection molded UV stabilized polycarbonate Patents Trademark and Patents.............Patents Pending Carmanah Technologies Corp. Copyright © 2006 Document number: MAN_ROAD R247 Owner's Manual 37224_vE Last revised: November 7, 2006...

  • Page 14: Appendix A: R247 Components

    Owner’s Manual | Model R247 8.0 Appendix A: R247 Components Carmanah Technologies Corp. Copyright © 2006 Document number: MAN_ROAD R247 Owner's Manual 37224_vE Last revised: November 7, 2006...
  • Page 15 Owner’s Manual | Model R247 9.0 Appendix B: R247 Round Pole Mounting Option Carmanah Technologies Corp. Copyright © 2006 Document number: MAN_ROAD R247 Owner's Manual 37224_vE Last revised: November 7, 2006...
