TAPE AND REEL INFORMATION

REEL DIMENSIONS
Reel Diameter
NOTE: The picture is only for reference. Please make the object as the standard.
KEY PARAMETER LIST OF TAPE AND REEL
Package Type
TSSOP-38
TQFN-5×5-32L
SG Micro Corp
www.sg-micro.com
W
Reel Width (W1)
Reel Width
Reel
W1
Diameter
(mm)
13" 16.4
13" 12.4
TAPE DIMENSIONS
P2
Q2
Q1
Q3
Q4
P1
DIRECTION OF FEED
A0 B0 K0
(mm) (mm) (mm)
6.80 10.20 1.60
5.30 5.30 1.10
PACKAGE INFORMATION
P0
Q2
Q1 Q1
Q3 Q3
Q4
A0
P0 P1 P2
(mm) (mm) (mm)
4.0 8.0 2.0
4.0 8.0 2.0
Q2
B0
Q4
K0
W Pin1
(mm) Quadrant
16.0 Q1
12.0 Q2
TX10000.000
