- Page 1 EXTREME SERIES OWNER’S MANUAL Extreme 3500 ti Extreme 5000 ti Extreme 8000 ti The Coolest Thing In Wine Storage...
- Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ............2 Before You Start . -
Page 4: Introduction
Customer Service Thank you for purchasing a WhisperKOOL Extreme Series cooling unit. We strive to provide the highest-quality products and the best possible customer service. If you have any questions about your WhisperKOOL unit, please call us at 1-800-343-9463 or visit www.whisperkool.com. -
Page 5: Before You Start
2. The unit should remain in an upright position for 24 hours prior to operation. 3. The WhisperKOOL unit requires a dedicated 115V, 20-amp circuit. Use a surge protector with the WhisperKOOL unit. Do not use a GFI (ground fault interrupter) line. -
Page 6: Receiving & Inspecting The Unit
WhisperKOOL Customer Service immediately. Please leave the WhisperKOOL unit in its original box until you are ready for installation. This will allow you to move the product safely without damaging it. When you are ready to remove the product from the box, refer to the installation instructions. - Page 7 Digital controller Bottle probe input Control panel (see page 12 for details) Fan speed control Bottle probe Rear / Side View Evaporator grille w/ filter UV power outlet UV/Access panel Rear power inlet Drain port www.whisperkool.com | Page 5...
-
Page 8: Quick Reference Guide
QUICK REFERENCE GUIDE- 8000 ti Front / Side View Evaporator grille w/ filter Digital controller Bottle probe input Compressor access panel Control panel (see page 12 for details) Bottle probe Fan speed control Rear / Side View Evaporator grille w/ filter Drain line access Rear power inlet... -
Page 9: Controller Layout
• Push to see the min. stored temperature. • Use as “select” button. • Use button to scroll down. Alarm Pre-Chill Display • Hold for three seconds when the min. or max. temperature is displayed to RESET. Control ON/OFF Button www.whisperkool.com | Page 7... - Page 10 FAN SPEED Fan speed selection is determined by the amount of heat that needs to be removed from the cellar and the type of installation (through-the-wall or fully ducted). Fan speed selection is based on the cellar size, insulation factor, door seal, and desired wine temperature.
-
Page 11: Preparing The Wine Cellar
Insulation Insulation is REQUIRED in order to properly use WhisperKOOL products. It is vital that all walls and ceilings be insulated to keep the cellar temperature as consistent as possible during the summer and winter months. Standard fiberglass or rigid foam insulation is normally used in cellar construction;... - Page 12 NOTE: Do not attempt to mount the unit in a wall recess or attempt to camouflage or cover the unit with any sort of aftermarket grille, accessory, etc. This can restrict airflow, prevent the unit from working properly, and void the warranty. Please feel free to call WhisperKOOL Customer Service with any questions or concerns regarding installation requirements. Door and Door Seal An exterior-grade (13/4”) door must be installed as a cellar door.
- Page 13 In some cases, it may be advisable to install a vent fan to dissipate heat from within the exhaust area. However, you must have a fresh air inlet as well. If your unit requires ducting, please contact WhisperKOOL to obtain a specially designed ducting plenum for the unit.
-
Page 14: Preparing The Unit For Installation
PREPARING THE UNIT FOR INSTALLATION The WhisperKOOL Unit requires a dedicated 115V, 20-amp circuit. The unit draws a large amount of amps during its initial startup. By designating a dedicated circuit breaker, you will guarantee the unit has enough power to run effectively. Contact an electrician for assistance with the installation of this dedicated electrical circuit. -
Page 15: Preparing The Installation Location
Make sure that the internal height remains at 16 inches (3500ti & 5000ti) or 22.75 inches (8000 ti) so that the WhisperKOOL unit will fit snugly through the framed cut-out. www.whisperkool.com | Page 13... - Page 16 OPTIONAL EXTERIOR GRILLE- 3500/5000 ti The exterior grille is required on all installations where the exhaust side of the unit is exposed to the outdoors (i.e., rain and other adverse weather conditions). Non-Flush Installation Install the unit according to the standard through-the-wall procedure. After the unit is installed, place the exterior grille over the exhaust side filter grille and align the screw holes on the sides of the unit.
-
Page 17: Optional Exterior Grille
4. Use the supplied 1/2" pan-head screws to fasten the grille and bracket to the unit ensuring the bracket stays perpendicular/ square. 5. Continue through-the-wall installation. You are required to use the 1/2” hex-head screws provided. Do not drill holes into unit. Non-Flush Installation Flush Installation www.whisperkool.com | Page 15... - Page 18 PREPARING THE UNIT FOR INSTALLATION 3500/5000 ti A two-piece mounting bracket is used to secure the unit to the wall studs. Two optional filler brackets can also be installed to frame around the top and bottom of the unit. The mounting holes on the unit have been designed to hold the unit at a two-degree (2°) angle.
- Page 19 5” inch thick wall (wall thickness may vary) Mounting Bracket Wine Cellar Exhaust Area #1 7.5–9.5” In Cellar #2 11.5–13.5” In Cellar #3 15.5–17.5” In Cellar #4 19.5–21.5” In Cellar www.whisperkool.com | Page 17...
