Section C - Wiring

Backup loads wiring

IQ System Controller 3/3G Quick Install Guide
300 kcmil-2 AWG
1/4"
AW G TO R Q U E ( L B . I N )
300 kcmil-2 250
300 kcmil-6 AWG
3/8"
AW G TO R Q U E ( L B . I N )
300 kcmil-6 275
N E U T R A L A N D G R O U N D C O N N E C T I O N S
Neutral and ground bar – large holes
Neutral and ground bar – small holes
Neutral lugs
300 kcmil-14 AWG
1/0-14 AWG
300 kcmil-14 AWG
1/0-14 AWG
AW G TO R Q U E ( L B . I N )
1/0 - 3 50
4 - 6 45
8 40
10 - 14 35
6 - 8 25
10 - 14 15
300 kcmil - 6 275
5/16"-24 UNF
#10-32 UNF
3/8
"
