Connects2 Vision CAM-16 User Manual

Universal camera, surface mounted in smooth squared plastic housing

U s e r M a n u a l

CAM-16

PRODUCT FEATURES:

Image Sensor 1099 HD CCD

TV Lines: 480

Resolution: 976 x 496

Lumen: 0.1 Lux

Horizontal Angle: 170 Degrees

Vertical Angle: 120 Degrees

TV System: NTSC

Video Output: 1.0V p-p 75ohm

Operating Voltage: 12V DC (Negative Ground)

Current Consumption: 120mA @ 13.8V

Waterproof Rating: IP68

Operating Temperature: -20 Degrees C to +70 Degrees C

Parking Lines: Yes

Removable Lines: Yes

Image Adjustment: Yes (Mirror/Normal)

Enhanced Performance In Low Light: Yes

DISCLAIMER:

Prior to Installation

Read the manual prior to installation. Technical knowledge is necessary for installation.

Please ensure you use the correct tools to avoid damage to the vehicle or product.

Connects2 can not be held responsible for the installation of this product.

Technical Support

Connects2 want to provide a fast and suitable resolution should you encounter any

technical issues. With this in mind, when contacting Connects2, try to provide as

much Information as possible. This will speed up the process and help us to help you.

Please use our dedicated online technical support centre: support.connects2.com

Universal Camera

Surface Mounted in Smooth Squared Plastic Housing
