  • Page 1 Sanitary systems TECElux TECHNICAL GUIDELINES...
  • Page 3: Table Of Contents

    Contents Introduction Design Advanced features Product range TECElux module Upper glass facings with actuation unit 1-10 Lower glass attachment facings for toilet attachment 1-10 Accessories 1-12 Shell installation 1-13 Installation in a TECEprofil pre-wall 1-13 Installation as an individual module in front of a solid wall 1-14 Installation in a floor-to-ceiling C-profile metal stud wall 1-18...
  • Page 4: Introduction

    TECElux – Introduction Introduction The TECElux toilet terminal conceals the working parts behind the wall. An extremely flat glass facing closes the inspection opening and conceals the cistern, connections for water and power and, depending on the version, an odour extraction or height adjustment for the ceramic. Design With its simple aesthetics, TECElux blends in with the archi- tecture of any bathroom.
  • Page 5: Advanced Features

    Advanced features “smart-Connect” interface Electronic “sen-Touch” flush actuation Additional functions on the toilet require space, and frequently also a power connection or extra water connec- tion. Up until now, the technology was simply added on A simple touch with the finger actuates the flush. The flush to the ceramic, and the water and power lines were laid can also be activated without contact, by moving to within visibly next to the toilet.
  • Page 6: Product Range

    TECElux – Range Product range A TECElux toilet terminal always consists of: (A) a TECElux module (B) an upper flush plate and (C) a lower facing for toilet attachment and notches for different power and water connections. TECElux module TECElux 100 TECElux 200 TECElux 400 Order no.
  • Page 7 Overview of lower attachment facings and accessories for toilets and shower toilets 9650100 (w) 9660001 9650101 (w) 9650102 (w) 9650103 (w) 9650104 (w) 9650109 (w) 9650105 (s) 9650106 (s) 9650107 (s) 9650108 (s) 9650110 (s) Standard ceramics (connection dimension 180 mm) TOTO Neorest AC * TOTO Neorest EW * TOTO Washlet CF...
  • Page 8: Tecelux Module

    All modules consist of height adjustment. the same self-supporting, stable mounting frame and the tried and trusted TECE dual-flush cistern. The flush is actuated mechanically by buttons or electronically via Other common components: “sen-Touch”.
  • Page 9 TECElux 400 module technology Note: It is possible to install the “ceramic-Air” odour extraction system in all well-known toilet ceramics. However, the flushing water remains standing in the flush pipe of some ceramics with a higher sitting position or higher flushing rim, resulting in the bowl becoming partially or completely full.
  • Page 10: Upper Glass Facings With Actuation Unit

    TECElux – Range Upper glass facings with actuation unit Lower glass attachment facings for toilet attachment Upper glass facings with manual operating unit Lower glass facing for TECEone Upper glass facing for TECElux module with two-spring mounted actuation buttons. Lower glass facing for combination with the TECEone ceramic with shower function.
  • Page 11 Untere Befestigungsglasplatte für Dusch-WC (TOTO, Lower glass facing for Geberit Aquaclean Sela shower Geberit) toilet. Lower glass facing for combination with shower toilet Lower toilet glass facing for combination with Geberit TOTO Neorest AC and EW or Geberit AquaClean AquaClean Sela shower toilet. 8000/8000 plus.
  • Page 12: Accessories

    TECElux – Range Connection set for electrical connection Accessories For fixed electrical connection of the “sen-Touch” glass “ceramic-Air” extraction upgrade kit facing in protection area II. Upgrade kit for subsequent installation of “ceramic-Air” odour extraction for TECElux 100 or TECElux 200 toilet terminals.
  • Page 13: Shell Installation

    TECElux – Shell installation Shell installation Universal module technology is also used on TECElux modules. This also increases the possible areas of installa- tion: • in a TECEprofil pre-wall • in front of a solid wall • in a C-profile wall •...
  • Page 14: Installation As An Individual Module In Front Of A Solid Wall

    TECElux – Shell installation Individual mounting with depth-adjustable universal attachments Installation in a free-standing TECEprofil wall Individual mounting with depth-adjustable universal attachments The universal module is placed directly against the wall. Installation as an individual module in front of The pre-wall depth can be adjusted using the universal a solid wall attachments.
  • Page 15 When using the TECElux 100 without barriers in front of Individual assembly with height-adjustable module a solid wall, an additional mounting set is required in the attachment module's bowl area. Individual assembly with height-adjustable module attachment Adjustment range of universal attachment 150-240 mm With the height- and depth-adjustable module attach- ment, variable supporting structure heights of 1160 mm Mounting in this way with four attachments is sufficient to...
  • Page 16 TECElux – Shell installation Installation with module attachment for wall corner instal- lation Individual module installation with module attachment for wall corner installation With the module attachment for wall corner installation, Mounting the module attachment for wall corner installation TECElux modules can be attached to a solid structural wall at an angle of 45°.
  • Page 17 Installation with module attachment for variable corner installation Module attachment for variable corner installation 9380003 Dimensions of module attachment for variable corner installation Installation of module attachment for variable corner installation The universal module can be directly attached to the structure with the corner attachment.
  • Page 18: Installation In A Floor-To-Ceiling C-Profile Metal Stud Wall