- Page 20 The 13/4" screws should penetrate the studs as well as the upper and lower supports to provide adequate support for the WhisperKOOL unit (see illustration). Seal all cracks and gaps around the WhisperKOOL Extreme unit with an air- tight sealant or caulking to prevent air leakage.
-
Page 21: Installing The Unit
The 13/4" screws should penetrate the studs as well as the upper and lower supports to provide adequate support for the WhisperKOOL unit (see illustration). Seal all cracks and gaps around the WhisperKOOL Extreme unit with an air- tight sealant or caulking to prevent air leakage. - Page 22 Button/Symbol Normal Functions Press the SET button once and it will display the setpoint. After approximately 5 seconds, the SET BUTTON display will return to normal operation and display the bottle probe temperature. Press and hold the SET button for 3–5 seconds until the setpoint is displayed and the °F symbol blinks.
-
Page 23: Condensation Drain Line
Then use the supplied drain line brush to clean the interior drain line. Use the drain line access door to drop a pan tab into the drip tray to prevent the buildup of microbial growth. WRONG: Drain line is under water. www.whisperkool.com | Page 21... -
Page 24: Liquid Measuring Thermostat System (Bottle Probe)
LIQUID-MEASURING THERMOSTAT SYSTEM (BOTTLE PROBE) WhisperKOOL cooling units come with a liquid-temperature-measuring thermostat. The self-calibrating bottle probe contains a sensor which communicates back and forth with the thermostat. This results in a consistent temperature setting and accuracy. Wine should be kept at a very precise, controlled temperature and humidity. By measuring the liquid temperature rather than air, the unit will operate 75–80% of the time. -
Page 25: Multi-Speed Fan Control
* To give you a feeling for decibels, a food blender at 3 ft. is 90 dBA, a garbage disposal at 3 ft. is 85 dBA, a vacuum cleaner at 10 ft. is 75 dBA, normal speech at 3 ft. is 79 dBA, a dishwasher in the next room is 55 dBA, and a quiet night is 35 dBA. www.whisperkool.com | Page 23... - Page 26 Anti-Short Cycle delay. Setpoint The setpoint is set at the factory (WhisperKOOL) to 55°F. It can In the event of a faulty bottle probe, the compressor will be adjusted by the customer between 50–67°F in one-degree cycle off for 10 minutes and on for 40 minutes.
-
Page 27: Controller Functions
At the beginning of the cycle the symbol will display and the symbol will flash. When the cycle begins properly, the symbol will be steadily illuminated. www.whisperkool.com | Page 25... -
Page 28: Extreme 3500Ti, 5000Ti, & 8000Ti Wiring Diagram
EXTREME 3500ti, 5000ti, & 8000ti WIRING DIAGRAM white line 16 5)A comp supply 120V neutral defrost D.I. Evap. Room black EXti 022123 Page 26... -
Page 29: Troubleshooting Guide
If so, call Customer Service at 1-800-343-9463. System runs constantly Possible cause Solution Leaky door seal or poorly insulated cellar Fix leaky door seal and insulate cellar in accordance with this manual (page 9) www.whisperkool.com | Page 27... - Page 30 Unit leaks water Possible cause Solution Unit is level °) System should have a two-degree (2 pitch towards the exhaust side Drain line clogged or kinked Check drain line to make sure water can flow freely Drain is clogged, preventing water from escaping 1.
-
Page 31: Maintenance Schedule
They are harmful or fatal if ingested. Wear protective gloves when handling pan tabs. Wash hands thoroughly after handling. If pan tabs make contact with eyes, rinse cautiously with water for several minutes. In case of an emergency, call 1-800-255-3924 (24 hours). www.whisperkool.com | Page 29... - Page 32 TECHNICAL ASSISTANCE WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. Pacific Standard Time. The appointed customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: The model and serial number of your WhisperKOOL system(s).
- Page 33 A. Two (2) Year Limited Warranty: For the period of TWO (2) YEARS (the “Limited Warranty Period”) from the date of original sale of a Product by WhisperKOOL, if a WhisperKOOL Product is found to be defective in material or workmanship after undergoing WhisperKOOL’s Customer Service troubleshooting, then, subject to the WhisperKOOL Product Limited...
- Page 34 16. No one has any authority to add to or vary the limited warranty on this Product. 3. Product Installation Requirements: A. Prior to installing a WhisperKOOL Product, the End User must read the WhisperKOOL Owner’s Manual and thereafter the End User must follow the required installation, use and maintenance procedures set forth by WhisperKOOL in WhisperKOOL’s Owner’s Manual.
- Page 35 Product Limited Warranty And Product Installation Requirements), and further these Terms and Conditions of Sale shall be interpreted as though drafted jointly by WhisperKOOL and Purchaser. Any dispute will be resolved by the courts in and for the County of San Joaquin, State of California, and all parties, WhisperKOOL, Purchaser and End User, hereby irrevocably submit to the personal jurisdiction of such courts for that purpose.
- Page 36 E-mail: support@whisperkool.com Web: www.whisperkool.com B. Technical Assistance: WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. (PST). The Customer Service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: 1.
- Page 37 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1-800-343-9463 www.whisperkool.com www.whisperkool.com | Page 35...
