Summary of Contents for Clevo P170SM-A

  • Page 1 P170SM-A...
  • Page 3 Preface Notebook Computer P170SM-A Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the P170SM-A series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data.  Take care when using peripheral devices. Removal Warning Use only approved brands of Unplug the power cord before When removing any peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on Disc This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Removing the Top Cover .............. 2-28 Part Lists ..........A-1 Overview ..................1-1 External Locator - Top View with LCD Panel Open ......1-4 Part List Illustration Location ............A-2 External Locator - Front & Right side Views .........1-5 Top with Fingerprint ..............
  • Page 12 Preface Lynix Point 1/9 ................B-20 Function LED Board ..............B-52 Lynix Point 2/9 ................B-21 Indicatory LED Board ..............B-53 Lynix Point3/9 ................B-22 P170 2nd HDD Board ..............B-54 Lynix Point 4/9 ................B-23 Power & LED Board ..............B-55 Lynix Point 5/9 ................B-24 P170 Click Board ................B-56 Lynix Point 6/9 ................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the P170SM-A series notebook computer. Informa- tion about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g.
  • Page 14 Introduction Specifications Storage Processor Options (Factory Option) One 12.7mm(h) Optical Device Type Intel® Core™ i7 Processor Drive (Super Multi Drive/Blu-Ray Combo Drive/Blu-Ray i7-4930MX (3.00GHz) Writer Drive) 8MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 57W Two Changeable 2.5" (h) SATA (Serial) Hard Disk Drives Intel®...

  • Page 15: Overview

    Introduction Audio Communication High Definition Audio Compliant Interface Built-In Gigabit Ethernet LAN S/PDIF Digital Output 2,0M FHD PC Camera Module Two Speakers WLAN/ Bluetooth Half Mini-Card Modules: One Sub Woofer (Factory Option) Intel® Centrino® Ultimate-N 6300 Wire- Built-In Microphone less LAN (802.11a/g/n) Sound Blaster Audio (Factory Option) Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In PC Camera 2. PC Camera LED 3. Built-In Microphone 4. LCD 5. Speakers 6. LED Indicators 7. Power Button 8. Illuminated Keyboard 9. TouchPad and Buttons 10.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power Indicators Figure 3 Right Side Views 1. Optical Device Drive Bay 2. Emergency Eject Hole 3. Headphone Jack 4. Microphone Jack 5. S/PDIF-Out Jack 6.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Mini-IEEE 1394a Port 2. RJ-45 LAN Jack 3. USB 3.0 Port / USB Charge 4. USB 3.0 Port 5. Combined eSATA/ Powered USB 3.0 Port 6.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Sub Woofer 2. Fan Outlet/Intake 3. Component Bay Cover 4. Primary HDD Bay 5. Secondary HDD 6. Battery  Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com-...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Platform Controller Hub 2. Audio Codec 3. KBC ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. VGA-Card Connector 2. CPU Socket (no CPU installed) 3. Memory Slots DDR3L SO-DIMM (Primary) 4. Hard Disk Connector 5. MSATA Connector Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. USB 3.0 Port / e-SATA 2. Multi-in-1 Card Reader 3. KB LED Connector 4. TP LED Cable Connector 5. LED 4 Cable Connector 6. TouchPad Cable Connector 7. MSATA Cable Connector 8.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. DC-In Jack 2. Mini Display Port 3. HDMI-Out Port 4. Display Port 5. VGA Fan Cable Connector 6. Sub Woofer Cable Connector 7. CPU Fan Cable Connector 8. USB 3.0 Ports 9.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the P170SM-A series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Secondary System Memory: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a Figure 1 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a Battery Removal 4.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 4. Slide the HDD assembly in the direction of the arrow (Figure 3c Figure 3 5. Remove the hard disk assembly (Figure 3d HDD Assembly 6. Remove screws & and the insulation plate (Figure 3e Removal (cont’d.) 7. Reverse the process to install a new hard disk (do not forget to replace all the screws and covers). c.
  • Page 32 Disassembly Hard Disk Size Note (Foam Rubber Insert) Note that the hard disks pictured on the following pages are all 9.5mm(H) hard disk drives. In some cases 7mm(H) hard disk drives will be installed. Figure 4 Foam Rubber Insert for 7mm(H) HDDs •...

  • Page 33: Removing The Ssd

    Disassembly Removing the SSD Figure 5 SSD Removal 1. Turn off the computer, and remove the battery (page 2 - 5) and hard disk (page 2 - 2. Remove the screws from the shielding plate (Figure 5a a. Remove the screws. 3.

  • Page 34: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 6 Optical Device 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Locate the secondary hard disk bay cover and remove screws & (Figure 6a 3. Remove the hard disk bay cover and screw at point (Figure 6b a.
  • Page 35 Disassembly 6. Carefully pry the bezel off the optical device at point (Figure 7d Figure 7 7. Separate the bezel and the optical device. Optical Device 8. Reverse the process to attach the front bezel with the new optical device at point (Figure 7f).

  • Page 36: Removing The Hard Disk From The Secondary Hdd Bay

    Disassembly Removing the Hard Disk from the Secondary HDD Bay Figure 8 Note that the secondary hard disk (if installed) is located under the optical device bay (CD/DVD). Secondary HDD Assembly Removal 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and optical device (page 2 -...
  • Page 37 Disassembly 5. Remove screws and the insulation plate from the hard disk (Figure 9d). Figure 9 Secondary HDD Assembly Removal d. Remove the screws and the insulation plate. 6. Reverse the process to install a new disk (make sure you install the insulation plate). 7.

  • Page 38: Removing The Primary System Memory (Ram)

    Disassembly Removing the Primary System Memory (RAM) Figure 10 The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO-DIMM) DDR 3L type memory modules RAM Module (see “Memory” on page 1 - 2 ). The total memory size is automatically detected by the POST routine once you turn on your Removal computer.
  • Page 39 Disassembly 4. Lift the component bay cover off the computer case. The modules will be visible at point (Figure 11c Figure 11 5. Gently pull the two release latches ( ) on the sides of the memory socket(s) in the direction indicated below &...

  • Page 40: Removing The Secondary System Memory (Ram)

    Disassembly Removing the Secondary System Memory (RAM) Figure 12 RAM Module Memory Upgrade Process Removal 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5), and component bay cover (page 2 - 14). a. Remove 2.
  • Page 41 Disassembly 5. Disconnect the keyboard ribbon cable and LED ribbon cable from the locking collar socket & by using Figure 13 a small flat-head screwdriver to pry the locking collar pins away from the base. (Figure 13e). RAM Module 6. Remove the keyboard and the memory sockets &...

  • Page 42: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 14 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the keyboard (page 2 - Module Removal 2. The Wireless LAN module will be visible at point under the keyboard (Figure 14a).

