- Page 1 Sanitary systems TECElux TECHNICAL INFORMATION...
- Page 2 All data contained in the Technical Information has been compiled with the utmost care. However, the correctness of the data presented cannot be guaranteed. TECE assumes no liability for damage resulting from the use of this information. Text and images are protected by copyright law.
-
Page 3: Table Of Contents
Contents Introduction Design Advanced features Product range TECElux module Upper glass flush plates with actuation unit Lower toilet attachment glass panels Accessories Shell installation Installation in a TECEprofil pre-wall Installation as an individual module in front of a solid wall Installation in C-profile metal stud wall Installation in floor-to-ceiling metal stud wall with UA-profiles Installation in a wooden stud wall... -
Page 4: Introduction
Introduction Introduction The TECElux toilet terminal conceals all its technology in the wall. An extremely flat glass facing closes the inspec- tion opening and conceals the cistern, connections for water and power and, depending on the version, an odour extraction or height adjustment for the ceramics. Design With its simple aesthetics, TECElux blends in with the archi- tecture of any bathroom. -
Page 5: Advanced Features
Introduction Advanced features “smart-Connect” interface Electronic “sen-Touch” flush actuation Additional functions on the toilet require space and often also a power or extra water connection. Until now, the technology was simply added onto the ceramics and the A simple touch with the finger actuates the flush. The flush necessary water and power lines were installed visibly next can also be activated without contact, by approaching to the toilet. -
Page 6: Product Range
A TECElux toilet terminal always consists of: (A) a TECElux module (B) an upper flush plate and (C) a lower toilet mounting plate with recesses for different power and water connections. TECElux module TECElux 100 TECElux 200 TECElux 400 Item no. 9600100 Item no. - Page 7 Product range Overview of lower attachment panel and accessories for toilets and shower toilets 9650100 (w) 9660001 9650101 (w) 9650102 (w) 9650103 (w) 9650104 (w) 9650109 (w) 9650105 (b) 9650106 (b) 9650107 (b) 9650108 (b) 9650110 (b) Standard ceramics (connection dimension 180 mm) TOTO Neorest AC 2.0 * TOTO Neorest EW 2.0 * TOTO Washlet CF...
-
Page 8: Tecelux Module
“ceram- ic-Air” air purification system. The flush is only actuated electroni- TECElux 100 module cally (sen-Touch). With TECE concealed cistern and dual-flush technology. Item no. 9600400 The flush is actuated mechanically by buttons or electronically via “sen-Touch”. - Page 9 Product range TECElux 400 module technology Note: It is possible to install the “ceramic-Air” odour extraction system in all common toilet ceramics. However, there are some ceramics where the flushing water remains in the flushing pipe due to a raised seating position or raised flushing rim and partial/full filling can occur.
-
Page 10: Upper Glass Flush Plates With Actuation Unit
Product range Upper glass flush plates with actuation unit Lower toilet attachment glass panels Upper glass flush plates with manual operating unit Lower glass panel for TECEone Upper glass flush plate for TECElux module with two- Lower glass panel for combination with the TECEone spring mounted flush buttons. - Page 11 Product range Lower glass attachment panel for shower toilet (Toto, Lower glass panel for Geberit Aquaclean Sela shower Geberit) toilet. Lower glass panel for combination with shower toilet TOTO Lower toilet glass panel for combination with Geberit Neorest AC and EW or Geberit AquaClean 8000/8000 AquaClean Sela shower toilet.
-
Page 12: Accessories
For permanent electrical connection of the “sen-Touch” “ceramic-Air” odour extraction upgrade kit glass panel in protection area II. Upgrade kit for subsequent installation of “ceramic-Air” odour extraction for TECElux 100 or TECElux 200 toilet terminals. Connection set consisting of: • Empty socket, protection class IP 44 •... -
Page 13: Shell Installation
Shell installation Shell installation Universal module technology is also used with the TECE- lux modules. This also increases the possible areas of installation: • In a TECEprofil pre-wall • In front of a solid wall • In a C-profile wall •... -
Page 14: Installation As An Individual Module In Front Of A Solid Wall
Shell installation Individual module assembly with depth-adjustable univer- sal fasteners Installation in a free-standing TECEprofil wall Individual module installation with depth-adjustable universal fasteners The universal module is placed directly against the wall. Installation as an individual module in front of The pre-wall depth can be adjusted using the universal a solid wall fasteners. - Page 15 Shell installation When using the TECElux 100 without barriers in front of a Individual module assembly with height-adjustable solid wall, an additional mounting set is required around module fastener the basin of the module. 2 x 9 380 014 Individual module assembly with height-adjustable module fastener Adjustment range of universal fastener 150 –...
- Page 16 Shell installation Installation with module fastener for wall corner installa- tion Single module assembly with module fastener for wall corner assembly The module fastener for wall corner installation allows Installation of the module fastener for corner assembly TECElux modules to be attached to a solid structural wall at an angle of 45°.
