WhisperKool EXTREME Series Owner's Manual

240v (metric)
Hide thumbs Also See for EXTREME Series:
Table of Contents

Advertisement

Quick Links

Download this manual
EXTREME SERIES
240V (METRIC)
OWNER'S MANUAL
Extreme tiR 3500
Extreme tiR 5000
Extreme tiR 8000
Extreme tiR FD 3500
Extreme tiR FD 5000
Extreme tiR FD 8000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXTREME Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WhisperKool EXTREME Series

Summary of Contents for WhisperKool EXTREME Series

  • Page 1 EXTREME SERIES 240V (METRIC) OWNER’S MANUAL Extreme tiR 3500 Extreme tiR 5000 Extreme tiR 8000 Extreme tiR FD 3500 Extreme tiR FD 5000 Extreme tiR FD 8000...
  • Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction ............2 Before You Start .

  • Page 4: Introduction

    How Does the WhisperKOOL Extreme Series Work? The WhisperKOOL unit is especially designed to maintain optimal conditions for wine storage and aging. The unit is fully self- contained and can be installed through most walls. The unit is also capable of a more flexible ducted application, which allows the unit to be placed in an indoor remote site, resulting in a quiet airflow.

  • Page 5: Before You Start

    WhisperKOOL’s authorization. This will void your warranty. If you encounter a problem with your WhisperKOOL system, please refer to the Troubleshooting Guide. If you have any further questions or concerns, or need assistance, please contact MacPhee’s Customer Service at info@ macphees.com.au. Please be sure all testing has been completed prior to contacting Customer Service.

  • Page 6: Receiving & Inspecting The Unit

    Customer Service immediately. Please leave the WhisperKOOL unit in its original box until you are ready for installation. This will allow you to move the product safely without damaging it. When you are ready to remove the product from the box, refer to the installation instructions.

  • Page 7: Quick Reference Guide

    Evaporator grille w/ filter Remote digital display Control panel (see page 11 for details) Bottle probe Fan speed control Rear / Side View Evaporator grille w/ filter UV power outlet UV/access panel Rear power inlet Drain port www.whisperkool.com | Page 5...
  • Page 8 Fully Ducted — Front / Side View Exhaust plenum Supply plenum Intake plenum Return plenum Rear Remote digital display °C Control panel (see page 11 for details) Drain port Bottle probe Fan speed control NOTE: Grilles and filters are not included with the fully ducted Extreme tiR. EXtiR 011824 Page 6...

  • Page 9: Fan Speed & Unit Specifications

    12.7 mm ID clear plastic tubing Installation Through-the-wall Thermostat Advanced digital controller, liquid-temperature-measuring bottle probe (retractable cable) Temp. Delta Can maintain a 13°C cellar temperature with up to 43°C condenser air intake temperature Warranty Two-year limited warranty (parts and labor) www.whisperkool.com | Page 7...
  • Page 10 FULLY-DUCTED EXTREME TIR 3500 tiR FD 5000 tiR FD 8000 tiR FD 22 cu. m when cellar is fully 35 cu. m when cellar is fully 56 cu. m when cellar is fully insulated Cellar Size* insulated and sealed with a insulated and sealed with a and sealed with a proper vapor proper vapor barrier...

  • Page 11: Preparing The Unit For Installation

    PREPARING THE UNIT FOR INSTALLATION The WhisperKOOL Unit requires a dedicated 240V, 15-amp circuit. The unit draws a large amount of amps during its initial startup. By designating a dedicated circuit breaker, you will guarantee the unit has enough power to run effectively. Contact an electrician for assistance with the installation of this dedicated electrical circuit.

  • Page 12: Preparing The Installation Location

    Make sure that the internal height remains at 406 mm (3500ti & 5000ti) or 578 mm (8000 ti) so that the WhisperKOOL unit will fit snugly through the framed cut-out. EXtiR 011824...
  • Page 13 127 mm inch thick wall (wall thickness may vary) Mounting Bracket Wine Cellar Exhaust Area #1 190–241mm In Cellar #2 292–342mm In Cellar #3 393–444mm In Cellar #4 495–546mm In Cellar www.whisperkool.com | Page 11...

