INSTALLATION INSTRUCTIONS
VOLT
Low Voltage Landscape Lighting
®
VOLT
Woodsman Integrated LED Downlight
®
VAL-1811-40-BBZ or VAL-1811-40-ABZ
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2017, VOLT
customersupport@voltlighting.com • 813.978.3700
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Volt VAL-1811-40-BBZ
Summary of Contents for Volt VAL-1811-40-BBZ
- Page 1 Low Voltage Landscape Lighting ® VOLT Woodsman Integrated LED Downlight ® VAL-1811-40-BBZ or VAL-1811-40-ABZ Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2017, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
- Page 2 INSTALLATION INSTRUCTIONS VOLT Woodsman Integrated LED Downlight ® VAL-1811-40-BBZ or VAL-1811-40-ABZ Important: Please Read Before Installation This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage, and void the warranty.
- Page 3 Package Contents A. (1) Fixture B. Mounting Hardware Product Dimensions 8” 8 1/4” 4 1/4” 9 3/4” Install Fixture Determine your desired location for the fixture. Pass self-tapping Fixture screws through the holes on the fixture mount and thread the self-tapping screws into desired Fixture location to secure the fixture.
- Page 4 INSTALLATION INSTRUCTIONS VOLT Woodsman Integrated LED Downlight ® VAL-1811-40-BBZ or VAL-1811-40-ABZ Wire Connections Pigtail Wire Connectors Main Supply Cable Strip both leads from the luminaire pigtail. Using two wire connectors (sold separately), connect both leads from the luminaire to main supply cable leads.
- Page 5 Install / Replace Optic Remove Glare Guard and Inner Shade Loosen the thumb screw and Glare Guard remove the glare guard from Lens lens. Remove the lens from the fixture body by unscrewing it counter-clockwise. Fixture Body Thumb Screw Replace Optic Remove plug at the center of optic.
- Page 6 w w w . v o l t l i g h t i n g . c o m - 6 -...
- Page 7 customersupport@voltlighting.com • 813.978.3700 - 7 -...
- Page 8 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2017, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
