PACKAGE OUTLINE DIMENSIONS
TQFN-5×5-32L
A
Symbol
SG Micro Corp
www.sg-micro.com
D
E
TOP VIEW
A1
A2
SIDE VIEW
Dimensions
In Millimeters
MIN
A 0.700
A1 0.000
A2 0.203 REF
D 4.924
D1 3.300
E 4.924
E1 3.300
k 0.200 MIN
b 0.180
e 0.500 TYP
L 0.324
PACKAGE INFORMATION
e
N17
L
D1
k
b
BOTTOM VIEW
3.4
0.7
0.24
RECOMMENDED LAND PATTERN (Unit: mm)
Dimensions
In Inches
MAX MIN
0.800 0.028
0.050 0.000
0.008 REF
5.076 0.194
3.500 0.130
5.076 0.194
3.500 0.130
0.008 MIN
0.300 0.007
0.020 TYP
0.476 0.013
E1
N32
N1
3.4 4.1 5.5
0.5
MAX
0.031
0.002
0.200
0.138
0.200
0.138
0.012
0.019
TX00089.000
