Danfoss CS10 Technical Information page 9

Technical Information
PLUS+1® CS10 Wireless Gateway
Configuration
© Danfoss | November 2020
On the WiFi Connection page, client status shows the connection status of the CS10 device.
Enable/Disable activates/deactivates the WiFi unit of the device, the actual status is indicated by the LED
WiFi enabled. When using the Connect button the device tries to connect to the access point defined in
the WiFi Connection.
The name of the network client is shown in the field SSID. The Mode field indicates if the connection has
been established. Link quality shows the quality of the connection when it's established.
Connection IPv4 address shows the assigned network address.
The section AP list shows the networks available. Using the Scan button starts a scan for available
networks.
The number of available networks is shown in the field Number of access points, the first element to be
shown in the list can be selected with the Start index field.
For each available network the SSID, signal quality, signal level and the security type are provided.
BC356772124151en-000102 | 9
