Espressif Systems ESP32-H2 Series Hardware Design Manuallines page 4

List of Figures
List of Tables
1 Description of Timing Parameters for Power-up and Reset
2 Chip Boot Mode Control
3 Description of Timing Parameters for the Strapping Pins
4 IO MUX Pin Functions
List of Figures
1 ESP32-H2 Schematic
2 Schematic for the Digital Power Supply Pins
3 Schematic for the Analog Power Supply Pins
4 Visualization of Timing Parameters for Power-up and Reset
5 Schematic for the Crystal
6 Schematic for the RTC Clock
7 Schematic for RF Matching
8 RF Tuning Diagram
9 Visualization of Timing Parameters for the Strapping Pins
10 ESP32-H2 PCB Layout
11 Placement of ESP32-H2 Modules on Base Board (antenna feed point on the right)
12 Placement of ESP32-H2 Modules on Base Board (antenna feed point on the left)
13 Keepout Zone for ESP32-H2 Module's Antenna on the Base Board
14 ESP32-H2 Power Traces in a Four-layer PCB Design
15 ESP32-H2 Crystal Oscillator Layout (Connected to the Ground)
16 ESP32-H2 Crystal Oscillator Layout (Not Connected to the Ground)
17 ESP32-H2 RF Layout in a Four-layer PCB Design
18 ESP32-H2 PCB Stack up Design
19 ESP32-H2 Stub in a Four-layer PCB Design
20 ESP32-H2 UART0 Layout
Espressif Systems 4
Submit Documentation Feedback
ESP32-H2 Series Hardware Design Guidelines v0.5
9
13
13
14
6
7
8
9
10
11
12
12
14
17
18
19
20
20
22
23
23
24
25
25
