Section B

Mounting the breakers

Internal view of
IQ System Controller 3/3G
The following figure shows the IQ System Controller 3/3G after
the dead front is removed. It comes with an inbuilt neutral forming
transformer, microgrid interconnection device, automatic transfer
switch, and a panel board to mount plug-in type breakers.
Hold-down kit
Load center for
DER breakers
Backup lugs
AUX and System
Shutdown terminals
Terminals for
DER cables
16
Main lugs
Neutral terminals
Ground terminals
