- Page 1 C-WT ® Pneumatic-hydraulic blind rivet nut setting gun Operating manual with spare parts list SFS Group Germany GmbH T +49 (0) 6105 962 0 Division Riveting – GESIPA ® F +49 (0) 6105 962 287 Nordendstraße 13-39 64546 Mörfelden-Walldorf info@gesipa.com www.gesipa.com...
- Page 2 1638027 Operating manual FireRex C-WT ®...
- Page 3 12;13 12;13 Overview C B A I, J 1638027 Operating manual FireRex C-WT ®...
-
Page 4: Table Of Contents
Table of Contents Overview (See images 1 - 4) ................5 Blind rivet nut setting tool FireRex C-WT ............5 ® 2.1 Correct use....................5 2.2 Safety instructions ..................5 2.3 Work capacity .....................6 2.4 Technical data ....................6 2.5 Equipment/accessories ................7 3. Configuration .....................7 3.1 Pneumatic circuit diagram ................9 3.2 Process data evaluation ................11 Starting procedure ...................11... -
Page 5: Overview (See Images 1 - 4)
Overview (See images 1 - 4) Item Designation Image Locknut 1, 4 Nosepiece 1, 4 Threaded mandrel 1, 4 Slide Wind down button Bead breaking process (solenoid valve) Slide Adjustable screw with colour scale Display window Oil refill screw Seal Blind rivet nut setting tool FireRex C-WT ®... -
Page 6: Work Capacity
• Repair work must be carried out by skilled personnel. Use genuine parts for repair at all times. In case of doubt, always send the complete blind rivet nut setting tool back to the supplier or to GESIPA ® •... -
Page 7: Equipment/Accessories
Process data module Supply voltage 24 Volt DC (no galvanic isolation in the device) Permissible supply voltage range 10-28 Volt Power consumption 1.5 Watt Behaviour in the event of a failure of the supply Automatic data retention after power failure voltage Laufzeit Stützbatterie (CR2032) für Realtime- 5 years... - Page 8 Figure 1 cable assembly pressure relay valve Air supply connection block Data cable bead breaking Threaded mandrel process Air motor Nosepiece Device holder Force/stroke sensors 1638027 Operating manual FireRex C-WT ®...
-
Page 9: Pneumatic Circuit Diagram
Pneumatic circuit diagram Pneumatic attachments (1544052) Item Description Part No. 1.1, 1.2 Solenoid valve 1630132 Solenoid valve 1600130 / 1630131 Solenoid valve 1630130 / 1630131 Connecting lead (for solenoid 1630134 valve) Plug connection 1445957 Blind plug 146142 Pneumatic hose 1445398 Pneumatic feed unit (1518269) Item Description... - Page 10 1638027 Operating manual FireRex C-WT ®...
-
Page 11: Process Data Evaluation
GESIPA . For editing of the blind rivet nut setting ® tool, it must be connected to a PC with Windows 7 or higher using the GESIPA GrivCheck ® 2.0 software and a USB adapter cable (Article No. 1435512). -
Page 12: Oiler
C-WT blind rivet nut setting tool with oiled air. • The lubricator may only be integrated in line 6 (twist off). • The original GESIPA oil can be used for lubrication. ® • The oiler should be set such that approx. 1 drop of oil is added to the compressed air every 300- 350 setting operations. One filling of the supplied oiler is therefore sufficient for 600,000 - 700,000... - Page 13 Stahl Edelstahl Steel Stainless steel To adjust the setting force, follow the sequence of operations below: The setting force can be pre-set using the enclosed colour code chart. The right colour code can be selected on the colour code chart according to the nut sizes and the nut materials (e.g.
-
Page 14: Sequence Of Operations
Sequence of operations How to wind down a nut • Position blind rivet nut without tilting on threaded mandrel C. • Then use the blind rivet nut setting tool to press the threaded mandrel C towards the rivet tool. This action will automatically start the winding down process. •... -
Page 15: Troubleshooting
® • Screw on mouthpiece B with lock nut A. Regular maintenance will extend the service life of your high-quality GESIPA ® tools and they should be serviced at least every 2 years by an authorised workshop or by GESIPA Service. -
Page 16: Notes On Environment
Increase air pressure to 5-7 bar Notes on environment Dispose of hydraulic waste oil according to current environmental regulations. Observe regulations about dangerous substances! Warranty The applicable terms and conditions of guarantee shall apply and can be viewed under following link: www.gesipa.com/agb 1638027 Operating manual FireRex C-WT ®... -
Page 17: Declaration Of Conformity Ec
Electronic Equipment Regulations 2012 EN ISO 11148-1:2011 EN 55014-1:2016 EN 55014-2:2015 Authorised documentation representative: SFS Group Germany GmbH Division Riveting – GESIPA ® Nordendstraße 13-39 D-64546 Mörfelden-Walldorf ppa. Dipl.-Ing. Stefan Petsch Head of Operations Tools Member of Division Management... - Page 18 Your partner...