  • Page 43: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 44: Removing The Msata Module

    Disassembly Removing the MSATA Module Figure 15 MSATA Module 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 14). Removal 2. Locate the module, it is visible at point Figure 15a 3.

  • Page 45: Removing And Installing The Processor

    Disassembly Removing and Installing the Processor Figure 16 Processor Processor Removal Procedure Removal 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 14). Procedure 2. Remove screws from the heat sink unit in the order indicated on the label (i.e screw 4 first through to screw 1 last Figure 16a)
  • Page 46 Disassembly 4. Turn the release latch towards the unlock symbol , to release the CPU (Figure 17c). Figure 17 5. Carefully (it may be hot) lift the CPU up out of the socket (Figure 17d). Processor Removal 6. See page 2 - 23 for information on inserting a new CPU.
  • Page 47 Disassembly Processor Installation Procedure Figure 18 Processor 1. Insert the CPU , pay careful attention to the pin alignment (Figure 18a), it will fit only one way (DO NOT Installation FORCE IT!), and turn the release latch towards the lock symbol (Figure 18b).

  • Page 48: Removing And Installing The Video Card

    Disassembly Removing and Installing the Video Card Figure 19 Video Card Video Card Removal Procedure Removal Procedure Turn off the computer, turn it over and remove the battery (page 2 - 5) and component cover (page 2 - Remove screws from the heat sink unit in the order indicated on the label (i.e screw 7 first through to screw a.
  • Page 49 Disassembly For video card (N15E-GX) additional removal procedure Figure 20 Remove screws from the video card assembly (Figure 20e) Video Card Separate the shielding plate from the video card (Figure 19d) Removal Procedure (cont’d.) e. Remove the screws. f. Separate shielding plate and video card.
  • Page 50 Disassembly Installing a New Video Card Figure 21 Installing a New Prepare to fit the video card into the slot by holding it at about a 30° angle (Figure 21e). Video Card The card needs to be fully into the slot, and the video card and socket have a guide-key and pin which align to allow the card to fit securely (Figure 21f)

  • Page 51: Removing The Ccd

    Disassembly Removing the CCD Figure 22 CCD Module 1. Turn off the computer, remove the battery (page 2 - Removal Remove the rubbers and screws (Figure 22a) 3. Run your fingers around the inner frame of the LCD panel at the points indicated by the arrows (Figure a.

  • Page 52: Removing The Top Cover

    Disassembly Removing the Top Cover Figure 23 Top Cover Removal 1. Turn off the computer, remove the battery (page 2 - 5), component bay cover (page 2 - 14), and keyboard (page 2 16). a. Disconnect cable Disconnect the cable connectors and c arefully lift the corresponding wires at the point from the holder as...
  • Page 53 Disassembly 5. Remove screws (Figure 24d). Figure 24 6. Lift the top cover at point (Figure 24e). Top Cover Removal 7. Carefully separate the top cover from the bottom case in the direction of the arrow at point . The hinge (cont’d) cover will automatically be released from its holder...
  • Page 54 Disassembly 2 - 30...

  • Page 55: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the P170SM-A series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 56: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts Top with Fingerprint page A - 3 Top without Fingerprint page A - 4 Bottom (N15E-GX) page A - 5 Bottom (N15P-GX)

  • Page 57: Top With Fingerprint

    Part Lists Top with Fingerprint Figure A - 1 Top with Fingerprint Top with Fingerprint A - 3...

  • Page 58: Top Without Fingerprint

    Part Lists Top without Fingerprint Figure A - 2 Top without Fingerprint A - 4 Top without Fingerprint...

  • Page 59: Bottom (N15E-Gx

    Part Lists Bottom (N15E-GX) Figure A - 3 Bottom (N15E-GX) (非耐落) Bottom (N15E-GX) A - 5...

  • Page 60: Bottom (N15P-Gx

    Part Lists Bottom (N15P-GX) Figure A - 4 Bottom (N15P-GX) (非耐落) A - 6 Bottom (N15P-GX)

  • Page 61: Lcd

    Part Lists Figure A - 5 LCD A - 7...

  • Page 62: Combo

    Part Lists COMBO Figure A - 6 COMBO A - 8 COMBO...

  • Page 63: Dvd-Dual Drive

    Part Lists DVD-Dual Drive Figure A - 7 DVD-Dual Drive DVD-Dual Drive A - 9...
  • Page 64 Part Lists A - 10...

  • Page 65: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the P170SM-A notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Diagram - Page Table B - 1...
  • Page 66 Schematic Diagrams Block Diagram P150SM-A Shark Bay System Block Diagram AUDIO BOARD VDD3,VDD5 SHEET 47 PHONE JACK x4, USB x1 SHEET 40 POWER LED BOARD P170 Finger BOARD SHEET 50 5V,3.3V,5VS,3VS, SHEET 56 6-7P-P15SG-0A4 SHEET 41 3.3VM P150 ODD BOARD SHEET 48 <=5"...

  • Page 67: Processor 1/7

    Schematic Diagrams Processor 1/7 Haswell Processor 1/7 ( DMI,FDI,PEG ) 20 mil PEG_IRCOMP_R R130 R130 24.9_1%_04 24.9_1%_04 VCCIOA_OUT U32A U32A Haswell rPGA EDS Haswell rPGA EDS VGA SIDE PEG_RXN[0..15] 13 PEG_RCOMP PEG_RXN_0 C367 C367 0.22u_10V_X5R_04 0.22u_10V_X5R_04 PEG_RXN0 PEG_RXN_0 DMI_TXN0 PEG_RXN_1 C525 C525 0.22u_10V_X5R_04...

  • Page 68: Processor 2/7

    Schematic Diagrams Processor 2/7 Haswell Processor 2/7 ( MISC,JTAG,CLK ) PU/PD for JTAG signals 1.05VS U32B U32B Haswell rPGA EDS Haswell rPGA EDS XDP_TMS R395 R395 51_04 51_04 SKTOCC# AP32 MISC MISC SM_RCOMP_0 XDP_TDI_R R400 R400 51_04 51_04 SKTOCC SM_RCOMP_0 SM_RCOMP_1 XDP_PREQ# R397...

