To change Track 1 output to be a mix-minus feed for New York
Hold down the Track 1 switch above the routing screen.
The ACCESS lights above the Paris faders illuminate to show that these channels are
currently subtracted from this mix. The same information will be shown on the routing screen
if you are using the reverse routing display.
While holding down the Track 1switch, cancel the Paris subtraction by pressing the ACCESS
buttons on channels 13 and 14 so the LEDs go out and subtract New York instead, by
pressing the Access button on channels 17 and 18.
It is not necessary to do any patching or re-porting of the hybrids attached to tracks 1 and 6.
To check which channels have been cancelled from a mix-minus output at any time, press
the appropriate mix-minus output (track) switch above the routing screen and the access
lights above the faders subtracted will illuminate and subtracted paths on the reverse routing
screen will turn blue.
Meters above each mix-minus output button show the output level.
To monitor each mix-minus output
Press the large TB/AFL switch at the top left of the routing screen so that it's LED is red. This
puts the small TB/AFL switches into AFL mode.
Press the TB/AFL switch above the mix minus switch to route the output to the monitoring
system via AFL.
To adjust the level of mix-minus outputs
Press the MIX-/TRACK button at the top of the AFU fader strip to assign output trim controls
to the top row of Logicators across the console.
If the monitor faders for the mix-minus tracks are positioned in the track send part of the
monitor path (see Configuring Libra Live) and the monitor paths have been assigned to
faders (on another layer perhaps), then the levels can be set using faders instead of
Logicators.
Mix Minus and Talkback
This description assumes that the talkback microphone has been connected to a console input
and that the talkback path has been ported to the talkback microphone's ADC.
To check that the talkback mic is connected and ported correctly
Hold down the SELECT key next to the SLATE key in the talkback panel and press the AFU
fader's ACCESS key so that the AFU fader scribble displays TBK. This calls the talkback path
to the AFU. Check in the I/O section of the AFU that the correct input is selected and turned
on. The signal present indicator next to the AFU fader should respond to talkback audio.
To route talkback to all mix-minus outputs simultaneously
Press the SLATE key on the talkback panel.
