Element 75 Manual
No Function
A Motor 'Reverse' Switch 0V
B Motor 'Reverse' Switch +5V
C Motor 'Forward' Switch 0V
D Motor 'Forward' Switch +5V
E
F
G
H
I
J
K
L Motor 'Reverse' LED 0V (BLUE)
M Motor 'Reverse' LED +12V (BLUE)
N Motor 'Forward' LED 0V (Green)
O Motor 'Forward' LED +12V (Green)
Original Instructions
Magnet Switch 0V
Magnet Switch +5V
Magnet 'ON' LED +5V
Magnet 'ON' LED +5V
Magnet 'ON' LED 0V
Power 'ON' LED 0V
Power 'ON' LED +5V
Wire Colour
White
White
White
White
White
White
White+Green
White+Red
White+Brown
White+Black
White+Brown
White
White
White
White
15
Dec2016