  • Page 69: Processor 3/7

    Schematic Diagrams Processor 3/7 Haswell Processor 3/7 ( DDR3L ) U32C U32C Haswell rPGA EDS Haswell rPGA EDS U32D U32D 9,10 M_A_DQ[63:0] Haswell rPGA EDS Haswell rPGA EDS 11,12 M_B_DQ[63:0] M_A_DQ0 AR15 RSVD_AC7 SA_DQ_0 RSVD M_A_DQ1 AT14 M_A_CLK_DDR#0 M_B_DQ0 AR18 RSVD_AG8 SA_DQ_1 SA_CKN0...
  • Page 70 Schematic Diagrams Processor 4/7 Haswell Processor 4/7 ( DISPLAY ) 3.3VS EDP_DISP_UTIL *2.2K_04 *2.2K_04 VCCIO_OUT Sheet 5 of 66 VCCIOA_OUT Processor 4/7 R701 R701 Haswell rPGA EDS Haswell rPGA EDS U32H U32H 24.9_1%_04 24.9_1%_04 10K_04 10K_04 DP_TDB#0 DDIB_TXN0 EDP_AUXN iGP_eDP_AUX# 15 DP_TDB0 DDIB_TXP0 EDP_AUXP...

  • Page 71: Processor 5/7

    Schematic Diagrams Processor 5/7 Haswell Processor 5/7 ( POWER ) V_VCCDDQ VDDQ PJ27 PJ27 *5mm *5mm C391 C391 C479 C479 D01a_1009_Alex *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 95A (1.6-1.85V ,57W CPU) VCORE VCORE 95A(57W CPU) V_VCCDDQ U32E U32E Haswell rPGA EDS Haswell rPGA EDS 4.2A (1.35V) AA26 Gary D03...
  • Page 72 Schematic Diagrams Processor 6/7 Haswell Processor 6/7 ( GND ) U32F U32F Haswell rPGA EDS Haswell rPGA EDS U32G U32G Haswell rPGA EDS Haswell rPGA EDS AK34 AL10 AL11 AL12 AL14 AL15 AL17 AL18 AL20 AL21 AA11 AL23 AA25 AA27 AA31 AA29 Sheet 7 of 66...

  • Page 73: Processor 7/7

    Schematic Diagrams Processor 7/7 Haswell Processor 7/7 ( RESERVED ) CFG STRAPS FOR PROCESSOR PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS 1: (DEFAULT)NORMAL OPERATION; U32I U32I Haswell rPGA EDS Haswell rPGA EDS LANE# DEFINITION MATCHES CFG2 SOCKET PIN MAP DEFINITION RSVD_AT1 RSVD_TP RSVD_AT2...

  • Page 74: Ddr3 Cha So-Dimm_0

    Schematic Diagrams DDR3 CHA SO-DIMM_0 Channel A SO-DIMM 0[RAM1] CHANGE TO STANDARD JDIMM3A JDIMM3A 4,10 M_A_A[15:0] M_A_DQ[63:0] 4,10 M_A_A0 M_A_DQ0 JDIMM3B JDIMM3B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 VDDQ M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 M_A_A6 M_A_DQ6 VDD2 VSS17 M_A_A7 M_A_DQ7 VDD3 VSS18...

  • Page 75: Ddr3 Cha So-Dimm_1

    Schematic Diagrams DDR3 CHA SO-DIMM_1 Channel A SO-DIMM 1[RAM3] CHANGE TO STANDARD JDIMM1A JDIMM1A M_A_A[15:0] M_A_DQ[63:0] 4,9 M_A_A0 M_A_DQ0 JDIMM1B JDIMM1B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 VDDQ M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 M_A_A6 M_A_DQ6 VDD2 VSS17 M_A_A7 M_A_DQ7 VDD3 VSS18 M_A_A8...

  • Page 76: Ddr3 Chb So-Dimm_1

    Schematic Diagrams DDR3 CHB SO-DIMM_1 Channel B SO-DIMM 1[RAM4] CHANGE TO STANDARD JDIMM2A JDIMM2A 4,12 M_B_B[15:0] M_B_DQ[63:0] 4,12 M_B_B0 M_B_DQ0 JDIMM2B JDIMM2B M_B_B1 M_B_DQ1 M_B_B2 M_B_DQ2 VDDQ M_B_B3 M_B_DQ3 M_B_B4 M_B_DQ4 M_B_B5 M_B_DQ5 VDD1 VSS16 M_B_B6 M_B_DQ6 VDD2 VSS17 M_B_B7 M_B_DQ7 VDD3 VSS18...

  • Page 77: Ddriii Chb So-Dimm_0

    Schematic Diagrams DDRIII CHB SO-DIMM_0 Channel B SO-DIMM 0[RAM2] CHANGE TO STANDARD JDIMM4A JDIMM4A 4,11 M_B_B[15:0] M_B_DQ[63:0] 4,11 M_B_B0 M_B_DQ0 JDIMM4B JDIMM4B M_B_B1 M_B_DQ1 M_B_B2 M_B_DQ2 M_B_B3 M_B_DQ3 VDDQ M_B_B4 M_B_DQ4 M_B_B5 M_B_DQ5 VDD1 VSS16 M_B_B6 M_B_DQ6 VDD2 VSS17 M_B_B7 M_B_DQ7 VDD3 VSS18...

  • Page 78: Mxm Pci-E

    Schematic Diagrams MXM PCI-E 3V3_RUN PW R_SRC PW R_SRC J_MXM1B J_MXM1B VDD3 CLK_PCIE_MXM# PEX_REFCLK# CLK_REQ# R195 R195 *10mil_short *10mil_short MXM 3.0 CLK_PCIE_MXM PEX_REFCLK PEX_RST# J_MXM1A J_MXM1A VGA_DDC_DAT E1-1 E2-1 D06 for NV & AMD MXM card R1009 R1009 3.3VS MXM_RST# PWR_SRC PWR_SRC RSVD...

  • Page 79: Panel, Inverter, Crt

    Schematic Diagrams Panel, Inverter, CRT PANEL HPD_L 40Pin & 30Pin Conn Co-layout Pin7,9 iGP_eDP_HPD R149 R149 1K_04 1K_04 iGP_eDP_HPD , Pin7,9 NC Pin. C154 C154 *BAV99 RECTIFIER *BAV99 RECTIFIER J_LCD1 J_LCD1 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 LVDS_UCLKN LVDS_UCLKP LVDS_UCLKN LVDS_UCLKP 15 3.3V PLVDD 3.3VS LVDS_U1N LVDS_U2N...

  • Page 80: Ps8625

    Schematic Diagrams PS8625 D04_Reflash_0910_Alex D04_Reflash_0910_Alex ENPVCC PS_PANEL_EN 14 BCIHP0420TB-2R2M BCIHP0420TB-2R2M HCB1005KF-121T20 HCB1005KF-121T20 HCB1005KF-121T20 HCB1005KF-121T20 HCB1005KF-121T20 HCB1005KF-121T20 ENBLT PS_BKL_EN 14 3.3VS VDDIO 3.3VS VDDIOX SW _OUT VDD12 VDDRX PW MO PW MO C534 C534 C195 C195 C170 C170 C533 C533 C169 C169 C438 C438...