  • Page 14: Optional Exterior Grille

    OPTIONAL EXTERIOR GRILLE The exterior grille is required on all installations where the exhaust side of the unit is exposed to the outdoors (i.e., rain and other adverse weather conditions). Non-Flush Installation Install the unit according to the standard through-the-wall procedure. After the unit is installed, place the exterior grille over the exhaust side filter grille and align the screw holes on the sides of the unit.

  • Page 15: Installing The Unit

    The 44 mm screws should penetrate the studs as well as the upper and lower supports to provide adequate support for the WhisperKOOL unit (see illustration). Seal all cracks and gaps around the WhisperKOOL Extreme unit with an air-tight sealant or caulking to prevent air leakage.

  • Page 16: Ducting Overview

    DUCTING OVERVIEW Use ductwork to connect the unit to the supply and return outlets in the wine cellar. Use only insulated ductwork to minimize cooling losses, prevent sweating, and reduce noise. Use ductwork on the condenser section to redirect or absorb sound, bring in outside air to the unit inlet, and/or exhaust the hot air.

  • Page 17: Ducting Configurations

    Half Duct Configuration Wine Cellar Cold Air Supply (Cellar Side) Adjacent Room Return Air (Cellar Side) Three-Quarter Duct Configuration Condenser Exhaust Wine Cellar Cold Air Supply (Cellar Side) Condenser Intake Adjacent Room Return Air (Cellar Side) www.whisperkool.com | Page 15...
  • Page 18 Fully Ducted Attic Mounted Unit It is recommended that you use a condensate pan for this application. Insulation Box Condenser Exhaust Cold Air Condenser Intake Return Air Fresh Air Intake EXtiR 011824 Page 16...

  • Page 19: Installing The Duct Plenums

    INSTALLING THE DUCT PLENUMS 1. Remove the filter grille from the unit by unscrewing the screws that hold it in place. 2. Move the ducting adapters into place. 3. Screw the ducting adapters into place using the supplied screws. www.whisperkool.com | Page 17...

  • Page 20: Condensation Drain Line

    CONDENSATION DRAIN LINE The condensation drain line tube is used to drain excess condensation from the unit to a proper discharge location. It is important that the drain line tube be properly connected in order to prevent leakage and other problems associated with excess condensation.

  • Page 21: Liquid Measuring Thermostat System (Bottle Probe)

    Extreme Series LIQUID-MEASURING THERMOSTAT SYSTEM (BOTTLE PROBE) WhisperKOOL cooling units come with a liquid-temperature-measuring thermostat. The self-calibrating bottle probe contains a sensor which communicates back and forth with the thermostat. This results in a consistent temperature setting and accuracy. Wine should be kept at a very precise, controlled temperature and humidity. By measuring the liquid temperature rather than air, the unit will operate 75–80% of the time.

  • Page 22: Multi-Speed Fan Control

    MULTI-SPEED FAN CONTROL Designed for wine cellars up to 35 and 56 cubic meters, the Extreme 3500ti, 5000ti, and 8000ti feature multi-speed fans. These fans have a high setting for maximum performance in high-temperature (+43°C) environments and a low setting for super-quiet operation.

  • Page 23: Remote Display: Installation And Configuration

    NOTE: Cut hole in the location shown for routing the display cable. * The display can be mounted on any wall (inside or outside the wine cellar), up to 15 m from the cooling unit. www.whisperkool.com | Page 21...
  • Page 24 WALL MOUNT BRACKET INSTALLATION, CONTINUED 2. Using a drill with a 5 mm bit, drill four holes in the plaster for the screws. Insert the four (4) provided plaster anchors into the plaster, then tap them in with a hammer until they are flush with the wall. 3.
  • Page 25 5. Place the display on the wall mount bracket as shown, attaching the back of the display panel to the magnets on the mounting bracket. Make sure that the alignment tab on the back of the display panel sits in the notch on the bottom of the bracket. www.whisperkool.com | Page 23...
  • Page 26 FLUSH MOUNT BRACKET INSTALLATION Flush Mount Bracket Installation Square the flush mount template on the wall using 2. Peel the backing off the template and stick it to the wall, a level. Then draw a 76 mm line along the bottom aligning the bottom edge with the line drawn in Step 1.
  • Page 27 5. Remove the backing from the double-sided tape on the flush mount bracket. 6. Align magnets with previously drilled holes. Make sure the cut-out portion of the bracket (circled below) is on the bottom. Press the bracket firmly against the wall. WALL HOLE CUTOUT www.whisperkool.com | Page 25...
  • Page 28 FLUSH MOUNT BRACKET INSTALLATION, CONTINUED Connect the end of the display cable to the JST connector on the display panel. DISPLAY BRACKET 8. Place the display on the flush mount bracket as shown, attaching the back of the display panel to the magnets on the mounting bracket.

