IMPORTANT!
DO NOT DESTROY
Installation
and
Maintenance
Manual
with
Safety Information
and Parts List
RECOMMENDED SPARE PARTS HIGHLIGHTED IN GRAY
Model 190-ACC, LRC,
LRS & LRSS
190-LRS
190-ACC
Hytrol Conveyor Co., Inc.
PRESS OPTImIzEd fOR THE ENVIRONmENT
(ImpresIón OptImIzada para prOteger el medIO ambIente)
¡IMPORTANTE!
NO DESTRUIR
Jonesboro, Arkansas
Manual
de Instalación
Mantenimiento
con
Información sobre Seguridad
y Lista de Refacciones
LAS REFACCIONES RECOMENDADAS SE RESALTAN EN GRIS
Effective April 2011
(Supercedes September 2003)
Bulletin #634
190-LRC
190-LRSS
© COPYRIGHT 2009–HYTROL CONVEYOR CO., INC.
y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 190-ACC and is the answer not in the manual?

Questions and answers

Related Manuals for HYTROL 190-ACC

Summary of Contents for HYTROL 190-ACC

  • Page 1 Effective April 2011 Model 190-ACC, LRC, (Supercedes September 2003) LRS & LRSS Bulletin #634 190-LRS 190-LRC 190-LRSS 190-ACC Hytrol Conveyor Co., Inc. Jonesboro, Arkansas © COPYRIGHT 2009–HYTROL CONVEYOR CO., INC. PRESS OPTImIzEd fOR THE ENVIRONmENT (ImpresIón OptImIzada para prOteger el medIO ambIente)

  • Page 2: Table Of Contents

    190-ACC Parts drawing ....12 model 190-ACC Parts List....13 JONESBORO, ARKANSAS model 190-LRC 90 deg Parts drawing &...

  • Page 3: Safety Information

    In an effort to reduce the possibility of injury to personnel working Training shall include instruction in operation under normal conditions around HYTROL conveying equipment, safety labels are placed at and emergency situations. various points on the equipment to alert them of potential hazards.

  • Page 4: Installation

    INSTALLATION • Support Installation 1. determine primary direction of product flow. figure 4A indicates the preferred flow as related to the drive. 2. Refer to “match-mark” numbers on ends of conveyor sections. (figure 4A) Position them in this sequence near the area of installation. 3.

  • Page 5: Connecting The V-Belts

    • Conveyor Set-Up FIGURE 5A (Figura 5a) DRIVE SECTION (seCCIón mOtrIz) CENTER SUPPORT INTERMEDIATE (sOpOrte Central) SECTION (seCCIón IntermedIa) “MATCH-MARK” MATCH MARKS NUMBERS (etIQUetas de armadO) END GUARD (nÚmerO de (gUarda del eXtremO) etIQUetas de armadO) • Connecting the V-Belts Model ACC The double groove sheave, located at one end of each conveyor section, is used to connect the driving V-Belts of the conveyor.

  • Page 6: Racked Sections

    TO CONNECT THE V-BELT 1. Remove the front cover of the chain guard and disconnect the drive chain. This will free the drive sheave so belts may be installed. 2. Remove five tread rollers from both ends of each conveyor section (figure 6A). This is done by depressing one end of the spring-loaded shaft. 3.

  • Page 7: Conveyor Start-Up

    • Pressure Adjustment FIGURE 7A (Figura 7a) SPRING DRIVE V-BELT TREAD ROLLER (resOrte) (banda mOtrIz-V) (rOdIllOs de transpOrtaCIón) CORRECT INCORRECT (COrreCtO) (InCOrreCtO) TREAD ROLLERS (rOdIllOs de transpOrtaCIón) DRIVING V-BELT (banda mOtrIz-V) KNURLED ADJUST- PRESSURE SUSPENSION MENT NUT ROLLER ANGLE (tUerCa de aJUste) (ÁngUlO de (rOdIllO de sUspensIón)

  • Page 8: Lubrication

    NOTE: Special length V-belts are used on the “ACC” & “LRSS” convey- lubrication schedule for your specific application. A custom lubrication sched- ors. It is recommended that replacements be obtained from HYTROL. ule may be developed by inspecting the drive chain on regular time intervals The Models “LRC”...