  • Page 81: 1394A_Xio2221

    Schematic Diagrams 1394a_XIO2221 C694 C694 270p_50V_X7R_04 270p_50V_X7R_04 AVDD_33 3.3VS PLVDD_33 IEEE1394a 3.3VS VDD_15 VDD_33 1394_TPBIAS0 C693 C693 1u_6.3V_X5R_04 1u_6.3V_X5R_04 HCB1005KF-121T20 HCB1005KF-121T20 HCB1005KF-121T20 HCB1005KF-121T20 D02 12/03 Value Gary R487 R487 56_04 56_04 D02 12/03 Value Gary D02_1112_Alex C836 C836 C832 C832 C833 C833 D02_1112_Alex...

  • Page 82: Display Port

    Schematic Diagrams Display Port dGPU DISPLAY PORT Sheet 17 of 66 PLEASE CLOSE TO CONNECTOR Display Port R719 R719 0_04 0_04 Close to Display PORT R720 R720 0_04 0_04 LP11 LP11 DP_B#3 C132 C132 0.1u_10V_X7R_04 0.1u_10V_X7R_04 D_DP_B#3 3.3VS C160 C160 0.1u_10V_X7R_04 0.1u_10V_X7R_04 D_DP_B3...

  • Page 83: Hdmi

    Schematic Diagrams HDMI HDMI CONNECTOR D04_Reflash_0910_Alex 5VS_HDMI R198 R198 FLG# VOUT1 P150SM-A-D01_Alex *4.7K_04 *4.7K_04 J_HDMI1 J_HDMI1 VIN1 VOUT2 VIN2 VOUT3 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 13,39,41,42 SUSB HDMI_HPD-C HDMI_HPD-C HOT PLUG DETECT AP2301M8G-13 AP2301M8G-13 DDC/CEC GND TMDS_CLOCK#-R HDMI_SDA-C HDMI_SCL-C RESERVED R192 R192 HDMI_CEC 220_04...

  • Page 84: Lynix Point 1/9

    Schematic Diagrams Lynix Point 1/9 Lynx Point (RTC,AZALIA,SATA,JTAG) INTVRMEN- Integrated SUS D02_1112_Stanley C222 C222 1.05V VRM Enable 22p_50V_NPO_04 22p_50V_NPO_04 High - Enable Internal VRs RTCVCC P/N:6-S03-0LYNX-0S0 Low - Enable External VRs VDD3 R199 R199 LPT_PCH_M_EDS LPT_PCH_M_EDS U19A U19A C264 C264 1u_6.3V_X5R_06 1u_6.3V_X5R_06 10M_04...

  • Page 85: Lynix Point 2/9

    Schematic Diagrams Lynix Point 2/9 Gary D03 3.3V_SPI Base on Lynx Point (LPC,SMBUS SPI,C-LINK) *OPEN-1mm *OPEN-1mm VDD3 3.3V_SPI VDD3 RTC-WakeUp D04_Reflash_0909_Alex PCH_BT_EN# R525 R525 10K_04 10K_04 SMB_CLK R722 R722 2.2K_04 2.2K_04 SMB_DATA R726 R726 2.2K_04 2.2K_04 DRAMRST_CNTRL R246 R246 1K_04 1K_04 SML0_DATA R756...
  • Page 86 Schematic Diagrams Lynix Point3/9 Lynx Point (DMI,FDI,GPIO) DSWODVREN - On Die DSW VR Enable R1 STUFFED, Enabled (DEFAULT) R2 UNSTUFFED LPT_PCH_M_EDS LPT_PCH_M_EDS U19B U19B DMI_RXN0 AW22 R1 STUFFED, Disabled DMI_RXN0 DMI_RXN_0 DMI_RXN1 AR20 DMI_RXN1 DMI_RXN_1 R2 UNSTUFFED AJ35 FDI_RXN_0 DMI_RXN2 AP17 DMI_RXN2 DMI_RXN_2...

  • Page 87: Lynix Point 4/9

    Schematic Diagrams Lynix Point 4/9 Lynx Point (CRT,DISPLAY,PCI) Boot BIOS Strap 3.3VS BBS_BIT1 BBS_BIT0 Boot BIOS Location DP_TDB_AUX# 61 Q115A Q115A Q115B Q115B R931 R931 MTDN7002ZHS6R MTDN7002ZHS6R MTDN7002ZHS6R MTDN7002ZHS6R Reserved (NAND) 100K_1%_04 100K_1%_04 DP_TDB_AUX#_R 0.1u_10V_X7R_04 0.1u_10V_X7R_04 DP_TDB_AUX_R C151 C151 0.1u_10V_X7R_04 0.1u_10V_X7R_04 DP_TDB_AUX 61 R463...

  • Page 88: Lynix Point 5/9

    Schematic Diagrams Lynix Point 5/9 Lynx Point (PCIe,USB) U19I U19I LPT_PCH_M_EDS LPT_PCH_M_EDS AW31 PERN1/USB3RN3 USB2N0 USB_PN0 28 AY31 USB3 PORT1 PERP1/USB3RP3 USB2P0 USB_PP0 28 USB_PN1 38 USB2N1 BE32 USB3 PORT2 USB_PP1 38 PETN1/USB3TN3 USB2P1 BC32 PETP1/USB3TP3 USB2N2 USB_PN2 36 FINGER USB2P2 USB_PP2 36 AT31...

  • Page 89: Lynix Point 6/9

    Schematic Diagrams Lynix Point 6/9 Lynx Point (GPIO,VSS_NCTF,RSVD) D01a_1011_Alex VDD3 D01a_1009_Alex R305 R305 10K_04 10K_04 SB_BLON R676 R676 10K_04 10K_04 GPIO27 R600 R600 *10K_04 *10K_04 PLL_ODVR_EN PLL_ODVR_EN R559 R559 *1K_04 *1K_04 PLL_ODVR_EN: HIGH- ENABLED (DEFAULT) LOW - DISABLED U19F U19F LPT_PCH_M_EDS LPT_PCH_M_EDS 3.3VS...

  • Page 90: Lynix Point 7/9

    Schematic Diagrams Lynix Point 7/9 Lynx Point (POWER) R829 R829 *15mil_short_06 *15mil_short_06 U19G U19G LPT_PCH_M_EDS LPT_PCH_M_EDS 1.05VS 1.312A VCCADAC1_5 AA24 CRT DAC CRT DAC AA26 Sheet 25 of 66 AD20 V3.3S_ADACBG R810 R810 *15mil_short_06 *15mil_short_06 Thermal Sensor VCCADACBG3_3 C500 C500 C509 C509 C510...