  • Page 29: Extreme 3500Tir/Fd, 5000Tir/Fd, & 8000Tir/Fd Wiring Diagram

    1 2 3 4 5 1 2 3 4 5 CRANKCASE HEATER BLACK WHITE WHITE COMPRESSOR BROWN CAPACITOR FAN SPEED SWITCH GREY EVAP FAN WHITE YELLOW HIGH BLACK BLUE BROWN CAPACITOR GREY WHITE COND FAN YELLOW BLUE BLACK www.whisperkool.com | Page 27...
  • Page 30 EXTREME 8000tiR/tiR FD WIRING DIAGRAM ELIWELL RTN 400 KDT PLUS DISPLAY CPB Pb3 CPB Pb2 CPB Pb1 KEYB OUT1 OUT4 NEUTRAL OUT2 OUT3 LINE 10 11 12 13 14 LINE NO NC NC NO C NO C NO NEUTRAL WHITE Extreme (AUS) BLACK tiR/FD 8000 Wiring...

  • Page 31: System Operation

    Anti-Frost Cycle is running, “dEF” will be displayed on the screen. The compressor will remain off until the evaporator coil reaches 4°C, or for a maximum of one hour. The unit will then return to normal operation. www.whisperkool.com | Page 29...
  • Page 32 ° DISPLAY LAYOUT Alarm is present Compressor is on Fan is on Anti-Frost Cycle running °C Scroll Button Return to Previous Menu Change Setpoint View/Change Setpoint Scroll Button Enter User Menu Change Setpoint (hold for 3 sec) Unlock Button Power On/Off (hold for 1 sec) EXtiR 011824 Page 30...

  • Page 33: Controller Functions

    This button confirms changes made to parameters such as the setpoint and returns you to the previous menu. LIGHT The light function is not in use. However, this button can still be used to unlock the display. www.whisperkool.com | Page 31...
  • Page 34 ICON GLOSSARY Icon Meaning SNOWFLAKE Blinking: The unit is calling for cooling, but must wait five minutes before restarting the com- pressor. This five-minute delay serves as an Anti-Short Cycle for the compressor’s protection. Constant: The unit is in cooling mode and the condensing unit is running. DRIPPING SNOWFLAKE The unit is undergoing an Anti-Frost Cycle.
  • Page 35 Extreme Series WHISPERKOOL CONTROLLER ALARM CODES Code Cause Solution The following alarm codes will be displayed on the screen along with the alarm icon. Bottle probe is not connected Attach bottle probe to circular connector Faulty bottle probe connection Locate faulty bottle probe connection by inspecting all wiring connections between the bottle probe and the circuit board.
  • Page 36 USER MENU The User Menu is accessed by pressing and holding the SET button for 3 seconds. Use the UP and DOWN ARROW buttons to navigate to desired parameters. Press the SET button again to view these parameters. Press the UP and DOWN ARROW buttons to adjust a parameter.

  • Page 37: Troubleshooting Guide

    If so, call Customer Service. System runs constantly Possible cause Solution Leaky door seal or poorly insulated cellar Fix leaky door seal and insulate cellar in accordance with this manual (page 9) www.whisperkool.com | Page 35...
  • Page 38 Unit leaks water Possible cause Solution °) Unit is level System should have a two-degree (2 pitch towards the exhaust side Drain line clogged or kinked Check drain line to make sure water can flow freely Drain is clogged, preventing water from escaping 1.

  • Page 39: Maintenance Schedule

    They are harmful or fatal if ingested. Wear protective gloves when handling pan tabs. Wash hands thoroughly after handling. If pan tabs make contact with eyes, rinse cautiously with water for several minutes. www.whisperkool.com | Page 37...
  • Page 40 FILTER REPLACEMENT PROCEDURE (FOR DUCTED UNITS) NOTE: For 3500/5000/8000 models the filters will be located at the return register inside the wine cellar. Replace filters according to specific register type selected by customer. EXtiR 011824 Page 38...
  • Page 41 Extreme Series NOTES www.whisperkool.com | Page 39...
  • Page 42 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 www.whisperkool.com...