  • Page 9: Drive Chain Alignment And Tension

    • Belt Replacement MODELS “LRC” & “LRS” The models “LRC” & “LRS” have a take-up bracket located near the center on MODEL “ACC” the underside of the conveyor. To adjust the belt tension, loosen the jam nuts Take-up brackets with sheaves are located at both ends of conveyor section on the take-up screw and move take-up sheave as indicated in figure 9A.

  • Page 10: Trouble Shooting

    3) Low voltage to motor. 3) Have electrician check and correct as necessary. 4) Low lubricant level in reducer. 4) Relubricate per manufacturer’s recommendations. for HYTROL reduc- 5) One or more V-belts too tight. er, refer to separate manual. 5) Re-position take-up sheaves further from double groove sheave.
  • Page 11 • External Slave Drive FIGURE 11A 3/8" (Figura 11a) CONNECTING CHAIN (CandadO) (COneCtOr de Cadena) ACORN NUT CHAIN GUARD SPROCKET (tUerCa CIega) BACK PLATE (CatarIna) (CUbIerta InterIOr de la gUarda) 3/4" CHAIN GUARD MOUNTING BRACKET FRONT PLATE (plaCa de mOntaJe) (CUbIerta FrOntal WING NUT de la gUarda)

  • Page 12: Model 190-Acc Parts Drawing

    • Model 190-ACC Parts Drawing Dibujo de Partes del Modelo 190-ACC (Vea la página 23 See Page 23 for para retenedores Sheave Retainers de polea) 15 16 21 22 24 23 24 12 13 30 31 33 VIEW B--B VIEW A--A...

  • Page 13: Model 190-Acc Parts List

    • Model 190-ACC Parts List Lista de Partes del Modelo 190-ACC 1-1/2 1-1/2 Ref. No. Part No. description Ref. No. Part No. description — motor - C-face 042.914 Shoulder Bolt - Suspension Angle — 030.7134 1/2 HP - 230/460 VAC - 3 Ph. - 60Hz. - TEfC 042.550...

  • Page 14: Model 190-Lrc 90 Deg Parts Drawing & List

    • Model 190-LRC 90 ° Parts Drawing and List Dibujo y Lista de Partes del Modelo 190-LRC de 90° See Page 23 for Sheave Retainers 15 16 (Vea la página 23 para retenedores de polea) END VIEW (Vista de Extremo) Ref.

  • Page 15: Model 190-Lrc 60 Deg Parts Drawing & List

    • Model 190-LRC 60 ° Parts Drawing and List Dibujo y Lista de Partes del Modelo 190-LRC de 60° See Page 23 for Sheave Retainers (Vea la página 23 para retenedores de polea) END VIEW (Vista de Extremo) Ref. No. Part No.

  • Page 16: Model 190-Lrc 45 Deg Parts Drawing & List

    • Model 190-LRC 45 ° Parts Drawing and List Dibujo y Lista de Partes del Modelo 190-LRC de 45° 15 16 See Page 23 for Sheave Retainers (Vea la página 23 para retenedores de polea) END VIEW (Vista de extremo) Ref.

  • Page 17: Model 190-Lrc 30 Deg Parts Drawing & List

    • Model 190-LRC 30 ° Parts Drawing and List Dibujo y Lista de Partes del Modelo 190-LRC de 30° 40 39 15 16 13 14 See Page 23 for Sheave Retainers (Vea la página 23 para retenedores de polea) End View (Vista de extremo) Ref.

  • Page 18: Model 190-Lrs 45 Deg Parts Drawing & List

    • Model 190-LRS 45 ° Parts Drawing and List Dibujo y Lista de Partes del Modelo 190-LRS de 45° 15 16 50 48 See Page 23 for Sheave Retainers (Vea la página 23 para retenedores de polea) End View (Vista de extremo) Ref.

  • Page 19: Model 190-Lrs 30 Deg Parts Drawing & List

    • Model 190-LRS 30 ° Parts Drawing and List Dibujo y Lista de Partes del Modelo 190-LRS de 30° 50 51 45 46 47 See Page 23 for Sheave Retainers (Vea la página 23 para retenedores de polea) End View (Vista de extremo) Ref.
  • Page 20 • Model 190-LRSS 45 ° Parts Drawing and List Dibujo y Lista de Partes del Modelo 190-LRSS de 45° See Page 23 for Sheave Retainers (Vea la página 23 para retenedores de polea) End View (Vista de extremo) Ref. No. Part No.