  • Page 91: Lynix Point 8/9

    Schematic Diagrams Lynix Point 8/9 Lynx Point (POWER) VDD3 P150SM-A_D01_Alex VDD3 HCB1608KF-121T25 HCB1608KF-121T25 D01a_1011_Alex 1.05VS LPT_PCH_M_EDS LPT_PCH_M_EDS U19H U19H R749 R749 0_04 0_04 C940 C940 C770 C770 0.1u_10V_X5R_04 0.1u_10V_X5R_04 VCCSUS3_3 VCCSUS3_3 C769 C769 C513 C513 0.1u_10V_X5R_04 0.1u_10V_X5R_04 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 0.1u_10V_X5R_04 0.1u_10V_X5R_04 0.1u_10V_X5R_04...

  • Page 92: Lynix Point 9/9

    Schematic Diagrams Lynix Point 9/9 D01a_1011_Alex VDD3 U19J U19J LPT_PCH_M_EDS LPT_PCH_M_EDS Lynx Point (GND) AL34 AL38 PCIECLKRQ4# R663 R663 100K_04 100K_04 AM14 AM24 PCIECLKRQ5# R662 R662 10K_04 10K_04 AM26 AM28 AM30 AM32 AM16 MXM_CLKREQ# R648 R648 *10K_04 *10K_04 AN36 AN40 AN42 LPT_PCH_M_EDS LPT_PCH_M_EDS...

  • Page 93: Usb+Esata, Usb Charging

    Schematic Diagrams USB+eSATA, USB Charging USBVCC3.0_3 SLG55583 USB Charging PORT 100 mil FLG# VOUT1 C360 C360 C359 C359 VIN1 VOUT2 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 VIN2 VOUT3 R100 R100 *10mil_short_04 *10mil_short_04 29,38,39,41 DD_ON# AP2301M8G-13 AP2301M8G-13 C326 C326 2A/90mohm R100 change to short 10u_10V_Y5V_08 10u_10V_Y5V_08 M-MSOP8...

  • Page 94: Usb 2.0, Ccd, Mini Pcie, Lid

    Schematic Diagrams USB 2.0, CCD, Mini PCIE, LID Change 5V_CCD to 3.3VS_CCD ,1/27 Stanley Change 5V to 3.3VS ,1/24 Stanley USB2.0 PORT 3.3VS 3.3VS_CCD 48 mil VOUT USBVCC01 C158 C158 Del R114 & USB_OC#89 C125 C125 C124 C124 100 MIL 1u_6.3V_X5R_04 1u_6.3V_X5R_04 CCD_EN...

  • Page 95: Led, Hotkey, Lid Sw, Fan

    Schematic Diagrams LED, Hotkey, LID SW, Fan CPU FAN CONTROL VGA FAN CONTROL BAT LED FON1# FON# VOUT C516 C516 C504 C504 VSET VOUT 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 AX995SA AX995SA C289 C289 C294 C294 VSET 4.7u_6.3V_X5R_06 4.7u_6.3V_X5R_06 CPU_FAN CPU_FAN 34 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 AX995SA AX995SA 4.7u_6.3V_X5R_06...
  • Page 96 Schematic Diagrams RJ 45 D05A RN2, RN5 0_8P4R_04 Del LP8, LP9 GIGA LAN 0_8P4R_04 0_8P4R_04 J_RJ1 J_RJ1 LAN_MDIN0 LMX1- DLMX1- DLMX1+ GND1 LAN_MDIN0 TD4- MX4- shield LAN_MDIP0 LMX1+ DLMX1+ DLMX1- GND2 LAN_MDIP0 TD4+ MX4+ shield LAN_MDIN1 LMX2- DLMX2- DLMX2+ LAN_MDIN1 TD3- MX3- LAN_MDIP1...

  • Page 97: Codec Realtek Alc892

    Schematic Diagrams Codec Realtek ALC892 3.3V 3.3V 2,14,19,29,30,36,37,39,41,42 Layout Note: 3.3VS 3,5,9,10,11,12,13,14,15,16,17,18,19,20,21,22,24,25,26,27,28,29,30,33,34,35,36,37,41,44,46,61 13,28,29,38,39,41,42 U43 pin 1 ~ pin 11 and pin 47 and pin 48 C332 C332 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 14,33,44 are Digital signals. R668 R668 C389 C389 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 The others are Analog signals. *100K_04 *100K_04 HCB1005KF-121T20...

  • Page 98: Apa2607-Tpa2008D2

    Schematic Diagrams APA2607-TPA2008D2 AMP_5VS TPA2008D2 The volume control.the gain range is from HCB1608KF-121T25 HCB1608KF-121T25 AUDIO AMP 3.3VS -80db(Vvolume=5V) to +20db(Vvolume=0V) with P2P BA20550 C355 C355 C319 C319 C320 C320 64 steps precise control. (TSSOP24) R236 R236 C331 C331 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 22u_6.3V_X5R_08...

  • Page 99: Kbc-Ite It8587A

    KB-SI4 KB-SI6 KB-SI6 P177SM-A 3.3V PCLK_KBC LPCCLK KSI4 KB-SI5 KB-SI7 KB-SI7 20,30,46 LPC_FRAME# LFRAME# KSI5 K/B MATRIX K/B MATRIX KB-SI6 P170SM-A 6.49K smart 20,30,46 SERIRQ SERIRQ KSI6 charger KB-SI7 KB-SO0 KB-SO0 16,22,29,30,37 BUF_PLT_RST# LPCRST#/WUI4/GPD2( PU ) KSI7 KB-SO1 KB-SO1 P151SM-A 11.8K...

  • Page 100: Backlight Keyboard

    Schematic Diagrams Backlight Keyboard DEFAULT PJ11 SHORT KB_LEDPWR_IN BCIHP0420TB-2R2M BCIHP0420TB-2R2M KB_LEDPWR_SW KB_LED_PWR PJ11 PJ11 OPEN_2A OPEN_2A FMS3004-AS-H FMS3004-AS-H C374 C374 R588 R588 D05A KB_LEDPWR_IN 0_04 0_04 Del R588 KB_LEDPWR_FREQ 12/06 value Gary J_KBLED2 J_KBLED2 FREQ R538 R538 *10mil_short *10mil_short R551 R551 KB_LED_PWR_FB KB_LED_PWR...

  • Page 101: Msata, Fan, Tp, Fp, Multi-Con

    Schematic Diagrams mSATA, FAN, TP, FP, MULTI-CON FOR CLICK BOARD P17&P15 FOR HDD&ODD BOARD P17&P15 J_SATA_HODD1 J_SATA_HODD1 D02A Change SATA4 to SATA3 J_TP1 J_TP1 R633 R633 R634 R634 C749 C749 SATA_TXP3 19 10K_04 10K_04 10K_04 10K_04 *10U_10V_08 *10U_10V_08 SATA_TXN3 19 SATA_ODD_PRSNT# TP_CLK TP_CLK...

