PACKAGE OUTLINE DIMENSIONS

TSSOP-38
E1 E
A1
A2
Symbol
NOTES:
1. Body dimensions do not include mode flash or protrusion.
2. This drawing is subject to change without notice.
SG Micro Corp
www.sg-micro.com
D
b e
Dimensions
In Millimeters
MIN
A
A1 0.050
A2 0.800
b 0.170
c 0.090
D 9.600
E 4.300
E1 6.250
e 0.500 BSC
H 0.250 TYP
L 0.450
θ
1°

PACKAGE INFORMATION

1.78
0.30
RECOMMENDED LAND PATTERN (Unit: mm)
A
θ
H
MAX MIN
1.200
0.150 0.002
1.000 0.031
0.270 0.007
0.200 0.004
9.800 0.378
4.500 0.169
6.550 0.246
0.750 0.018
7° 1°
0.50
L
Dimensions
In Inches
MAX
0.047
0.006
0.039
0.011
0.008
0.386
0.177
0.258
0.020 BSC
0.010 TYP
0.030
7°
5.94
c
TX00183.001
