DIP Switches

5.4. DIP Switches
See figure: Gateway layout (page 19)
1: DIP switch A (SW A).
2: DIP switch B (SW B).
Each DIP switch is dedicated to a 485 port, and its function is to activate or deactivate the termination resistor
and the polarization of each port:
Position
1 2 3
↑ X X 120 Ω termination active
↓ X X 120 Ω termination inactive (default position)
X ↑ ↑ Polarization active (default position)
X ↓ ↓ Polarization inactive
