BendPak LR-10000 Service Manual

Low-rise scissor lift
Hide thumbs Also See for LR-10000:

Advertisement

Quick Links

Download this manual
Service Manual
SERVICE PARTS & DIAGRAMS
BENDPAK
LR-10000
PRODUCT SKU
5175232
DRAWING Nº
5260184
(After-2022)
CATEGORY
Low-Rise Scissor Lift
REV
Version V
DATE
09.27.2022
This guide is a troubleshooting reference used for maintaining and
servicing your Bend Pak product. It provides comprehensive information
on identifying serviceable parts and components and assists in
troubleshooting problems and performing assembly /disassembly
procedures.