  • Page 102: Card Reader Rtl8411

    Schematic Diagrams Card Reader RTL8411 Switching Regulator close to PIN48 LAN (RTL8411) R457 R457 0_06 0_06 VDD10 (>20mil) PULL HIGH: SWR Mode VDD3 RSET R293 R293 2.49K_1%_04 2.49K_1%_04 REGOUT VDD10 ENSWREG R464 R464 *0_04 *0_04 Crystal 8045 & 3225 Co-lay meet realtek Freq tolerance 50ppm (>20mil) SHORT...

  • Page 103: Usb 3.0

    Schematic Diagrams USB 3.0 USB3.0 PORT2 DEL L82 C237 C237 220u_6.3V_6.3*6.3*4.2 220u_6.3V_6.3*6.3*4.2 USBVCC3.0_2 J_USB3_2 J_USB3_2 CLOSE TO CONNECTOR Z2804 GND1 C268 C268 0.1u_10V_X7R_04 0.1u_10V_X7R_04 USB3_TXP2 SSTX+ SHIELD VBUS C266 C266 0.1u_10V_X7R_04 0.1u_10V_X7R_04 Z2805 USB3_TXN2 SSTX- USB_PN1 USB_PP1 USB3_RXP2 SSRX+ GND_D GND2 USB3_RXN2 *WCM2012F2S-161T03...

  • Page 104: Ddr 1.35V/0.75Vs Pch 1.5V

    Schematic Diagrams DDR 1.35V/0.75VS PCH 1.5V VDDQ PQ10 PQ10 1.35V/0.75VS MDU1516 MDU1516 PC119 PC119 PC118 PC118 PC42 PC42 PC54 PC54 ULTRASO-8 ULTRASO-8 PC128 PC128 PC127 PC127 RB0540S2 RB0540S2 uP6163 uP6163 PC48 PC48 VDDQ_R 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 VTT_MEM 10u_10V_Y5V_08 10u_10V_Y5V_08 1.35V PC82 PC82...

  • Page 105: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR116 PR116 *0_04 *0_04 PR115 PR115 0_04 0_04 PC98 PC98 1u_10V_Y5V_06 1u_10V_Y5V_06 PR118 PR118 PR114 PR114 EN_3V EN_5V PC93 PC93 120K_1%_04 120K_1%_04 124K_1%_04 124K_1%_04 PC95 PC95 1000p_50V_X7R_04 1000p_50V_X7R_04 1000p_50V_X7R_04 1000p_50V_X7R_04 DEL P1756,PC176.ADD 5.6u_25V_B2 cap for noise D01A VREG3 2/28 Stanley...

  • Page 106: 5V, 5Vs, 3.3V, 3.3Vs, 1.5Vs

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS, 1.5VS P150EM/P151EM1 only VIN1 R458 R458 *100K_04 *100K_04 DD_ON POWER SWITCH LED 3.3VS R474 R474 100K_04 100K_04 VIN1 DD_ON_LATCH 34 3.3VS P150SM-A_D01_Alex R483 R483 *100K_04 *100K_04 220_04 for P151EM1 DD_ON_LATCH USB_CHARGE_EN 28,34,40 C428 C428 C570 C570 C427...

  • Page 107: Power 1.05Vs

    Schematic Diagrams Power 1.05VS For CV test PC183,PC194 3/6 Stanley PJ22 PJ22 *CV-40mil *CV-40mil PR99 820K_1%_06 PR99 820K_1%_06 1.05V_LAN_M PR56 PR56 100K_04 100K_04 Z3501 Short PJ24 PJ24 *OPEN-1mm *OPEN-1mm PC111 PC111 PC183 PC183 PC194 PC194 PC113 PC113 1.05V_LAN_M_EN 1.05V_LAN_M_EN 21,41 PM_SLP_LAN# PJ33 PJ33...

  • Page 108: Led 5V

    Schematic Diagrams LED 5V Sheet 43 of 66 LED 5V D04_Reflash_0905_Alex 13,28,29,32,38,39,41,42 13,14,39,40,41,42,44,45 ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ ! ! ! !!DMFWP!DP/ Title Title Title [43] P375SM LED 5V [43] P375SM LED 5V [43] P375SM LED 5V Size Size Size...

  • Page 109: [43] Power V-Core1

    Schematic Diagrams Power V-Core 1 3.3VS PR163 PR163 *20mil_04 *20mil_04 0513 POWER PR128 PR128 APGND 0513 POWER TSENSE TH05-4F104FR TH05-4F104FR PR384 PR384 SWN3 CSREF 100K_04 100K_04 162K_1%_06 162K_1%_06 PUT COLSE PC313 PC313 PR364 PR364 *20K_04 *20K_04 TO VCORE PJ25 PJ25 PR360 PR360 PR385...

  • Page 110: Ac_In, Charger

    Schematic Diagrams AC_In, Charger PQ72 PQ72 D02A modify ME4425 ME4425 PQ7, PQ49, PQ72 value PQ38 PQ38 D02A modify ME4425 ME4425 PQ37, PQ38 value PC289 PC289 PC288 PC288 PC290 PC290 PC291 PC291 PR316 PR316 0_04 0_04 PR317 PR317 *470K_04 *470K_04 P150SM-A_D01_Alex PQ49 PQ49 PQ37...

  • Page 111: Tpm

    Schematic Diagrams SLB9635TT & SLB9655TT Co-Layout 12/06 DVT Gary SLB9635,SLB9655 3.3VS 12/06 DVT Gary LPC_AD0 R315 R315 *0_04 *0_04 20,30,34 LPC_AD0 LAD0 VDD1 LPC_AD1 20,30,34 LPC_AD1 LAD1 VDD2 LPC_AD2 C181 C181 C171 C171 C205 C205 C213 C213 20,30,34 LPC_AD2 LAD2 VDD3 LPC_AD3 20,30,34...

  • Page 112: Audio Board

    Schematic Diagrams Audio Board USB PORT A_USBVCC A_USBVCC A_USBVCC2 HCB1608KF-121T25 HCB1608KF-121T25 60 mil 50 mil *0_04 *0_04 AC11 AC11 *0_04 *0_04 AC17 AC17 AC15 AC15 AC14 AC14 100u_6.3V_B_A 100u_6.3V_B_A 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10u_10V_Y5V_08 10u_10V_Y5V_08 AJ_USB1 AJ_USB1 ISSUE AGND AUSB_PN0_R DATA_L...

