Introduction To The Device - Nokta Simplex LITE User Manual

1
4 99
56
25
7 8 5 3 4

INTRODUCTION TO THE DEVICE

(1) LCD Display
(2) Power & Settings Button
Press the button once to turn the device on. To turn
off the device, press and hold it for around 3 seconds.
For a hard reset in case of any unresponsiveness of
the system, press and hold down for about 6 seconds.
(3) Pinpoint / Back Button
(4) Minus (-) Button: Reduce Sensitivity / Values of
Settings
(5) Plus (+) Button: Increase Sensitivity / Values of
Settings
(6) Right Arrow: Right side navigation between the
search modes and settings.
(7) Left Arrow: Left side navigation between search
modes and settings.
(8) Ground Balance / Confirm Button
(9) Speaker
(10) LED Flashlight
(11) Search coil input socket
(12) Wired headphones and charger input socket
IMPORTANT! When the connector is not in use, keep it
closed with the cap!
2 6
9
10
11
12
3
