1.1 General

Orthopantomograph
diagnostic panoramic dental x-ray equipment for producing
high quality images of dentition and TM-joints. Orthoceph
OC200 model is a more equipped x-ray panoramic unit
with cephalometric exposure option.
This manual covers the installation of panoramic unit,
cephalostat and Ortho Trans options. For information
about how to use OP200 please refer to the appropriate
manuals.
Following manuals are shipped with the OP200:
OP200 Installation & Adjustments Manual
OP200 User Manual & Technical Specifications
OP200 Ortho Trans User Manual (only if Ortho Trans
option purchased with the OP200 unit)
These manuals and future updates are available on
request from Instrumentarium Dental.
In order to maintain safe and correct operation of the
OP200 unit, read and follow carefully instructions provided
in this manual during the unit installation process.
Use only approved cables and plugs.
Mains connector types:
– NEMA 6-15P or similar Hospital grade (US/230 V)
– NEMA 5-20P or similar Hospital grade (US/110 V)
– HBL8215C or similar Hospital grade (JAPAN)
Power supply cord:
– For UL-countries: S or SO, AWG 14x3
– H05VV-F3G 10-16A 250V (CE)
