SGM5200
PACKAGE/ORDERING INFORMATION
PACKAGE
MODEL
DESCRIPTION
TSSOP-38
SGM5200
TQFN-5×5-32L
MARKING INFORMATION
NOTE: XXXXX = Date Code, Trace Code and Vendor Code.
X X X X X
Vendor Code
Trace Code
Date Code - Year
Green (RoHS & HSF): SG Micro Corp defines "Green" to mean Pb-Free (RoHS compatible) and free of halogen substances. If
you have additional comments or questions, please contact your SGMICRO representative directly.
ABSOLUTE MAXIMUM RATINGS
AINP or CHx to AGND .............................. -0.3V to V
+VA to AGND, +VBD to BDGND ......................... -0.3V to 6V
Digital Input Voltage to BDGND ........................... -0.3V to 6V
Digital Output to BDGND .......................... -0.3V to V
Input Current to Any Pin except Supply Pins..... -10mA to 10mA
Junction Temperature ................................................. +150℃
Storage Temperature Range ....................... -65℃ to +150℃
Lead Temperature (Soldering, 10s) ............................ +260℃
ESD Susceptibility
HBM ............................................................................. 4000V
CDM ............................................................................ 1000V
RECOMMENDED OPERATING CONDITIONS
Analog Power Supply Voltage Range ............... 2.7V to 5.25V
Digital I/O Power Supply Voltage Range ............... 1.7V to V
Reference Voltage Range......................................... 2V to 3V
SCLK Frequency ........................................................ 20MHz
Operating Temperature Range .................... -40℃ to +125℃
SG Micro Corp
www.sg-micro.com
SPECIFIED
TEMPERATURE
RANGE
SGM5200XTS38G/TR
-40℃ to +125℃
-40℃ to +125℃ SGM5200XTQL32G/TR
+ 0.3V
A
+ 0.3V
A
12-Bit, 1MSPS, 16 Channels,
Single-Ended, Serial Interface ADC
ORDERING
NUMBER
OVERSTRESS CAUTION
Stresses beyond those listed in Absolute Maximum Ratings
may cause permanent damage to the device. Exposure to
absolute maximum rating conditions for extended periods
may affect reliability. Functional operation of the device at any
conditions beyond those indicated in the Recommended
Operating Conditions section is not implied.
ESD SENSITIVITY CAUTION
This integrated circuit can be damaged if ESD protections are
not considered carefully. SGMICRO recommends that all
integrated circuits be handled with appropriate precautions.
Failure to observe proper handling and installation procedures
can cause damage. ESD damage can range from subtle
performance degradation to complete device failure. Precision
integrated circuits may be more susceptible to damage
because even small parametric changes could cause the
A
device not to meet the published specifications.
DISCLAIMER
SG Micro Corp reserves the right to make any change in
circuit design, or specifications without prior notice.
PACKAGE
MARKING
SGM5200
XTS38 Tape and Reel, 4000
XXXXX
SGM5200
XTQL32 Tape and Reel, 3000
XXXXX
PACKING
OPTION
