Technical Information
PLUS+1® CS10 Wireless Gateway
Literature references

Technical Information (TI)

Module product Data Sheet (DS)

API specifications (API)

PLUS+1 GUIDE User Manual
®
4 | © Danfoss | November 2020
Literature title
PLUS+1 ® CS10 Family Technical Information
PLUS+1 ® CS10 Data Sheet
PLUS+1 GUIDE Software User Manual
®
Comprehensive technical literature is online at www.danfoss.com
A TI is comprehensive information for engineering and service personnel to reference.
A module product DS contains summarized information and parameters that are unique to an individual
PLUS+1 ® module, including:
•
Numbers and types of inputs and outputs
•
Module connector pin assignments
•
Module maximum current capacity
•
Module sensor power supply (if present) current capacity
•
Module installation drawing
•
Module weights
•
Product ordering information
Module API specifications contain detailed information about the module BIOS. PLUS+1
functionality is pin dependent. Pins are defined in module data sheets as C (connector number) p (pin
number).
API specifications include:
•
Variable name
•
Variable data type
•
Variable direction (read/write)
•
Variable function and scaling
Module API specifications are the definitive source of information regarding PLUS+1
characteristics.
The Operation Manual (OM) details information regarding the PLUS+1
®
+1 applications. This OM covers the following broad topics:
•
How to use the PLUS+1 ®
applications
•
How to configure module input and output parameters
•
How to download PLUS+1
•
How to upload and download tuning parameters
•
®
How to use the PLUS+1
GUIDE graphical application development tool to create machine
® GUIDE applications to target PLUS+1
Service Tool
Document type Literature ID
BC314255793849
User Guide
AI314170881786
Data Sheet
Operation Guide AQ152886483724
® module pin
® GUIDE tool used in building PLUS
® hardware modules
BC356772124151en-000102
® BIOS