  • Page 113: P150 Odd Board

    Schematic Diagrams P150 ODD Board O_5VS OJ_SATA_HODD1 OJ_SATA_HODD1 OSATA_TXP0 OSATA_TXN0 EODD_EDTECT# EODD_DA# OSATA_RXN0 OSATA_RXP0 OJ_ODD1 OJ_ODD1 0.01u_16V_X7R_04 0.01u_16V_X7R_04 OSATA_TXP0 C1952 C1952 OSATA_TXN0 0.01u_16V_X7R_04 0.01u_16V_X7R_04 0.01u_16V_X7R_04 0.01u_16V_X7R_04 OSATA_RXN0 OGND OGND 0.01u_16V_X7R_04 0.01u_16V_X7R_04 OSATA_RXP0 Sheet 48 of 66 OGND EODD_EDTECT# O_5VS P150 ODD Board O_5VS EODD_DA# FP->AT13035BAA089...

  • Page 114: P150 Click Board

    Schematic Diagrams P150 Click Board CSW1~2 T3.3V T+5VS TC17 TC17 RIGHT LIFT T+5VS 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 FCM1005KF-121T03 FCM1005KF-121T03 TJ_TPB1 TJ_TPB1 TSW 1 TSW 1 TSW 2 TSW 2 TGND T4BJB16-Q T4BJB16-Q T4BJB16-Q T4BJB16-Q TJ_TP1 TJ_TP1 TGTP_CLK TGTP_DATA TTPBUTTON_R TTPBUTTON_L TGTP_CLK TGTP_DATA TTPBUTTON_L TR24 TR24...

  • Page 115: Power Led Board

    Schematic Diagrams Power LED Board P150SM/P170SM LLED_ACIN LLED_PWR LLED_BAT_CHG LLED_BAT_FULL LJ_LED1 LJ_LED1 LED_GND 220_04 220_04 220_04 220_04 220_04 220_04 220_04 220_04 LLED_ACIN Gary D03 Update( exchange) Gary D03 Update( exchange) LLED_PWR LLED_BAT_CHG LLED_BAT_FULL Sheet 50 of 66 85204-05001 85204-05001 RY-SP155UHYUYG4 RY-SP155UHYUYG4 RY-SP155UHYUYG4 RY-SP155UHYUYG4...

  • Page 116: Function Led Board

    Schematic Diagrams Function LED Board L2_3.3VS L2J_LED1 L2J_LED1 L2SATA_LED# L2WLAN_AIRPLANE# ADD LED for AIRPLANE LED/dGPU L2dGPU_PWR_EN# 85201-06051 85201-06051 L2GND L2_3.3VS L2_3.3VS L2R2 L2R2 L2_3.3VS Sheet 51 of 66 HDD/CD-ROM 220_04 220_04 L2R3 L2R3 Function LED 220_04 220_04 Board L2D2 L2D2 RY-SP172DNB74-5A RY-SP172DNB74-5A L2D1...

  • Page 117: Indicatory Led Board

    Schematic Diagrams Indicatory LED Board L3_3.3VS L3_3.3VS L3_3.3VS L3_3.3VS L3J_LED1 L3J_LED1 L3LED_NUM# D02A_1219_Alex D02A_1219_Alex D02A_1219_Alex L3LED_CAP# L3LED_SCROLL# L3R3 L3R3 L3R2 L3R2 L3R1 L3R1 220_1%_04 220_1%_04 220_1%_04 220_1%_04 220_1%_04 220_1%_04 85201-06051 85201-06051 SCROLL CAPS LOCK NUM LOCK LOCK L3D3 L3D3 L3D2 L3D2 L3D1 L3D1...

  • Page 118: P170 2Nd Hdd Board

    Schematic Diagrams P170 2nd HDD Board HJ_ODD1 HJ_ODD1 H_5VS HJ_SATA_HODD1 HJ_SATA_HODD1 HC16 HC16 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_TXP0 HC15 HC15 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_TXN0 HSATA_TXP0 HSATA_TXN0 HC14 HC14 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_RXN0 H_EODD_EDTECT# HC13 HC13 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_RXP0 H_EODD_DA# HSATA_RXN0 HSATA_RXP0 H_5VS HSATA_TXP1 HSATA_TXN1 HGND H_3.3VS H_EODD_EDTECT#...

  • Page 119: Power & Led Board

    Schematic Diagrams Power & LED Board L4_3.3VS L4_VDD3 L4_3.3VS L4_3.3VS L4_3.3VS L4J_LED1 L4J_LED1 L4R2 L4R2 100K_04 100K_04 L4_WLAN_AIRPLANE# L4R5 L4R5 L4R6 L4R6 L4R7 L4R7 L4_SATA_LED# L4_U2 L4_U2 L4_LID_SW# 220_04 220_04 220_04 220_04 220_04 220_04 L4_dGPU_PWR_EN# L4_LED_NUM# L4_C1 L4_C1 L4_LED_CAP# L4C2 L4C2 L4_LED_SCROLL# PT3661G-BB...

  • Page 120: P170 Click Board

    Schematic Diagrams P170 Click Board C3.3V C+5VS CC17 CC17 RIGHT LIFT C+5VS 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 FCM1005KF-121T03 FCM1005KF-121T03 CJ_TPB1 CJ_TPB1 CSW 2 CSW 2 CSW 1 CSW 1 CGND T4BJB16-Q T4BJB16-Q T4BJB16-Q T4BJB16-Q CJ_TP1 CJ_TP1 CGTP_CLK CGTP_DATA CTPBUTTON_R CTPBUTTON_L CGTP_CLK CGTP_DATA CC16 CC16 CTPBUTTON_L CR24...

  • Page 121: P150 Fingerprint Board

    Schematic Diagrams P150 Fingerprint Board P150 ONLY FPJT2 FPJT2 F_DISCON F_2.5V F_LED1 FXOUT F_LED2 FXIN F_MISO F_MOSI F_MCK F_MCS FRST_N F_USB_PN10 F_USB_PP10 F_3.3V SPNZ-24S1-B-017-1-R SPNZ-24S1-B-017-1-R SPNZ-24S1-X-C-Z SPNZ-24S1-X-C-Z 6-21-41700-212 6-21-41700-212 F_GND F_GND NOTE: MODE Sheet 56 of 66 MODE=HIGH (NC) , USB MODE MODE=LOW , SPI MODE EGND...

  • Page 122: P170 Fingerprint Board

    Schematic Diagrams P170 Fingerprint Board FPJT1 FPJT1 P170 ONLY FDISCON F2.5V FLED1 FLED2 FMISO FMOSI FMCLK FMCS F_RST_N FUSB_PN1 F_XIN F3.3V F3.3V FUSB_PP1 1M_04 1M_04 F_XOUT SPNZ-24S2-VB-017-1-R SPNZ-24S2-VB-017-1-R FGND FGND FGND 6-21-41710-212 FGND HSX321G_12Mhz HSX321G_12Mhz FC11 FC11 NOTE: MODE 15p_50V_NPO_04 15p_50V_NPO_04 15p_50V_NPO_04 15p_50V_NPO_04...

