Introduction
This user manual gives an overview of the use of STEVAL-IFS001V1 kit with MEMS (Micro-
Electro-Mechanical System) evaluation board.
As shown in the next section, this evaluation board consists of the DK3420 (uPSD
evaluation board) and the ST-MEMS-xx-EVAL (MEMS evaluation module). When connected
together as an evaluation kit, MEMS applications can be evaluated and measured through a
USB connection to a PC. A brief introduction to the MEMS software, MEMS USB Reader
7.x, is also provided.
MEMS can be used in a variety of vibration sensor and intelligent movement estimator
situations, for example:
■
Vibration analysis
– Motor control
– High buildings
■
Control of position
– Stability system for caravans
– Stability for cable cars
■
Sport
– Sport shoes
– Speedometers
■
Automotive
– Black box
– Intelligent driver sensors
– Car alarms
■
Navigation
– Dead-reckoning for GPS
■
Logistics
– Blackbox for containers (sensoring)
■
Robotics
– Control of robot arms (welding robots)
■
Security
– Vibration detection (broken window alarm)
April 2006
STEVAL-IFS001V1 evaluation kit with MEMS
Rev 1
UM0223
User manual
www.st.com
1/14
Advertisement
Table of Contents
Related Manuals for ST STEVAL-IFS001V1
Summary of Contents for ST STEVAL-IFS001V1
- Page 1 User manual STEVAL-IFS001V1 evaluation kit with MEMS Introduction This user manual gives an overview of the use of STEVAL-IFS001V1 kit with MEMS (Micro- Electro-Mechanical System) evaluation board. As shown in the next section, this evaluation board consists of the DK3420 (uPSD evaluation board) and the ST-MEMS-xx-EVAL (MEMS evaluation module).
-
Page 2: Table Of Contents
Contents STEVAL-IFS001V1 Contents Overview of MEMS evaluation boards ......3 Pin description ..........6 I2C and SPI use . -
Page 3: Overview Of Mems Evaluation Boards
STEVAL-IFS001V1 Overview of MEMS evaluation boards Overview of MEMS evaluation boards Figure 1. STEVAL-IFS001V1 This consists of DK3420 and ST-MEMS-XX-EVAL Figure 2. DK3420 - USB Demonstration board with µPSD Turbo Plus For a pin description, see Section 2. Further information is available in the uPSD34xx datasheet and online, from http://www.st.com... - Page 4 Overview of MEMS evaluation boards STEVAL-IFS001V1 Figure 3. ST-MEMS-DQ-EVAL The MEMS module ST-MEMS-DQ-EVAL is designed for the evaluation of a MEMS application which can be used in a variety of vibration sensor and intelligent movement estimator situations. For a pin description, see Section 2.
- Page 5 STEVAL-IFS001V1 Overview of MEMS evaluation boards Figure 4. ST-MEMS-AQ-EVAL (check for availability) Components include: ● LIS3L02AQ (QFN44) ● 3x analog outputs ● 3x buttons ● 3x LEDs 5/14...
-
Page 6: Pin Description
Pin description STEVAL-IFS001V1 Pin description Table 1. DK3420 - USB demonstration board with µPSD Turbo Plus and ST-MEMS- DQ-EVAL P1.5 P1.3 P1.1 RESET 3.3V Ain5 LED6 Ain3 Ain1 BUT5 P1.6 P1.7 P1.4 P1.2 P1.0 Ain6 Ain7 LED5 LED7 Ain4 Ain2... -
Page 7: I2C And Spi Use
STEVAL-IFS001V1 I2C and SPI use C and SPI use Figure 5. Board schematics for ST-MEMS-DQ-EVAL LIS3LV02DQ LIS3LV02DQ VUSB P4.7 P4.6 SDA_SDI P4.5 P4.4 SCL_SPC P4.3 P4.2 P4.1 P4.0 P3.0 P3.3 RSTn reserved RDYINT P3.2 P3.1 V3.3 P3.4 P3.5 reserved reserved... -
Page 8: Recommendations For I2C Use
I2C and SPI use STEVAL-IFS001V1 Recommendations for I C use ● With I C, the use of R36 & R37 pull-up resistors (4k7) is advised ● The use of resistor R34 (10k) is not normally necessary as uPSD has an internal pull- up of around 100k. -
Page 9: Upsd Software Use
STEVAL-IFS001V1 uPSD software use uPSD software use Digital or analog module The program automatically detects whether a module is digital or analog. The recognition is based on the value on pin P3.3. A digital module has this pin unconnected which is the same as logic ‘1’ because of an internal uPSD pull-up. Analog modules must employ a pull-down resistor to enable the detection of logic ‘0’. -
Page 10: On-Line Measurement
STEVAL-IFS001V1 On-line measurement During on-line measurement, data is read from MEMS and sent via USB to the PC. Logically, all three LEDs should blink. In this mode, the buttons have the following meanings: ● no button is pressed uPSD sends data from MEMS to the PC (a packet with MEMS data) ●... - Page 11 STEVAL-IFS001V1 uPSD software use values translate as <-1,-1,-1> readings on the PC MEMS USB Reader, which should be considered to detect both false readings and end of Flash data. ● BUT6 is pressed No effect. ● BUT7 is pressed No effect.
-
Page 12: Mems Software - Mems_Usb_Reader_7X
MEMS software - MEMS_USB_Reader_7x STEVAL-IFS001V1 MEMS software - MEMS_USB_Reader_7x Initial window and features overview Figure 6. Screenshot of initial screen of MEMS USB Reader 7.1 Main features available in the MEMS USB Reader include: ● MEMS values in time graph ●... -
Page 13: Butterworth Filters
STEVAL-IFS001V1 MEMS software - MEMS_USB_Reader_7x Use the MEMS Values screen to: ● Copy data into the Excel directly via clipboard ● Copy the graphic figure (graph) as a metafile via clipboard ● Save data into a CSV file Butterworth filters Figure 8. - Page 14 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
