2 Schematic Checklist
Name
MTDO
MTCK
MTDI
GPIO8
GPIO9
GPIO10
GPIO11
GPIO12
XTAL_32K_P
XTAL_32K_N
GPIO22
U0RXD
U0TXD
GPIO25
GPIO26
GPIO27
Reset
The default configuration of each pin after reset:
• 0 - input disabled, in high impedance state (IE = 0)
• 1 - input enabled, in high impedance state (IE = 1)
• 2 - input enabled, pull-down resistor enabled (IE = 1, WPD = 1)
• 3 - input enabled, pull-up resistor enabled (IE = 1, WPU = 1)
• 4 - output enabled, pull-up registor enabled (OE = 1, WPU = 1)
• 1* - When the value of eFuse bit EFUSE_DIS_PAD_JTAG is
0, input enabled, pull-up resistor enabled (IE = 1, WPU = 1)
1, input enabled, in high impedance state (IE = 1)
• 3* - input enabled, pull-up resistor enabled (IE = 1, WPU = 0, USB_WPU = 1). See details in Notes
We recommend pulling high or low GPIO pins in high impedance state to avoid unnecessary power
consumption. You may add pull-up and pull-down resistors in your PCB design, or enable internal pull-up and
pull-down resistors during software initialization.
Notes
• R - These pins have analog functions.
• USB - The pull-up value of a USB pin is controlled by the pin's pull-up value together with the USB pull-up
value. If any of the two pull-up values is 1, the pin's pull-up resistor will be enabled. The pull-up resistors of
USB pins are controlled by the USB_SERIAL_JTAG_DP/DM_PULLUP bit, and the pull-up value is
Espressif Systems
No. Function 0
6 MTDO
7 MTCK
8 MTDI
10 GPIO8
11 GPIO9
12 GPIO10
13 GPIO11
14 GPIO12
15 GPIO13
16 GPIO14
21 GPIO22
22 U0RXD
23 U0TXD
24 GPIO25
25 GPIO26
26 GPIO27
Submit Documentation Feedback
Function 1 Function 2
GPIO3 FSPIHD
GPIO4 FSPICLK
GPIO5 FSPID
GPIO8 —
GPIO9 —
GPIO10 —
GPIO11 —
GPIO12 —
GPIO13 —
GPIO14 —
GPIO22 —
GPIO23 FSPICS1
GPIO24 FSPICS2
GPIO25 FSPICS3
GPIO26 FSPICS4
GPIO27 FSPICS5
15
ESP32-H2 Series Hardware Design Guidelines v0.5
Reset Notes
1 R
1* R
1 R
1 —
3 —
0 R
0 R
0 —
0 R
0 R
0 —
3 —
4 —
1 —
1 R, USB
3* R, USB
