SLIMLINE 2500 & 3300
OWNER'S MANUAL
The Coolest Thing In Wine Storage

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLIMLINE 3300 and is the answer not in the manual?

Questions and answers

Summary of Contents for WhisperKool SLIMLINE 3300

  • Page 1 SLIMLINE 2500 & 3300 OWNER’S MANUAL The Coolest Thing In Wine Storage...
  • Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.
  • Page 3: Table Of Contents

    Slimline 2500 Wiring Diagram ......16 Slimline 3300 Wiring Diagram ......17 Controller Functions .
  • Page 4: Introduction

    Temperature Setting The WhisperKOOL Slimline unit can be set at any temperature within the acceptable wine-aging range of 45°F to 67°F. It is designed to create up to a 30°F temperature differential between the wine cellar and the space to which it is exhausting.
  • Page 5: Before You Start

    2. The unit should remain in an upright position for 24 hours prior to operation. 3. The unit requires a dedicated 115V, 20-amp circuit. Use a surge protector with the WhisperKOOL unit. Do not use a GFI (ground fault interrupter) line.
  • Page 6: Receiving & Inspecting The Unit

    • Write any discrepancy or visual damage on the bill of lading before signing. • Place the box containing the WhisperKOOL unit on a tabletop to prepare it for testing prior to installing. • Sit unit upright for 24 hours.
  • Page 7: Quick Reference Guide

    Front / Side View (in cellar / evaporator) Bottle probe Evaporator Bottle probe grille Controller input Power cord Drain port Bottom View Rear / Side View (out of cellar / condenser) Bottle probe input Power cord Condenser grille www.whisperkool.com | Page 5...
  • Page 8: Unit

    • Turns the Cooling Unit the min or max temperature is displayed to RESET. “ON/OFF” UNIT SPECIFICATIONS Slimline 2500 Slimline 3300 Cellar Size (cu. ft.)* Dimensions 22”W x 10.25” H x 19” D 22”W x 10.25”H x 19”D Weight 50 lbs...
  • Page 9: Preparing The Wine Cellar

    Insulation Insulation is REQUIRED in order to properly use WhisperKOOL products. It is vital that all walls and ceilings be insulated to keep the cellar temperature as consistent as possible during the summer and winter months. Standard fiberglass or rigid foam insulation is normally used in cellar construction;...
  • Page 10 NOTE: Do not attempt to mount the unit in a wall recess or attempt to camouflage or cover the unit with any sort of aftermarket grille, accessory, etc. This can restrict airflow, prevent the unit from working properly, and void the warranty. Please feel free to call WhisperKOOL Customer Service with any questions or concerns regarding installation requirements. Door and Door Seal An exterior-grade (13/4”) door must be installed as a cellar door.
  • Page 11 The drain line will prevent overflow and leaking by allowing for the discharge of the additional condensate. WhisperKOOL carries a condensate pump kit, which allows the excess condensate to be pumped up to 20 feet away from the unit.
  • Page 12: Pre-Installation

    Testing the Unit Place the WhisperKOOL system on a tabletop to prepare it for installation and testing. Plug the unit into a live electrical outlet and turn it on. The unit may take up to 10 to 15 minutes before running cool. Once the operation has been tested, turn the unit off and unplug it from the electrical outlet.
  • Page 13: Preparing The Installation Location

    Note: The following installation examples are for reference only. Door header construction and framing may vary. When not installing above a door, you must have adequate framing inside of the wall. WhisperKOOL recommends consulting a licensed contractor for framing and construction needs.
  • Page 14: Installation

    INSTALLATION Mounting STEP 4 Options Determine which of the four bracket mounting options (displayed in Figure 1) will be the most suitable for the desired position of the cooling unit. Figure 1 STEP 5 Foam tape needs to be placed on bracket surfaces which will be in direct contact with the wall.
  • Page 15 STEP 9 If removed, reinstall the grilles on both sides of the unit and plug in the power cord. The use of an extension cord is not recommended. www.whisperkool.com | Page 13...
  • Page 16: Liquid-Measuring Thermostat System

    LIQUID-MEASURING THERMOSTAT SYSTEM (BOTTLE PROBE) WhisperKOOL cooling units come with a liquid-temperature-measuring thermostat. The self-calibrating bottle probe contains a sensor which communicates back and forth with the thermostat. This results in a consistent temperature setting and accuracy. Wine should be kept at a very precise, controlled temperature and humidity. By measuring the liquid temperature rather than air, the unit will operate 75–80% of the time.
  • Page 17: System Operation