- Page 17 Shell installation Installation with module fastener for variable corner assembly Module fastener for variable corner assembly 9380003 Dimensions of module fastener for variable corner assembly Installation of module fastener for variable corner assembly The universal module can be directly attached to the struc- tural shell with the corner attachments.
-
Page 18: Installation In C-Profile Metal Stud Wall
Shell installation Installation in floor-to-ceiling metal stud wall Installation in C-profile metal stud wall with UA-profiles Installation in C-profile metal stud wall The module is screwed to the wall profiles at four points each using the self-tapping screws provided. The module Installation in a floor-to-ceiling UA-profile metal stud wall feet are at the front under the horizontal C-profile and can If particularly wide or high walls are to have a higher... -
Page 19: Installation In A Wooden Stud Wall
Shell installation Installation in a wooden stud wall Mounting holes must be drilled to attach the module Installation in a wooden stud wall As well as metal stud walls, the module can also be installed in wooden stud walls. The frame can be mounted using special wood screws (item no. -
Page 20: Attaching Individual Modules To The Floor
Shell installation If installed horizontally, the fastening clip is directly Attaching individual modules to the floor screwed onto the module frame. If installed vertically, the Unless screwed tightly to a profile pipe, the feet of the clip must be screwed into the wall. TECElux modules should be attached to the bare floor using the screws and wall plugs supplied. - Page 21 Shell installation Apply the exact dimensions of the bare-wall protection to the plaster board. Cutting out the wall recess To ensure the height adjustment of both TECElux 200/400 modules, the module frames should not be drilled through in certain areas. These are indicated by 2 x 3 stickers on the frame.
- Page 22 Shell installation After attaching the panel plates, cover the welts. Plinth height max. 50 mm Covering welts of the plaster board. When tiling the wall, make sure that the wall covering is applied seamlessly right up to the bare-wall protection. Applying the wall covering When tiling the floor, make sure that the plinth height is maximum 50 mm, otherwise the lower attachment glass panel could collide with the plinth.
-
Page 23: Power Supply
Shell installation Power supply Power and water connection with TECEone When installing the power supply, ensure compliance with When using a TECEone with a TECElux module, a power local regulations and guidelines. supply is only necessary if a “sen-Touch” flush plate is used. -
Page 24: Fine Installation
Fine installation Fine installation Now secure the threaded rods at the back and tighten the locking nuts. The order of the fine installation for the TECElux terminal is as follows: Mount the lower attachment glass panel. • Lower attachment glass panel Cut the toilet connection set to a suitable length and plug •... - Page 25 Fine installation Lower attachment glass panel for TOTO Neorest and Geberit AquaClean 8000, 8000 plus (item no. 9650101/...106) Mount the lower attachment glass panel. Guide the reinforced hose through the hole provided for the purpose in the glass panel. Cut toilet connection set to length and plug in, attach sound insulation strip to ceramics.
- Page 26 Fine installation Lower attachment glass panel for Duravit SensoWash Starck C (item no. 9650103/...107) Mount the lower attachment glass panel. Connect the reinforced hose to the shower toilet. Lower attachment glass panel for TOTO Washlet and Geberit AquaClean 5000, 5000 plus Guide the reinforced connection hose and power cable (item no.
- Page 27 Fine installation Mount the Duravit electronic connection box (following Guide the reinforced hose and the power cable through the Duravit assembly instructions) or V & B connector plug the waste water connection opening or the opening on the (following the V & B assembly instructions). side of the glass panel.
-
Page 28: Lower Attachment Glass Panel For Teceone
Fine installation Lower attachment glass panel for TECEone When using a TECEone with a TECElux module, a power supply is only necessary if a “sen-Touch” flush plate is used. Put the glass panel in place and guide the reinforced hoses through the large opening in the glass panel to the front. -
Page 29: M-Lift" Height Adjustment
Fine installation “m-Lift” height adjustment For modules with manual “m-Lift” height adjustment, the adjustment is carried out by means of an easily accessible adjusting screw (A). On TECElux modules 200 and 400, it is possible to lower the height 20 mm downwards or raise it 60 mm upwards – compared with the module frame's factory settings. -
Page 30: Upper Glass Flush Plate With Actuation Unit
Fine installation Screw in both magnetic holders – 10 mm in front of the Upper glass flush plate with actuation unit wall surface. Manual actuation: Cut actuation rod to length and screw in - 4 mm in front of wall surface. Insert the upper flush plate into the holders and fold it up. -
Page 31: Programming The Sen-Touch Electronics
Fine installation Programming the sen-Touch electronics Within the first hour after connection to the power supply, the sen-Touch electronics can be programmed. In the event of a power failure, the last settings saved are retained. Each configurable function is assigned a position on one of the two touch fields. - Page 32 Fine installation How to program the sen-Touch electronics: • Touch the large or small touch field with your hand. Programming mode starts after 10 seconds with a quick series of short beeps. • After the start-up phase, a sequence of the same beeps can be heard.
