Kobold SWK Operating Instructions Manual

Float flow meter / monitor
Hide thumbs Also See for SWK:

Advertisement

Quick Links

Operating Instructions
for
Float Flow Meter / Monitor
Model: SWK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWK and is the answer not in the manual?

Questions and answers

Summary of Contents for Kobold SWK

  • Page 1 Operating Instructions Float Flow Meter / Monitor Model: SWK...
  • Page 2: Table Of Contents

    4. Regulation Use .....................4 5. Operating Principle ..................4 6. Mechanical Connection.................5 7. Electrical Connection ..................5 8. Operation / Configuration / Adjustments ............6 8.1. Adjustment of Limit-Value (SWK-1...)..........6 8.2. Adjustment of Limit-Value (SWK-2...)..........6 9. Technical Information..................7 10. Maintenance ....................7 11. Dimensions ....................8 12.
  • Page 3: Note

    In case of damage, please inform your parcel service / forwarding agent immediately, since they are responsible for damages during transit. Scope of delivery: The standard delivery includes: • Float Flow Meter / Monitor Model: SWK • Operating Instructions SWK 12/03 page 3...
  • Page 4: Regulation Use

    4. Regulation Use These units of type SWK are used with a view to measure and monitor the liquid flow. Only clean, low-viscous and homogeneous liquids may be measured which do not chemically attack the materials used in the construction of these units. An attempt to measure high-viscous liquids may lead to considerable measurement errors.
  • Page 5: Mechanical Connection

    • Make sure that the supply wires are de-energized. • The connection of bistable reed contact succeeds through the cable on contact housing. The potential-free contact closes on rising level above the adjusted flow value. SWK 12/03 page 5...
  • Page 6: Operation / Configuration / Adjustments

    The unit is supplied in 'ready for operation' condition. The switching point is adjusted on the lowest scale value. 8.1. Adjustment of Limit-Value (SWK-1...) • Loosen the knurled nut on reed contact. • Adjust the marking on the contact for the desired value on the scale. In this position the knurled nut should be tightly screwed.
  • Page 7: Technical Information

    Protection cat.: IP 65 10. Maintenance In case the medium to be measured is not contaminated, the device SWK is almost maintenance-free. With lime or such depositions within inner sections the device should be cleaned regularly. Attention! Before the commencement of maintenance work, make sure that the supply wires are de-energized.
  • Page 8: 11. Dimensions

    11. Dimensions G 1/2 22,4 G 1/2 G ½ l/min. Typ: G ½ Approx. 70 page 8 SWK 12/03...
  • Page 9: 12. Declaration Of Conformance

    12. Declaration of Conformance We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole responsibility that the product: Float Flow Meter / Monitor Model: SWK... to which this declaration relates is in conformity with the standards noted below: DIN EN 61010-1...
