Summary of Contents for Nokta Simplex LITE

  • Page 1 USER MANUAL...

  • Page 3: Table Of Contents

    UNDERWATER : 26 SIMPLEX metal detector may only be disassembled CHECK COIL ICON : 26 and repaired by Nokta Authorized Service Centers. Unauthorized disassembly/intrusion into the metal SOFTWARE UPDATE : 26 detector control housing for any reason voids the TECHNICAL SPECIFICATIONS : 27 warranty.
  • Page 4 ASSEMBLY (1) After inserting the washers on the lower shaft, place the lower shaft in its location on the search coil. Secure by tightening the screw and nut. Do not overtighten. (2) To join the middle rod with the upper and lower rods, open the lever latches and engage the pieces together.

  • Page 5: Introduction To The Device

    INTRODUCTION TO THE DEVICE (1) LCD Display (2) Power & Settings Button Press the button once to turn the device on. To turn off the device, press and hold it for around 3 seconds. For a hard reset in case of any unresponsiveness of the system, press and hold down for about 6 seconds.

  • Page 6: Display

    DISPLAY (1) Target ID scale (5) Magnetic Mineralization Indicator Shows the ID of the detected target on the ID (6) Wireless Connection scale. It also indicates the IDs filtered by Notch (7) Instant Depth Indicator Discrimination setting. (8) Battery Level Indicator (2) Search Modes (9) Settings (3) Sensitivity Indicator...

  • Page 7: Battery Information

    Do not charge the battery in temperatures over 35° C (95° F) or below 0° C ( 32° F). The SIMPLEX battery can only be replaced by Nokta Detectors or its authorized service centers. The battery pack takes 4 AA Alkaline or rechargeable NiCd or NiMH batteries.

  • Page 8: Headphones

    If you will not submerge the headphones underwater but just the system box, then you can also purchase our Nokta Koss Headphones with waterproof connector. 2. You can turn on or off the Bluetooth® connection using the plus (+) and minus (-) buttons.

  • Page 9: Correct Use

    CORRECT USE CORRECT WAY OF SWEEPING Shaft height is wrong Wrong search coil angle It is very important to adjust the shaft to your height correctly to be able to search without discomfort and fatigue. Correct search coil angle Incorrect way of sweeping It is important to keep the search coil parallel to the ground in order to get accurate results.

  • Page 10: Quick Guide

    QUICK GUIDE 4) You can increase the sensitivity if needed. Increasing the sensitivity will offer you greater depth. However, if 1) Assemble the device as per the instructions on page 2. the surroundings or the ground cause excessive noise in the device, you need to lower the sensitivity setting. 2) Press the Power &...
  • Page 11 8) You can now start searching. 11) Upon target detection, you can pinpoint the exact location of the target by pressing and holding the PP button. The audio volume will increase and the audio pitch will also increase as you approach the target. 9) Since your device operates with the motion principle, swing the search coil right and left maintaining 5cm (2”) distance above the ground.

  • Page 12: Target Id

    TARGET ID In some cases, the device may fail to provide any ID. The device needs to receive a strong and a clear signal TARGET ID is the number produced by the metal from the target in order to provide an ID. Therefore, it detector based on the conductivity of the metals and may not be able to provide an ID for targets at fringe gives an idea to the user about what the target may be.

  • Page 13: Search Modes

    Designed for coin and jewelry hunting in urban areas SIMPLEX ULTRA and parks where there are lots of modern trash (aluminum foil, pull-tabs, bottle caps etc.) present. SIMPLEX LITE Park SIMPLEX BT In this mode, the device produces a low tone...
  • Page 14 Beach In the All Metal mode, search is performed with a continuous humming sound in the background, also SIMPLEX LITE/BT/ULTRA) referred to as the threshold sound. The loudness of this This is a special mode of the SIMPLEX hum directly impacts the detection depth of smaller...

  • Page 15: Sensitivity

    SENSITIVITY TARGET DEPTH Sensitivity is the depth setting of the device. It The device provides an estimated target depth is also used to eliminate the ambient according to the signal strength during electromagnetic signals from the surrounding detection. environment and noise signals transmitted Depth Indicator: It shows the target’s proximity from ground.

