- Page 1 INSTALLATION INSTRUCTIONS VOLT LOW VOLTAGE LANDSCAPE LIGHTING ® VOLT ® Modernelle Flat Top Brass Path Light (Bronze) ITEM: VAL-1052-BBZ 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- Page 2 INSTALLATION INSTRUCTIONS VOLT Modernelle Flat Top Brass Path Light (Bronze) - VAL-1052-BBZ ® IMPORTANT: PLEASE READ BEFORE INSTALLATION This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 PACKAGE CONTENTS A. (1) Fixture Body Parts Required (Sold Separately) B. Mounting Accessory A. (1) G4 Bulb PRODUCT DIMENSIONS 8.47” 24” 7.1” 7.1” 813.978.3700 • customersupport@voltlighting.com • www.voltlighting.com...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Modernelle Flat Top Brass Path Light (Bronze) - VAL-1052-BBZ ® REMOVE LENS Remove the lens from the fix- Fixture Fixture ture. Lens Screw Install G4 Bulb G4 Bulb Insert G4 bulb with correct wattage and type marked on fixture label.
- Page 5 Install Lens Place the lens back onto Fixture Fixture the fixture and secure with previously removed screws. Lens Screw Install Lamp Body to Stake Pass the fixture wire through the stake and thread the stake onto the fixture. Thread the lock ring against the stake and hand tight- en until snug.
- Page 6 INSTALLATION INSTRUCTIONS VOLT Modernelle Flat Top Brass Path Light (Bronze) - VAL-1052-BBZ ® INSTALL STAKE Determine the desired location for mounting the fixture. Insert the stake into the ground until flange of stake is flush to grade. NOTE: If the ground is hard and...
- Page 7 INSTALL REPLACE BULB Please reverse Step 2 - Step 3 to expose the G4 bulb and replace it with the correct wattage and type marked on the fixture label. Then, reinstall the shade. IMPORTANT: The G4 bulb must be protected from moisture and dust at all times.
- Page 8 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2023, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • www.voltlighting.com...
