Outline Construction And Installation - Microsensor MPM430 Operation Manual

Operating temp.: -30℃~80℃(Plug)
Storage Temp.:
Shock Error:≤±0.01%FS (X,Y,Z 200Hz/g)
Temp Error:
Load: ≤((U–12V)/20mA)–Rwire(kΩ)
(Rwire is lead resistance(kΩ), U is power supply voltage(V))
Protection: IP65

3 Outline Construction and Installation

3.1 Outline dimension
M20×1.5
Type I
-20℃~70℃(cable material: PE,
-20℃~80℃(cable material:
-20℃~60℃(Intrinsic safe version)
-40℃~120℃
≤±0.15%FS/10℃
≤±0.2%FS/10℃
5 0
Ø42
Ø43
SW45
SW2 7
-20℃~85℃(Cable)
(-20℃~80℃)
(-30℃~-20℃)
50
M 42×1 .5
Type II
Figure 1
2
PVC)
PUR)
Ø 42
SW45
M42 ×1.5
Type III
Unit:mm
