ESP32-H2 series is a low-power MCU-based SoC solution that supports Bluetooth
Thread 1.3 (802.15.4). With its state-of-the-art power and RF performance, this SoC is an ideal choice for a wide
variety of application scenarios relating to Internet of Things (IoT), smart home, industrial automation, health care,
and consumer electronics.
ESP32-H2 has a 32-bit RISC-V processor, operating at up to 96 MHz. The chip supports application
development to operate without the need for a host MCU.
ESP32-H2 series provides a highly-integrated way to implement wireless communication technologies using a
complete RF subsystem, including a antenna switch, RF balun, power amplifier, low noise amplifier (LNA), filter,
power management unit, calibration circuits, etc. As a result, PCB size has been greatly reduced.
With its advanced calibration circuitry, ESP32-H2 series can dynamically adjust itself to remove external circuit
imperfections or adapt to changes in external conditions.
For more information about ESP32-H2 series, please refer to
Note:
Unless otherwise specified, "ESP32-H2" used in this document refers to the series of chips, instead of a specific chip
variant.