  • Page 16: Ground Balance

    GROUND BALANCE 2. Press and hold down the Ground Balance / Confirm button and start pumping the search coil up and down SIMPLEX is designed to work without ground from about 15-20 cm (~6’’- 8’’) above the ground down balancing in Field and Park modes on most to 3 cm (~1’’) off the ground with smooth movements terrains.
  • Page 17 Manual Ground Balance Allows you to manually modify the ground balance value. It is not preferred mostly because it takes time. However, it is the preferred option in cases where automatic ground balance cannot be performed or fine tuning is necessary for the automatic ground balance value.

  • Page 18: Settings

    SETTINGS When you turn off and on the device it will start with the last volume level you chose. This setting is common Press the Power & Settings button to access all to all modes; changes will take effect in all modes. settings.
  • Page 19 Automatic Notch Discrimination: 2. You can move the cursor using the plus (+) and minus (-) buttons and reject the ID you want by pressing the 1. After entering settings by pressing the Power & Ground Balance / Confirm button. Rejected IDs will be Settings button, use the right and left buttons to select shown with lines over the ID scale.
  • Page 20 Iron Off Ground Suppressor Each time the SIMPLEX is turned on, iron will be off. It is used to eliminate false ground signals in tough In other words, the detector will not detect ferrous terrains. If you think your device is noisy and you are targets.
  • Page 21 Frequency Shift Threshold It is used to eliminate the electromagnetic interference In the All Metal mode, search is performed with a that the device receives from another detector which continuous humming sound in the background, also operates in the same frequency range nearby or from referred to as the threshold sound.
  • Page 22 OPTIONS For more detailed info about the wireless headphones, please read the instructions included with the In all the versions of the SIMPLEX, to access the headphones. Options, press the Power & Settings button to go into settings and then use the right and left buttons The Bluetooth®...
  • Page 23 The vibration setting is restored to the final saved setting when the device is turned off and on again. This setting is common in all modes; change made in any mode also applies to the other modes. Brightness It enables you to adjust the display and keypad backlight level according to your personal preference.

  • Page 24: Settings For Ultra Version Only

    SETTINGS FOR ULTRA VERSION ONLY Target ID Depth Coin/Relic ID Scale Adjusts the depth level that the device displays an ID for a detected target. It consists of 3 levels: L (Low), M By using this feature, you can differentiate the Target (Medium), H (High).
  • Page 25 Tone Break To adjust the Recovery Speed, press the Power & Settings button. Then use the right and left buttons to The Tone Break setting allows you to move the point select the Recovery Setting. The current value will be that separates the target zones.
  • Page 26 Tone Frequency Tone Volume setting range is from 0 to 5. At 0, the volume will be off. Tone Volume setting only affects the This setting allows you to adjust the frequency of mode currently selected; changes made in one mode do target response tones as well as the Threshold tone not affect the others.

  • Page 27: Pinpoint

    PINPOINT 3) Signal sound becomes stronger and changes in pitch while getting closer to the target center and the circles Pinpoint is to find the center or the exact location of a start disappearing in the pinpoint graphics. detected target. SIMPLEX is a motion detector.

  • Page 28: False Signals And Reasons

    LARGE OR NEAR-SURFACE ROCKS AND SEARCHING IN ROCKY TARGETS TERRAINS Targets which are near the surface may give multiple Challenging ground conditions arise especially when different signals to the device. If you suspect a target conductivity and magnetic properties of the ground are near the surface, lift the search coil and swing it more too intense.

  • Page 29: Detection On The Beach And Underwater

    DETECTION ON THE BEACH AND CHECK COIL ICON UNDERWATER It indicates an interruption in the search coil transmitter signal. The search coil connector may be unattached, SIMPLEX is a waterproof metal detector. This provides loose or disconnected. If you own another detector with convenient detection underwater and on the beach.

  • Page 30: Technical Specifications

    Length : 63cm - 132cm (25” - 52”) adjustable Battery : 2300mAh Lithium Polymer Warranty : 3 years Nokta Detectors reserves the right to change the design, specifications or accessories without notice and without any obligation or liability whatsoever. 55000536_EN...
  • Page 32 w w w . n o k t a d e t e c t o r s . c o m...
