Patient Instruction Guide
Fitting instructions
1. Place SpryStep Plus into Shoe
Take the original inlay out of the shoe, if removable
•
The SpryStep Plus should fit into the shoe
•
with minimal distortion to the shoe
2. Place Inlay Over the Footplate
Place original inlay over the top
•
of the SpryStep Plus foot plate
If the inlay is not removable,
•
disregard this step
3. Fitting the SpryStep Plus
With the shoe laces loose, slide the foot inside
•
the shoe. You may use a shoe horn if needed
1.
Cautions
Risk of accident when driving a motor vehicle or machinery
•
when wearing SpryStep Plus is determined on a case by case
basis. Criteria include the type of fitting and the individual
abilities of the SpryStep Plus user
If the SpryStep is applied too tightly to the body it can result in
•
restricted blood flow or nerve palsy
SpryStep Plus can only be worn in appropriate footwear
•
(closed heel, closed toe, maximum heel height of 1")
Warranty
1 year warranty on carbon
•
fiber portion of the AFO
6 month warranty for pad and strap
•
Warranty Limitations
Extreme squatting or kneeling.
•
Loading a portion of the toe while
•
climbing stairs or uneven surfaces
L-0099 REV. A
3.
SpryStep
4. Check the Fit
Ensure the heel sits flat on the sole
•
and that the shoe heel is not distorted
5. Secure the Calf Strap
Feed the straps through the loop
•
If the strap is too long, remove the alligator
•
tab and trim the strap with scissors
Replace alligator tab
•
Fasten strap firmly
•
6. Secure the Fit
Ensure laces or other fastening
•
mechanisms are firmly tightened
Ensure comfort with no impingements prior to use
•
5.
Product Disclaimer
This brace is a prescription product that should be used
in accordance with the directives of a physician as part of
a treatment plan for managing the patient's total health.
While this type of brace has proven beneficial to many
patients, outcomes will vary based on factors including
patient age, general health, and/or lack of compliance
with instructions for how to put on and use the product.
Because of variations in the health and condition of each
patient, Townsend Design also does not make any specific
recommendations regarding appropriate activities for the
user of this brace. You should IMMEDIATELY DISCONTINUE
USE of this brace if there is any abnormal redness that lasts
more than 10 minutes after removing the brace, or any skin
irritation, bruising, blistering or abrasion.
4615 Shepard Street Bakersfield, CA 93313
Tele 800.432.3466 - Fax 800.798.2722
www.ThuasneUSA.com
Plus AFO
®
6.
MADE IN USA BY
TOWNSEND DESIGN
4615 SHEPARD STREET
BAKERSFIELD, CA 93313
TEL 661.837.1795
