Thuasne TOWNSEND SpryStep Plus AFO Instruction Manual page 2

Footplate Preparation
1. Tracing Footwear Inlay
Use the inlay from the footwear to measure the
•
template size (if the inlay is removable)
Trace the template onto the SpryStep Plus footplate
•
2. Cutting the Footplate
Use scissors to trim the footplate
•
to the correct template size
Note: It is only possible to trim
•
the blue area with scissors
Fitting instructions
1. Place SpryStep Plus into Shoe
Take the original inlay out of the shoe, if removable
•
The SpryStep Plus should fit into the shoe
•
with minimal distortion to the shoe
2. Place Inlay Over the Footplate
Place original inlay over the top
•
of the SpryStep Plus foot plate
If the inlay is not removable,
•
disregard this step
3. Fitting the SpryStep Plus
With the shoe laces loose, slide the foot inside
•
the shoe. You may use a shoe horn if needed
1.
L-0098 REV. A
3.
SpryStep
4. Check the Fit
Ensure the heel sits flat on the sole
•
and that the shoe heel is not distorted
5. Secure the Calf Strap
Feed the straps through the loop
•
If the strap is too long, remove the alligator
•
tab and trim the strap with scissors
Replace alligator tab
•
Fasten strap firmly
•
6. Secure the Fit
Ensure laces or other fastening
•
mechanisms are firmly tightened
Ensure comfort with no impingements prior to use
•
5.
4615 Shepard Street Bakersfield, CA 93313
Tele 800.432.3466 - Fax 800.798.2722
www.ThuasneUSA.com
Plus AFO
®
6.
MADE IN USA BY
TOWNSEND DESIGN
4615 SHEPARD STREET
BAKERSFIELD, CA 93313
TEL 661.837.1795
