Sensitivity; Target Depth - Nokta Simplex LITE User Manual

SENSITIVITY

Sensitivity is the depth setting of the device. It
is also used to eliminate the ambient
electromagnetic signals from the surrounding
25
environment and noise signals transmitted
from ground.
NOTE: To obtain maximum depth performance, to
eliminate the noise caused by electromagnetic
interference, try shifting the frequency first.
Sensitivity setting consists of 30 levels and is pre-
defined for each mode. All modes start at the default
setting. They can be manually modified when necessary.
Sensitivity adjustment applies to the selected mode; the
modified setting does not affect the sensitivity setting
of the other modes.
Sensitivity setting is a personal preference. However, It
is important to set the sensitivity to the highest level
possible where no major popping sounds are heard to
avoid missing smaller and deeper targets. For example;
if the noise level is suitable for searching and is the
same at level 25 and 30, then 30 should be preferred.
You can increase and lower the setting by using the (+)
and (-) buttons on the main screen. The bar on the left
indicates the level of sensitivity.
25
4 99

TARGET DEPTH

The device provides an estimated target depth
according to the signal strength during
detection.
Depth Indicator: It shows the target's proximity
to the surface in 5 levels during detection. As
the target gets closer, the levels decrease and
vice versa.
Shallow Target
Because each mode of the SIMPLEX has different
depth, the depth indicator will display a different depth
level for the same target in different modes.
Depth detection is adjusted presuming that the target
is a 2.5 cm (1'') coin. Actual depth varies according to
the size of the target. For instance, the detector will
indicate more depth for a target smaller than a 2.5 cm
(1'') coin and less depth for a larger target.
13
Deep Target
