INSTRUCTIONS FOR USE
CB-TECHNOLOGY (CLEAN BURN)
The stove is equipped with CB technology. In order to ensure optimal combustion of gases released during the combustion
process, air passes through a specially developed system of channels. The heated air is conducted into the combustion chamber
through the holes in the rear lining of the combustion chamber and at the baffle plates. This airflow is controlled by the rate of
combustion and cannot therefore be regulated.
NOTE: The wood must never be placed higher than the tertiary holes at the rear of the burn chamber (This does not apply at a
cold start).
PRIMARY AIR
The primary air is used when lighting the stove and must be closed after 10-20 minutes, when the fire has caught well. The prima-
ry air can be used continuously when using very hard wood.
Settings for normal load: 0 - 30%
SECONDARY AIR
Secondary air is pre-heated and fed indirectly to the fire. At the same time, the secondary airflow cleans the glass pane to avoid
soot build-up. If you over-restrict the secondary airflow, soot can build up on the glass pane. The secondary airflow determines
the heat output from your wood stove.
Settings for normal load: 50 - 70%
BAFFLE PLATE
The baffle plate is located in the upper part of the combustion chamber. The plate holds back smoke, making sure it stays inside
the combustion chamber for a longer time before escaping through the chimney. This reduces the flue gas temperature as the
gases have more time to dissipate heat to the stove.
The baffle plate must be removed for sweeping; see "Maintenance". Note that the baffle plate is made of porous, ceramic material,
and is liable to break easily. You should therefore handle it with care.
The baffle plate is subject to wear and tear and not covered by the warranty.
ASH CONTAINER
¬
Open the door of the stove to access the ash container under the combustion chamber
¬
The ash container must always be closed during operation
¬
The ash container must not be become too full and must therefore be emptied at regular intervals
¬
Never empty ashes into a flammable container. Ashes can contain glowing embers long after you finish operating the stove
16