  • Page 123: P150 2Nd Hdd Board

    Schematic Diagrams P150 2nd HDD Board DJ_ODD1 DJ_ODD1 DSATA_TXP0 DSATA_TXN0 DSATA_RXN0 DSATA_RXP0 DGND D_5VS Sheet 58 of 66 DJ_HDD1 DJ_HDD1 242003-1 242003-1 P150 2nd HDD DSATA_TXP0 DSATA_TXN0 DGND ISSUE GND1~3=QGND Board DSATA_RXN0 *0_04 *0_04 DSATA_RXP0 *0_04 *0_04 *0_04 *0_04 D_5VS .1u_16V_Y5V_04 .1u_16V_Y5V_04 .1u_16V_Y5V_04...

  • Page 124: Indicatory Led Board

    Schematic Diagrams Indicatory LED Board LBL_3.3VS LBL_3.3VS LBL_3.3VS LBL_3.3VS LBLJ_LED1 LBLJ_LED1 LBL_LED_NUM# LBL_LED_CAP# LBL_LED_SCROLL# LBL_R1 LBL_R1 LBL_R2 LBL_R2 LBL_R3 LBL_R3 220_1%_04 220_1%_04 220_1%_04 220_1%_04 220_1%_04 220_1%_04 Gary 10/18 220_04 Gary 10/18 220_04 Gary 10/18 220_04 FP215H-006S1AM FP215H-006S1AM SCROLL CAPS LOCK NUM LOCK LOCK LBL_D1...

  • Page 125: Function Led Board

    Schematic Diagrams Function LED Board LBR_3.3VS LBRJ_LED1 LBRJ_LED1 LBR_SATA_LED# LBR_WLAN_AIRPLANE# ADD LED for AIRPLANE LED/dGPU LBR_3.3VS LBR_dGPU_PWR_EN# FP215H-006S1AM FP215H-006S1AM LBR_3.3VS LBRGND D02_1119_Alex LBR_3.3VS 220_04 220_04 Sheet 60 of 66 HDD/CD-ROM LBR_R1 LBR_R1 Function LED 220_1%_04 220_1%_04 Board Gary 10/18 220_04 LBR_D3 LBR_D3 LBR_D1...

  • Page 126: Mini-Dp

    Schematic Diagrams Mini-DP D04_Reflash_0925_Alex 3.3VS MTN2306AN3 MTN2306AN3 DPSNK0_3_P_R C946 C946 0.1u_10V_X7R_04 0.1u_10V_X7R_04 DP_TDB3 5 R344 R344 R391 R391 DPSNK0_3_N_R C947 C947 0.1u_10V_X7R_04 0.1u_10V_X7R_04 DP_TDB#3 5 DPSNK0_2_P_R C948 C948 0.1u_10V_X7R_04 0.1u_10V_X7R_04 DP_TDB2 5 DPSNK0_2_N_R C949 C949 0.1u_10V_X7R_04 0.1u_10V_X7R_04 DP_TDB#2 5 DPSNK0_1_P_R C951 C951 0.1u_10V_X7R_04...

  • Page 127: 2Nd Msata Board

    Schematic Diagrams 2nd mSATA Board mSATA M_mSATA_3.3V M_mSATA_3.3V MJ_MSATA3 MJ_MSATA3 MC273 MC273 1u_6.3V_X5R_04 1u_6.3V_X5R_04 MC274 MC274 0.1u_16V_04 0.1u_16V_04 D04_Reflash_0926_Alex MJ_mSATA2 MJ_mSATA2 40 mil *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 WAKE# 3.3VAUX_0 M_mSATA_3.3V MGND COEX1 1.5V_0 COEX2 UIM_PWR MGND UIM_DATA CLKREQ# UIM_CLK mSATA_TXP4_M 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 REFCLK- UIM_RESET mSATA_TXN4_M...

  • Page 128: Power On / S4 Resume Seq

    Schematic Diagrams Power on / S4 Resume Seq. PWR_SW# 636ms PWR_SW# 140.8ms DD_ON DD_ON 3.3V 1.768ms 3.3V 2.44ms RSMRST# RSMRST# PWR_BTN# 176ms 124ms PWR_BTN# SUSC# 190ms SUSC# VDDQ 6.72ms VDDQ V_VCCDDQ 6.72ms V_VCCDDQ SUSB# 34us SUSB# 640us 3.3VS 1.12ms 3.3VS 1.5VS 1.66ms 1.5VS...

  • Page 129: S3 Resume Seq

    Schematic Diagrams S3 Resume Seq. SUSB# SUSB# 660us 3.3VS 1.4ms 3.3VS 1.5VS 1.5VS 1.68ms Sheet 64 of 66 1.05V_LAN_M 1.176ms 1.05V_LAN_M 1.05VM 1.2ms 1.05VM S3 Resume Seq. 1.232ms 1.05VS 1.05VS VTT_MEM VTT_MEM 280us ALL_SYS_PWRGD ALL_SYS_PWRGD 1.144ms 8.56ms PM_PCH_PWROK PM_PCH_PWROK PMSYS_PWRGD_BUF PMSYS_PWRGD_BUF 62.4ms H_CPUPWRGD...

  • Page 130: Into S3 Sequence

    Schematic Diagrams Into S3 Sequence PWR_SW# PWR_SW# DD_ON DD_ON 3.3V 3.3V RSMRST# RSMRST# PWR_BTN# PWR_BTN# SUSC# SUSC# VDDQ VDDQ V_VCCDDQ V_VCCDDQ SUSB# SUSB# 340ms 4.56ms 3.3VS 3.3VS 53.2ms 1.5VS 1.5VS 14.6ms 1.05V_LAN_M Sheet 65 of 66 1.05V_LAN_M 12.6ms 1.05VM 1.05VM Into S3 Sequence 16.2ms 1.05VS...

  • Page 131: Into S4 Sequence

    Schematic Diagrams Into S4 Sequence PWR_SW# PWR_SW# DD_ON DD_ON 3.3V 3.3V 44.8Mms 14.4ms RSMRST# RSMRST# PWR_BTN# PWR_BTN# 376ms SUSC# SUSC# VDDQ 1.12ms VDDQ V_VCCDDQ 1.12ms V_VCCDDQ 96us SUSB# SUSB# 324ms 3.3VS 3.3VS 332ms 1.5VS 1.5VS 248ms 1.05V_LAN_M 17.8ms 1.05V_LAN_M 14ms Sheet 66 of 66 1.05VM 1.05VM...
  • Page 132 Schematic Diagrams B - 68...

  • Page 133: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...
  • Page 134 BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.

Table of Contents
