- Page 1 STAR-LIGHT Camera Camera DWC-LPR650U – gray housing DWC-LPR650UW – white housing User’s Manual 10/22...
- Page 2 Safety Information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage This exclamation point symbol is intended to alert the consisting a risk of electric shock is present within user to the presence of important operating and...
- Page 3 Safety Information 11. Do not install near any heat sources such as radiators, heat registers, or other products (including amplifiers) that produce heat. 12. Keep out of direct sunlight and heat radiation sources. It may cause a fire. 13. If any unusual smells or smoke come from the unit, stop using the product at once. Immediately disconnect the power source and contact the service center.
- Page 4 Contents Important Safety Instructions 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the product. 11. If any laser equipment is used near the product, make sure the surface of the sensor is not exposed to the laser beam as that may damage the sensor module.
- Page 5 Important Safety Instructions Liability Every care has been taken in the preparation of this document. Digital Watchdog cannot be held responsible for any technical or typographical errors and reserves the right to make changes to the product and manuals without notice.
- Page 6 Disposal and recycling Digital Watchdog cares for the environment at all product manufacturing stages and is taking measures to provide customers with more environmentally friendly products. When this product has reached the end of its useful life, dispose of it according to local laws and regulations. For information about your nearest designated collection point, contact your local authority responsible for waste disposal.
-
Page 7: Table Of Contents
Contents INTRODUCTION Features Product & Accessories Parts Name Dimension INSTALLATION Installa�on Connec�ng to Monitors Control Board Adjus�ng the Camera angle OSD MENU Menu Tree Exposure Color Day/Night Function Motion Privacy Setup Exit APPENDIX Troubleshoo�ng Specifications LIMITS AND EXCLUSIONS WARRANTY INFORMATION... -
Page 8: Features
Features Analog High Defini�on Universal over Coax Technology █ Universal LPR License Plate Recogni�on Technology captures reflec�ve license █ plates up to 50mph with a 13’~30’ Capture Range Reliable Performance under Any Ligh�ng Condi�ons █ External OSD and Lens Adjustment █... -
Page 9: Product & Accessories
Product & Accessories Please check if all the camera and accessories are included in the package. Camera Sunshield Cover & Star Wrench DC Plug Cable Adjus�ng Screws (T-20) Screws & Quick Setup & Mounting Template Plas�c Anchors - 4pcs Installation Guides... -
Page 10: Parts Name
Part name Sunshield Adjus�ng Screws Sunshield Cover Lens Pan/Tilt/Rotate Stopper screw Zoom Control Focus Control Cable Guide Rubber Moun�ng Bracket OSD Joys�ck EX-CON Con Cap Universal Cable Power Cable CVBS Cable DC12V UNIVERSAL CVBS AC24V... -
Page 11: Dimension
Dimension Unit: inches (mm) 10.39" (264mm) 3.62" (92mm) 3.7" (94mm) 5.15" (131mm) 8.85" (225mm) 4-ø0.16" (ø4.2mm) 3.81" (97mm) 3.07" (78mm) -
Page 12: Installa�On
Installa�on - Instruc�ons Using the mounting template or your own camera, mark and drill the necessary holes to mount the bracket to a wall or ceiling. Pull all necessary wires through and make the proper connections. Mount the camera to the mounting surface or mounting accessory using the screws and anchors included. - Page 13 Installa�on - Instruc�ons An LPR camera is designed to read a license plate only. When a license plate passes by the camera, the reflec�ve film on the plate will be reflected back to the camera which gives you the good clear shot of the plate. You will ONLY capture an image of the plate. US license plates need to be at least 216 pixels wide.
- Page 14 Installa�on - Instruc�ons CAMERA ANGLE NO GREATER THAN 20 DEGREES FOR SIDE MOUNT INSTALLATIONS THE CAMERA SHOULD BE MOUNTED AT AN ANGLE NO GREATER THAN 30 DEGREES...