    Once the compressor relay is de-energized the controller must with all WhisperKOOL units. APST ensures that, in the event of wait five minutes before reenergizing the relay. This prevents a cooling deficiency, the heat from the indoor fan will not raise the compressor from repeatedly turning off and on.
  • Page 18: Slimline 2500 Wiring Diagram

    SLIMLINE 2500 WIRING DIAGRAM Evaporator Evaporator Condenser Condenser Page 16 | 1-800-343-9463 SL 040418...
  • Page 19: Slimline 3300 Wiring Diagram

    Slimline SLIMLINE 3300 WIRING DIAGRAM Evaporator Evaporator Condenser Condenser www.whisperkool.com | Page 17...
  • Page 20: Controller Functions

    CONTROLLER FUNCTIONS Button/Symbol Normal Functions ON/OFF The ON/OFF button allows the customer the convenience of turning the refrigeration system on or off from the control panel. This feature does not disconnect power from the unit. In order for the power to be shut off from the unit, the power cord must be unplugged from the wall outlet.
  • Page 21 Allow the room to warm up, which will increase the temperature of the wine “LA” perature of 4° below the setpoint Defective bottle probe Replace the bottle probe “POF” The controller is locked Hold UP and DOWN ARROW buttons for 3 to 5 seconds to disable. “PON” should appear. www.whisperkool.com | Page 19...
  • Page 22 CUSTOMER Customer Preference Selection Mode (CPSM) permits customers to fine-tune their unit’s operating system. The PREFERENCE CPSM menu is accessed by pressing the SET and DOWN ARROW buttons simultaneously for 10-15 seconds. SELECTION MODE The following CPSM options are available in the menu: FOn –...
  • Page 23: Maintenance Schedule

    1. Clean front and rear intake grilles Annually 1. Use a vacuum with brush attachment to clean grilles 2. Inspect for corrosion 3. Check wiring connections and integrity of cords 4. Pour a 50/50 bleach solution into the drain line every spring www.whisperkool.com | Page 21...
  • Page 24 NOTES Page 22 | 1-800-343-9463 SL 040418...
  • Page 25: Troubleshooting Guide

    If so, contact your installing techni- cian to assist with troubleshooting. System runs constantly Possible Cause Solution Leaky door seal or poorly insulated cellar Fix leaky door seal and insulate cellar in accordance with this manual (page 8) www.whisperkool.com | Page 23...
  • Page 26 TROUBLESHOOTING GUIDE Unit leaks water Possible Cause Solution Unit is not level Unit should be level in wall to prevent leaking Drain line clogged or kinked Check drain line to make sure water can flow freely Drain is clogged, preventing water from escaping Disconnect drain and clear it out Drain line does not have a downward slope Fix drain line so there is a downward slope from the unit to the drain...
  • Page 27: Technical Assistance & Accessories

    Slimline TECHNICAL ASSISTANCE WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. Pacific Standard Time. Your customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: •...
  • Page 28: Installation Terms & Conditions

    A. Two (2) Year Limited Warranty: For the period of TWO (2) YEARS (the “Limited Warranty Period”) from the date of original sale of a Product by WhisperKOOL, if a WhisperKOOL Product is found to be defective in material or workmanship after undergoing WhisperKOOL’s Customer Service troubleshooting, then, subject to the WhisperKOOL Product Limited...
  • Page 29 16. No one has any authority to add to or vary the limited warranty on this Product. 3. Product Installation Requirements: A. Prior to installing a WhisperKOOL Product, the End User must read the WhisperKOOL Owner’s Manual and thereafter the End User must follow the required installation, use and maintenance procedures set forth by WhisperKOOL in WhisperKOOL’s Owner’s Manual.
  • Page 30 County of San Joaquin, State of California, and all parties, WhisperKOOL, Purchaser and End User, hereby irrevocably submit to the personal jurisdiction of such courts for that purpose. No waiver by WhisperKOOL of any breach or default of the contract of sale (including these Terms and Conditions of Sale) concerning a Product will be deemed to be a waiver of any preceding or subsequent breach or default.
  • Page 31 E-mail: support@whisperkool.com Web: www.whisperkool.com B. Technical Assistance: WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. (PST). The Customer Service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: 1.
  • Page 32 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1(800) 343-9463 www.whisperkool.com...
