Summary of Contents for Kobold SZM

  • Page 1 Operating Instructions By-pass level indicator Model: SZM...
  • Page 2: Table Of Contents

    EU Declaration of Conformance ..............9     EU Declaration of Conformance (contact) ........... 10     Manufactured by: Sold by: Kobold-Unirota Ltd. Kobold Messring GmbH 4400 Nyíregyháza Nordring 22-24 Derkovits út 132-136. D-65719 Hofheim Tel.: +36-42-342-215 Tel.: +49(0)6192-2990 Fax: +36-42-500-175 Fax: +49(0)6192-23398 E-Mail: info.hu@kobold.com...
  • Page 3: Note

    Please read these operating instructions before unpacking and putting the unit into operation. Follow the instructions precisely as described herein. The instruction manuals on our website www.kobold.com are always for currently manufactured version of our products. Due to technical changes, the instruction manuals available online may not always correspond to the product version you have purchased.
  • Page 4: Regulation Use

    The user assumes all risk for such usage. 5. Operating Principle The Kobold Unirota SZM model by-pass level indicator works on the basis of the intercommunicating vessels principle. The SZM type glass tube level indicator is applicable for the indication of liquid level in small and middle-sized, standing or lying round containers used in food, pharmaceutical and chemical industries.
  • Page 5: Electrical Connection

     Plug in the system according to the connecting diagrams. 7.1.1 We recommend the use of wires with cross sectional area of min. 0.25 mm² Attention! Incorrect wiring will lead to damage of the unit’s electronics. 7.1.1.1 Wiring diagram load SZM K06/0323 page 5...
  • Page 6: Operation

    (electrically conductive) and nonmetal (electrically non- conductive) objects. Note: Customer cannot retrofit the contacts himself. If retrofitting of contacts is desired, the SZM should be ordered with a remark “prepared for retrofitting of limit contact”. Installing of the capacitive switch Slide the switch housing up until the glass tube is empty under the switch.
  • Page 7: Maintenance

    10. Maintenance If the medium to be measured is clean, the series SZM is virtually maintenance- free. If deposits form is on the inner housing or parts, periodic cleaning of the unit is recommended. At case of SZM-x1…, SZM-x2…, SZM-x3…, SZM-x5…, SZM-x8 (with cleaning hole): ...
  • Page 8: Disposal

    (Cd, Hg, Li or Pb) of the heavy metal that is decisive for the classification as containing pollutants: 1. „Cd" stands for cadmium 2. „Hg" stands for mercury 3. „Pb" stands for lead 4. „Li" stands for lithium Electrical and electronic equipment page 8 SZM K06/0323...
  • Page 9: Eu Declaration Of Conformance

    15. EU Declaration of Conformance We, KOBOLD Unirota Kft. Nyíregyháza Hungary, declare under our sole responsibility that the product: By-pass level indicator Model: SZM-… to which this declaration relates is in conformity with the standards noted below: EN IEC 63000:2018 Technical documentation for the assessment of electrical...
  • Page 10: Eu Declaration Of Conformance (Contact)

    16. EU Declaration of Conformance (contact) page 10 SZM K06/0323...
