Evaluation Board User Guide
Table 9. Daughter Board
Qty Reference Designator
1 U1
3 A1, A2, A3
2 C2, C4
2 C1, C3
1 J1
1 J2
2 J3, J4
1 FEC refers to Farnell Electronic Component Distributors.
Description
256-position digital potentiometer
3-pin SIL header and shorting link
6.3 V tantalum capacitor (Case A), 10 µF, ±20%
50 V, X7R ceramic capacitor, 0.1 µF, ±10%
Header, 2.54 mm, PCB, 1 × 8-way
12-pin (2 × 6), 0.1" pitch header
5-pin SIL header
Rev. 0 | Page 19 of 20
UG-472
Supplier 1 /Part Number
AD5142ABCPZ10
FEC 1022248 and 150410
FEC 1190107
FEC 1759122
FEC 1766172
FEC 1804099
FEC 1929016
