- Page 1 WASHING MACHINE USER‘S MANUAL GWN 47430 CB www.grundig.com Document Number 2820524733/ 26-12-16.(14:17)
- Page 2 Please read this user manual first! Dear Customer, Thank you for preferring a Grundig product. We hope that you get the best results from your product which has been manufactured with high quality and state-of- the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important instructions for safety Selecting the spin speed ..25 and environment 5.10 Programme and consumption table ......27 General safety . -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. General safety •• This product can be used by children at and above 8 years old and by persons whose physi- cal, sensory or mental capabilities are not fully developed or who lack experience and knowl-... -
Page 5: Product Safety
tion. If you wish to cancel the programme, see "Cancelling the programme" section. •• Connect the product to a grounded outlet pro- tected by a 16 A fuse. Have the grounding instal- lation made by a qualified electrician. Our com- pany shall not be liable for any damages that will arise when the product is used without ground- ing in accordance with the local regulations. -
Page 6: Intended Use
•• Use detergents, softeners and supplements suit- able for automatic washing machines only. •• Follow the instructions on the textile tags and on the detergent package. •• Place the product on a rigid, flat and level sur- face. •• Do not place it on a long-pile rug or similar sur- faces. -
Page 7: Compliance With The Weee
•• Store all detergents and additives in a safe place away from the reach of the children by closing the cover of the detergent container or sealing the detergent package. While washing the laundry at high temperatures, the loading door glass becomes hot. -
Page 8: Package Information
Package information •• Packaging materials of the product are manu- factured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points desig- nated by the local authorities. -
Page 9: Your Washing Machine
Your washing machine Overview 1- Power cable 2- Top panel 3- Control panel 4- Filter cap 5- Adjustable feet 6- Loading door 7- Detergent drawer 8- Drain hose... -
Page 10: Package Contents
Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronic water shut-off b- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual 7- Blind plug***... -
Page 11: Technical Specifications
Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark GRUNDIG Model name GWN47430CB Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 0.798... -
Page 12: Installation
Installation Removing packaging Refer to the nearest Authorised Service reinforcement Agent for installation of the product. To make the product ready for use, review Tilt the machine backwards to remove the information in the user manual the packaging reinforcement. Remove and make sure that the electricity, the packaging reinforcement by pulling tap water supply and water drainage... -
Page 13: Connecting Water Supply
•2. Remove transportation safety WARNING: Models with a single bolts by turning them gently. water inlet should not be connected to the hot water tap. In such a case the laundry will get damaged or the product will switch to protection mode and will not operate. -
Page 14: Connecting To The Drain
•3. Open the taps completely after drain more than 15 cm. If it is too making the hose connection long, cut it short. to check for water leaks at the •• The end of the hose should not connection points. If any leaks be bent, it should not be stepped occur, turn off the tap and on and the hose must not be... -
Page 15: Electrical Connection
•3. Tighten all lock nuts again by Transportation of the product •1. Unplug the product before hand. transporting it. •2. Remove water drain and water supply connections. •3. Drain all water that has remained in the product. •4. Install transportation safety bolts in the reverse order of removal procedure;... -
Page 16: Preparation
Preparation Sorting the laundry •• Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. •• Always obey the instructions given on the garment tags. LAUNDRY WASH SYMBOLS Machine Wash Symbols WASH Maximum Water Temperatures Symbol(s) Drying... -
Page 17: Preparing Laundry For Washing
Things to be done for Preparing laundry for washing energy saving •• Laundry items with metal attachments such as, underwired Following information will help you bras, belt buckles or metal use the product in an ecological and buttons will damage the machine. energy-efficient manner. -
Page 18: Correct Load Capacity
Laundry type Weight (g) Bathrobe 1200 Napkin Duvet cover Bed Sheet Pillowcase Tablecloth Towel Hand towel Evening gown Underclothing Men’s overalls Use an anti-limescale suitable for Men’s shirt the washing machines. Men’s Some water might have remained pyjamas in the product due to the Blouses quality control processes in the Loading the laundry... - Page 19 Detergent Drawer Choosing the detergent type The detergent drawer is composed of The type of detergent to be used three compartments: depends on the type and colour of the – (1) for prewash fabric. •• Use different detergents for – (2) for main wash coloured and white laundry.
- Page 20 Using liquid detergents Use the tablet or gel detergent If the product contains a liquid detergent without selecting the prewash cup: function. •• Place the liquid detergent cup in compartment nr. "2". Using starch •• If the liquid detergent has lost its ••...
-
Page 21: Tips For Efficient Washing
Tips for efficient washing Clothes Delicates/ Light colours and Dark Colours Woollen/ whites colours Silks (Recommended (Recommended (Recommended (Recommended temperature temperature temperature range temperature range range based on range based on based on soiling level: based on soiling level: soiling level: cold soiling level: cold 40-90 cold -40... -
Page 22: Operating The Product
Operating the product Control panel 1 - Programme Selection display 7 - Spin Speed Adjustment button 2 - Display 8 - Temperature Adjustment button 3 - Programme Follow-up indicator 9 - Programme Selection knob 4 - Start / Pause button 10 - On / Off button 5 - End Time Adjustment button 6 - Auxiliary Function buttons... -
Page 23: Preparing The Machine
Preparing the machine Main programmes •1 Check if the hoses are connected Depending on the type of fabric, use tightly. the following main programmes. •2 Plug in your machine. • Cotton •3 Turn the tap on completely. Use this programme for your cotton •4 Place the laundry in the machine. -
Page 24: Additional Programmes
• SenseWash • Anti-Allergy Use this to wash your frequently Use this programme for your laundry washable cotton, synthetic or blended for which you require an anti- (cotton+synthetic) clothes. Programme allergic and hygienic washing at high detects the type and quantity of the temperature with intensive and long laundry to automatically adjust water washing cycles. -
Page 25: Special Programmes
programme is over, leave the loading Temperature Adjustment button door ajar so that the inside of the functions only in the temperature machine gets dry. decrement direction. Finally, “-” symbol indicating the cold This is not a washing programme. It option appears on the display. - Page 26 Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display. Spin speed adjustment button functions only in the spin speed decrement direction. Rinse Hold option is indicated with “ı_ı” symbol and No Spin option is indicated with “_”...
