Summary of Contents for Nokta SCORE

  • Page 1 USER MANUAL...

  • Page 3: Table Of Contents

    COMMON AND MODE-BASED SETTINGS artifacts you find. SEARCH MODES : 9-10 WARNINGS SCORE is a state-of-the-art electronic device. Do not SENSITIVITY : 11 assemble or operate the device before reading the user TARGET DEPTH : 11 manual.

  • Page 4: Assembly

    ASSEMBLY (1) After inserting the washers on the lower shaft, place the lower shaft in its location on the search coil. Secure by tightening the screw and nut. Do not overtighten. (2) To join the middle rod with the upper and lower rods, open the lever latches and engage the pieces together.

  • Page 5: Introduction To The Device

    IMPORTANT! The higher model DOUBLE SCORE is used throughout this manual for illustration purposes. Some of the features and settings shown are NOT present in the SCORE model.

  • Page 6: Display

    DISPLAY 1. Info Bar 6. Operating Frequency 2. Search Modes 7. Depth Indicator 3. Target ID Scale and Rejected IDs 8. Sub-settings and Pinpoint Indicator 9. Settings 4. Sensitivity Indicator 5. Target ID...

  • Page 7: Battery Information

    / charger input socket and the other end to the powerbank. Please note that you will not be SCORE battery can only be replaced by Nokta Detectors able to attach wired headphones to the device when a or its authorized service centers.

  • Page 8: Correct Use

    CORRECT WAY OF SWEEPING CORRECT USE Wrong search coil angle While detecting, the device may detect the metal objects you’re carrying or your shoes and generate false signals. Correct search coil angle Incorrect way of sweeping It is important to keep the search coil parallel to the While detecting, the device will not detect the metal ground in order to get accurate results.

  • Page 9: Quick Guide

    3. You can increase the sensitivity using the Plus (+) & QUICK GUIDE Minus (-) Buttons if needed. Increasing the sensitivity 1. Press and hold the Power & Settings Button for 3 will offer you greater depth. However, if the surroundings seconds to turn on the device.

  • Page 10: Common And Mode-Based Settings

    COMMON AND MODE-BASED SETTINGS Certain settings are common to all modes; changes in these settings will take effect in all modes. Most of the settings are mode based and they only affect the mode currently selected; changes made in one mode do not affect the others. Common settings and mode-based settings are shown below: Common Settings...

  • Page 11: Search Modes

    Both single frequency and multi frequency can be used SEARCH MODES in this mode. Based on target type, you can choose the SCORE has 3 search modes designed for different frequency you want. Multi frequency in Park mode will terrains and targets.
  • Page 12 There are 2 tones in this mode and the tone break point is set to 10. In the SCORE, Iron Filter feature is set to a higher level (8) in the Park and Beach modes, and in the Field mode Black Sand to a lower level (3) by default.

  • Page 13: Sensitivity

    Target ID. The indicator consists of 5 bars. Each bar estimated depth may vary for the same target represents 2 levels of sensitivity for DOUBLE SCORE during frequency changes. and 1 level of sensitivity for SCORE.

  • Page 14: Frequency

    Multi Frequency FREQUENCY Multi frequency which runs multiple frequencies SCORE offers Multi frequency (M1/M2/M3), simultaneously gives the user the advantage of covering where a wide range of frequencies work a broader range of targets on all types of terrains. simultaneously, as well as 1 single frequency In addition, it offers maximum depth for a large range of (15kHz).

  • Page 15: Noise Cancellation

    Noise Cancellation NOISE CANCELLATION 1. Before doing a noise cancellation, lift the device up in It is used to eliminate the electromagnetic interference the air as shown in the picture and hold it still until the that the device receives from another detector which process is completed.

  • Page 16: Target Id

    It may take some time and experience to make best use of the Target ID feature in your search area. Different SCORE’s Target ID scale consists of 30 lines and each brands and models of detectors produce different line represents 2 Target IDs.

