Microsensor MPM430 Operation Manual page 6

a) The electric connection method of transmitter with Cable
Connection to see Figure2
P/I Transmitter
P
P
Input
b) The Electrical Connection Method of Explosion Proof Version
Transmitter to see Figure3:
Dangerous Area
P
P
Input
ExiaIICT6 Ga
Transmitter explosion proof parameter:
Ui=28VDC Ii=93mADC
Li=0mH Ci=0.044μF
Pi=0.65W
+V
0V/OUT
I
Figure 2
+V
OV
I
Figure 3
:
DC current
+
U
Load
+
R
Safe Area
Safe
Barrier
Load
[Exia] IIC
Safe barrier output
explosion proof parameter:
Uo=28VDC Io=93mADC
Po=0.65W
4
-
-
I
4mA 20mA
～
+
Power
-
24VDC