-
Page 15: Connec�Ng To Monitors
Connec�ng to Monitors Use the diagram below to connect to an Universal DVR or CRT Monitor properly. CVBS 12VDC/24VAC UNIVERSAL (COAX) CCTV Monitor EX-CON - Power Connec�on - 12VDC/24VAC Dual Voltage (Auto Polarity Detec�on and Protec�on) - All cameras are equipped with a test video output for on-site configura�on. -
Page 16: Control Board
Control Board Zoom Control Focus Control CVBS(960H) HD-TVI HD-A EX-CON HD-CVI - OSD Joys�ck: The func�on se�ng and video output can be adjusted with OSD joys�ck. (default : HD-A) Image Mode Switches to HD-TVI mode when press OSD Joys�ck to le� 5sec or longer. Switches to HD-A mode when press OSD Joys�ck to right 5sec or longer. -
Page 17: Adjus�Ng The Camera Angle
Adjus�ng the Camera angle Pan 360˚ Rotate 360˚ Tilt 90˚ Warning: - Do not rotate more than 360 ˚ - Do not unnecessarily twist too many times. -
Page 18: Exposure
OSD Menu Tree NOTE : The function setting can be adjusted with both switch (OSD joystick) and remote control through RS485 or UTC. In case of camera without OSD joystick, it can be adjusted with coaxial (UTC) only. PRIVACY EXPOSURE LENS MANUAL / AUTO OFF / ON... - Page 19 OSD Menu Exposure LENS MANUAL : Manual mode supports the fixed board lens or the manual iris lens. AUTO : AUTO mode sets the camera’s iris automatically. EXPOSURE LENS LENS AUTO LEVEL BACKLIGHT BRIGHTNESS SHUTTER MANUAL DEFOG FOCUS ADJ RETURN 3D DNR HIGH EXIT JUMP...
- Page 20 OSD Menu Exposure BACKLIGHT HME HIGHLIGHT MASKING EXPOSURE HME allows objects to appear clearly on the screen by EXPOSURE masking extremely bright areas. To setup HME, set the level and color. The lower the setting, the darker the LENS AUTO BACKLIGHT masking areas have to be.
- Page 21 OSD Menu Exposure EXPOSURE DEFOG LENS AUTO MODE AUTO BACKLIGHT LEVEL ____ RETURN DEFOG 3D DNR EXIT JUMP DRC ( DYNAMIC RANGE COMPRESSOR ) DRC enables dark areas in images to become more visible without overexposing the bright areas to create one perfect image.
-
Page 22: Color
OSD Menu Color NOT USED COLOR EXIT JUMP This is a License Plate Recognition Camera. As such, it has been programmed specifically to register license plates only. For optimal results, this camera is set to B/W mode only. There is no Color mode on this camera. -
Page 23: Day/Night
OSD Menu Day & Night DAY/NIGHT SMART IR EXIT JUMP SMART IR 0 ~ 20 : Enable Smart IR and set the level. Higher values will make Smart IR stronger. -
Page 24: Function
OSD Menu Function FUNCTION SHARPNESS GAMMA 0.75 MIRROR FLIP EXIT JUMP SHARPNESS 0 ~ 10 - Sets the image sharpness. The higher the number, the sharper the image. GAMMA 0.45 ~ 0.75 - Select the desired gamma level. 0.75 is default setting. MIRROR / FLIP MIRROR : Reflects the camera horizontally. -
Page 25: Motion
OSD Menu Motion The camera can detect movement and display an alarm on the screen. when movement is detected. MOTION DET WINDOW MOTION WINDOW USE DET WINDOW WINDOW ZONE DET TONE DET H-POS DET V-POS MDRECT FILL DET H-SIZE SENSITIVITY DET V-SIZE MOTION OSD RETURN... -
Page 26: Privacy
OSD Menu Privacy You can hide some parts of the screen for privacy masking. A total of 16 different privacy masking zones are available. The cameras support square privacy masks or advanced polygon masks. PRIVACY PRIVACY ZONE NUM ZONE DISP H-POS V-POS H-SIZE... - Page 27 OSD Menu Setup COMMUNICA SETUP CAM ID BAUDRATE 9600 COMMUNICA SET DONE CAM TITLE RETURN IMAGE RANGE FULL FREQ 60Hz LANGUAGE INITIAL EXIT JUMP COMMUNICATION Adjust the camera’s ID and Baudrate. Default Protocol is Pelco-D. - CAM ID : Provide an ID number for the camera (0 ~ 255). - BAUDRATE : 9600bps is default.