  • Page 17: Discrimination Patterns

    The default discrimination pattern for Park, Field, Beach modes is the ‘’F’’ discrimination pattern which stands Default Discrimination Patterns for Ferrous Off. Search Mode Discrimination Patterns In SCORE, two IDs are rejected or accepted at the same PARK Ferrous Off (F) time. FIELD Ferrous Off (F)

  • Page 18: Pinpoint

    Pinpoint is to find the center or the exact ground. location of a detected target. SCORE is a motion detector. In other words, you are required to move the search coil over the target or the target over the search coil in order for the device to detect the target.

  • Page 19: Settings

    Press the Power & Settings Button once to exit the settings menu. 1. Ground Balance DOUBLE SCORE is designed to work without ground balancing on most terrains. However, for experienced users and on highly mineralized grounds, ground balancing will bring extra depth and stability to the device.
  • Page 20 In such a case, retry ground balancing at a different spot. IMPORTANT: DOUBLE SCORE automatically resets the Ground Balance value to zero (0) when Ground Balance cannot be done in Park and Field modes.
  • Page 21 Ground Tracking 3. You need to listen to the sounds coming from the ground in order to perform manual ground balance. The device tracks the changes in the ground during Pump the search coil up and down from about 15-20 detection and updates the ground balance automatically.

  • Page 22: Recovery Speed

    Ground Balancing on the Beach 2. Recovery Speed In DOUBLE SCORE, users are provided with a Stability The Recovery Speed setting adjusts the speed setting in addition to Ground Balance. This setting of target response. reduces noise and false signals received from the...

  • Page 23: Iron Filter

    Adjusting the Recovery Speed 3. Iron Filter Press the Power & Settings Button once. Select the Iron Filter allows desired non-ferrous targets in Recovery Speed setting using the Right & Left Buttons. trashy sites, previously masked by iron, to be The current value will be displayed on screen.

  • Page 24: Volume

    4. Volume 5. Backlight This control allows you to increase or decrease It enables you to adjust the display backlight the device’s volume based on your preference level according to your personal preference. and environmental conditions. It ranges from 0 to 5 and A1 to A5 . At 0 level, the Volume setting consists of 6 levels and it is set to 3 by backlight is off.

  • Page 25: Bluetooth

    Standard Bluetooth® headphones connected. aptX™ Low Latency headphones connected. For more detailed info about the Nokta BT Headphones, When the wireless connection is turned on, the please read the instructions included with the Bluetooth Headphones icon will start blinking in the headphones.

  • Page 26: Ground Suppressor

    7. Ground Suppressor 8. User Profile It is used to eliminate false ground signals in DOUBLE SCORE offers 2 user profiles where you tough terrains. can save your settings and create 2 different user profiles. This setting can be used both in Multi and single frequencies.
  • Page 27 Saving a User Profile DOUBLE SCORE tracks all changes made in the settings 2. If a user profile has been saved before, press and hold and even if you do not save them in a user profile, the the Pinpoint &...

  • Page 28: Notch (Accepting And Rejecting Ids)

    Target ID scale. To turn off or to turn on the ID press the Pinpoint & Discrimination Button. DOUBLE SCORE will not generate an audio response for rejected targets. However, their IDs will be shown in the notch discrimination menu.

  • Page 29: Sub-Settings

    During automatic notching, if the IDs are too jumpy, The current vibration value will appear on the display. you can press the Frequency & Noise Cancellation You can change the value using the Plus (+) & Minus Button to instantly decrease the sensitivity, allowing (-) Buttons.

  • Page 30: Led Flashlight

    In the settings menu, after selecting the user profile locations. in DOUBLE SCORE or sub-settings in SCORE, press and hold the Frequency & Noise Cancellation Button LED Flashlight does not operate when the device is off.

  • Page 31: Warning Messages

    System Version Information: coil transmitter signal. The search coil connector may be unattached, loose or The software version of SCORE will be displayed under disconnected. If you own another detector the ID Scale each time you turn the detector on.

  • Page 32: Technical Specifications

    The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. Qualcomm® aptX™ is a product of Qualcomm Technologies, Inc. Nokta Detectors reserves the right to change the design, specifications or accessories without notice and without any obligation or liability whatsoever.
  • Page 36 w w w . n o k t a d e t e c t o r s . c o m...