-
Page 27: Table
5.10 Programme and consumption table Auxiliary functions Selectable Programme (°C) temperature range °C SenseWash **** **** 1400 • • • • Cold-60 60** 1400 Cold-60 Cotton Eco 60** 0.73 1400 Cold-60 40** 0.73 1400 Cold-60 2.03 1400 • • • •... - Page 28 ** “Cotton eco 40°C and Cotton eco 60°C are standard programmes.” These programmes are known as '40°C cotton standard programme' and '60°C cotton standard programme' and shown on the panel with symbols. The auxiliary functions in the table may vary according to the model of your machine. Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.
-
Page 29: Auxiliary Function Selection
5.11 Auxiliary function selection • Prewash A Prewash is only worthwhile for Select the desired auxiliary functions heavily soiled laundry. Not using the before starting the programme. Prewash will save energy, water, Whenever a programme is selected, detergent and time. frames of the auxiliary function symbols that can be selected together • Express with it illuminate. -
Page 30: End Time
5.12 End Time When the End Time selection With the function, the startup End Time is done, the time appearing on of the programme may be delayed the screen consists of end time up to 24 hours. After pressing plus the duration of the selected button, the displayed time is the programme. -
Page 31: Changing The Selections After
5.15 Changing the selections after Changing the auxiliary function, speed and temperature programme has started Depending on the step the programme Adding laundry after the programme has has reached, you can cancel or activate started: the auxiliary functions; , "Auxiliary button is When the Start / Pause function selection". -
Page 32: Cancelling The Programme
5.17 Cancelling the programme 5.20 Your machine is equipped The programme is cancelled when the with a “Standby Mode” machine is turned off and on again. In case of not starting any programme Press and hold On / Off button for 3 or waiting without making any other seconds. -
Page 33: Quick User Guide Preparing The Machine
Quick User Guide Preparing the machine Cancelling the programme •1 Check if the hoses are connected The programme is cancelled when the tightly. machine is turned off and on again. •2 Plug in your machine. Press and hold On / Off button for 3 •3 Turn the tap on completely. -
Page 34: Maintenance And Cleaning
Maintenance and cleaning Service life of the product extends and For products without drum cleaning, follow the below steps to clean the frequently faced problems decrease if drum: cleaned at regular intervals. Select Additional Water or Extra Cleaning the detergent drawer Rinse auxiliary functions. -
Page 35: Cleaning The Body And Control
Draining remaining water and WARNING: Never use sponge cleaning the pump filter or scrub materials. These will The filter system in your machine damage the painted, chrome plated and plastic surfaces. prevents solid items such as buttons, coins and fabric fibers clogging the Cleaning the body and pump impeller during discharge of control panel... - Page 36 •2 Open the filter cap. •3 Some of our products have • If the filter cap is composed of emergency draining hose and two pieces, press the tab on the some does not have. Follow the filter cap downwards and pull the steps below to discharge the piece out towards yourself.
-
Page 37: Troubleshooting
Troubleshooting Program does not start after closing the door. *Press the Start / Pause / Cancel •• Start / Pause / Cancel button was not pressed. >>> button. Programme cannot be started or selected. •• Washing machine has switched to self protection mode due to a supply problem (line Press and hold On / Off button for 3 seconds to reset voltage, water pressure, etc.). - Page 38 Loading door cannot be opened. Drain the water by •• Door lock is activated because of the water level in the machine. >>> running the Pump or Spin programme. Wait until the •• Machine is heating up the water or it is at the spinning cycle. >>> programme completes.
- Page 39 Washing performance is poor: Laundry turns grey. (**) Use the •• Insufficient amount of detergent was used over a long period of time. >>> recommended amount of detergent appropriate for water hardness and the laundry. •• Washing was made at low temperatures for a long time over a long period of time. >>> Select the proper temperature for the laundry to be washed.
- Page 40 Laundry became stiff after washing. (**) Using insufficient amount of detergent for •• Insufficient amount of detergent is used. >>> the water hardness can cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness. If detergent is put in the prewash ••...
- Page 41 Laundry remains wet at the end of the programme. (*) •• Excessive foam might have occurred and automatic foam absorption system might have Use recommended amount of been activated due to too much detergent usage. >>> detergent. Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
- Page 42 Accidental damage, misuse or abuse of a product. An attempted repair of a product by anyone other than a Grundig Approved Engineer (the “Engineer”). Installation or use of a product where such installation or use fails to meet the requirements contained in this guarantee or the User Instructions Booklet.
- Page 43 Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only. Does Grundig offer replacements? This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model, but when this is not possible, a model of similar specification will be provided.
- Page 44 Will there be any charge for the repairs? It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if: You cannot provide evidence that your product is covered by this guarantee.
- Page 45 Should you experience any difficulty in obtaining service contact the Grundig Customer Helpline on Tel: 0333 207 9920 or e-mail: customerservice@support.grundig.co.uk...
- Page 48 www.grundig.com...
