Section A

Mounting an
IQ System Controller 3 INT
Tools/additional items required
S . N O I T E M N A M E
1 Breakers of different ratings
2 Conduits (with fittings and fitting tools) - IP55 and above (for non-rear entry systems)
3 IP55 conduit ground locknut (for non-rear entry systems)
4 M6 pilot bit
5 Screw driver
6 Wrench
7 Adjustable wrench
8 Torque wrench up to 10 N m
9 Level
10 5/32" Allen key
11 Conductor stripper
12 Electrician's hole saw (2") or punch set
13 Stud finder
14 Drill, drill bit extender
M6 lag bolts or screw 80 mm long (depending on attaching wall) for each wall-mount
15
bracket
16 Control wire
* Recommended Electra EAS7302PHV or the LAPP 1270802
NOTE: The IQ System Controller 3 INT weighs 15.2 kg and will
require two people to lift and align the unit.
IQ System Controller 3 INT Quick Install Guide
M I N I M U M Q U A N T I T Y S O U R C E
4 Provided by installer
As required Provided by installer
1 Provided by installer
1 Provided by installer
1 Provided by installer
1 Provided by installer
1 Provided by installer
1 Provided by installer
1 Provided by installer
2 Provided by installer
1 Provided by installer
1 pair Provided by installer
1 Provided by installer
As required Provided by installer
2 Provided by installer
As required Provided by installer*