-
Page 28: Setup
OSD Menu Setup SETUP COMMUNICA CAM TITLE IMAGE RANGE FULL FREQ 60Hz LANGUAGE INITIAL EXIT JUMP FREQ When the camera’s image appears to have flickering issues, change the frequency value to adjust the image. LANGUAGE Select from the following: English (Default), Chinese, Chinese (S), Japanese, and Koran. INITIAL Reset the camera to its default settings. -
Page 29: Exit
OSD Menu EXIT EXIT SAVE&EXIT EXIT SAVE & EXIT Exit the OSD menu after saving the recent changes. EXIT Exit the OSD menu without saving any changes. -
Page 30: Troubleshoo�Ng
Troubleshoo�ng Before sending your camera for repair, check the following or contact our technical specialist. FOR NO VIDEO Check the coaxial cable and make sure it is connected securely. Check the power supply and make sure the camera has the proper voltage and current. FOR OUT-OF-FOCUS VIDEO Check the Front case cover and the lens for dirt or fingerprints. - Page 31 Specifica�ons VIDEO Image Sensor 1/3” CMOS Sensors Ac�ve Pixels 1944(H) x 1092(V) Scanning System Progressive scan Freguency 60Hz / 50Hz Signal Technology 2.0 Megapixel Universal Synchroniza�on Internal Resolu�on 1920x1080 (1080p30fps) Minimum Scene Illumina�on F1.6 (30IRE): 0 Lux (B&W) S/N Ra�o 55dB Universal (Coax/UTP) HD-A/HD-TVI/HD-CVI/CVBS...
- Page 32 Specifica�ons OPERATIONAL (CONT.) Digital Noise Reduc�on OFF / LOW / MIDDLE / HIGH Day and Night NIGHT 0 ~ 10 Auto Gain Control Mo�on Detec�on ON/OFF (4 Zones) Privacy Zones ON/OFF (16 Zones) Sharpness 0 ~ 10 Gamma 0.45 ~ 0.75 Remote Control Coaxial (UTC) ENVIRONMENTAL...
-
Page 33: Limits And Exclusions
This warranty gives you specific legal rights, and you may also have other rights that vary from state-to-state. If the problem is not handled to your satisfaction, then write to the following address: Digital Watchdog, Inc. ATTN: RMA Department 5436 W. Crenshaw Street... -
Page 34: Warranty Information
Warranty Information Go to https://digital-watchdog.com/page/rma-landing-page/ to learn more about Digital Watchdog’s warranty and RMA. To obtain warranty or out of warranty service, please contact a technical support representative 1+ (866) 446-3595, Monday through Friday from 9:00 AM to 8:00 PM EST. A purchase receipt or other proof of the date of the original purchase is required before warranty service is rendered. - Page 35 DW® East Coast office and warehouse: 5436 W Crenshaw St, Tampa, FL USA 33634 DW® West Coast office and warehouse: 16220 Bloomfield Ave, Cerritos, CA USA 90703 PH: 866-446-3595 | FAX: 813-888-9262 www.Digital-Watchdog.com dw-tech@digital-watchdog.com Technical Support PH: USA & Canada 1+ 866-446-3595 International 1+ 813-888-9555 French Canadian: + 1-904-999-1309 Technical Support Hours: Monday-Friday 9 a.m.
