3.2 Installation

3.2.1 Attention before installation
a) Please be sure the measuring pressure will not exceed the
transmitter measurement range;
b) Please be sure the measuring media is compatible with the
construction material;
c) Please be sure the measuring media will not jam the liquid
leading hole.
3.2.2 Installation Method
Usually the transmitter should be mounted vertically up to the horizontal
direction. In order to install and maintain conveniently, it is recommended
to install a cut-off value between the transmitter and the measuring point.
3.2.3 The pressure port can be customized for users
according to special request.

4 Electric Connection

4.1 The transmitter could be connected with the external
circuit through socket, cable or connection box.
Wire Color
Red
Black
4.2 Typical electrical connection method
Table 1
Plug Elctric connection
Pin 1
Pin 2
3
+V
0V/+OUT