    TECElux – Shell installation Installation in floor-to-ceiling metal stud wall Installation in a floor-to-ceiling C-profile metal with UA-profiles stud wall Installation in a floor-to-ceiling C-profile metal stud wall In double-stud walls, the individual stud rows must be Installation in a floor-to-ceiling UA-profile metal stud wall tightly connected to each other in accordance with If particularly wide or high walls have a higher rigidity, DIN 18183.
  • Page 19: Installation In A Wooden Stud Wall

    Installation in a wooden stud wall Mounting holes must be drilled to attach the module Installation in a wooden stud wall In addition to metal stud walls, the module can also be installed in wooden stud walls in accordance with DIN 4103-1.
  • Page 20: Attaching Individual Modules To The Floor

    TECElux – Shell installation If installed horizontally, the fastening clip is directly Attaching individual modules to the floor screwed onto the module frame. If installed vertically, the Unless screwed tightly to a section tube, the feet of the clip must be screwed into the wall. TECElux modules should be attached to the bare floor using the screws and dowels supplied.
  • Page 21 Transfer the exact dimensions of the bare-wall protection to the plaster board. Cutting out the wall recess To ensure height adjustment of both TECElux 200/400 modules, the module frames should not be drilled through in certain areas. These are indicated by 2 x 3 stickers on the frame.
  • Page 22 TECElux – Shell installation After attaching the panel plates, cover the welts. Plinth height max. 50 mm Covering welts of the plaster board. When tiling the wall, make sure that the wall covering is applied seamlessly right up to the bare-wall protection. Applying the wall covering When tiling the floor, make sure that the plinth height is maximum 50 mm, otherwise the lower glass attachment...
  • Page 23: Power Supply

    Installing TECElux in zone 2 Power supply When installing an electrical connection in zone 2, the Electrical requirements and safety zones in bathrooms connection set for permanent electrical connections DIN VDE 0100-701 (0100 part 701) 2010-08 applies to (9660002) must be used. rooms in which a person washes in a bath and/or shower, and in which baths and/or shower devices are permanently attached.
  • Page 24 TECElux – Shell installation Installing a TECElux module in safety zone 2 (with connection set) Installing a TECElux module outside the safety zone (with surface-mounted sockets) 1-24...
  • Page 25: Power And Water Connection With Teceone

    Power and water connection with TECEone When using a TECEone with a TECElux module, a power supply is only necessary if a “sen-Touch” flush plate is used. warm kalt cold chaud froid caliente frio caldo freddo ciepła zimna теплый холодный Position of socket and corner valve with TECEone For the corner valves, we recommend the position shown at the top as, in this way, accessibility can be provided...
  • Page 26: Fine Installation

    TECElux – Fine installation Fine installation The order of the detailed installation for the TECElux termi- nal is as follows: • lower glass attachment facing • height adjustment, if applicable • upper glass facing with actuation unit Lower glass attachment facing for standard toilet Remove the bare-wall protection.
  • Page 27 Mount the lower glass facing with actuation unit and — if not already carried out at the factory — insert both glass protection caps. Align the glass facing and mount the toilet ceramic. Cut the toilet connection set to a suitable length and insert. Mount the sound insulation strips on the ceramic.
  • Page 28: Lower Glass Attachment Facing For Shower Toilet And Seats

    TECElux – Fine installation Lower glass attachment facing for shower toilet and seats TECE supplies attachment facings for different shower toilets and seats. The first 14 assembly steps are the same for all facings: Remove the bare-wall protection. Adjust the lower glass facing at the top and bottom so that it fits flush against the wall, and tighten or loosen the four threaded rods with a flat-head screwdriver.
  • Page 29 Open the cistern. Sufficiently flush out the connecting pipe. Remove the reinforced hose and replace it with the replacement reinforced hose with the water connection for the shower toilet or shower toilet seats. 1-29...
  • Page 30 TECElux – Fine installation Guide the reinforced hose through the hole provided for the purpose in the glass facing. Cut the insertion opening with a cutter knife, insert the reinforced hose into the cistern and connect. Caution: On the TOTO Neorest and Washlet, use the long rein- forced hose (order number 9660001)! Lower glass attachment facing for TOTO Neorest and Cut the toilet connection set to a suitable length and insert.
  • Page 31 Lower glass attachment facing for TOTO Washlet and Geberit AquaClean 5000, 5000 plus (order number 9650102) After the preparation phase — see assembly steps 1 to 14 at the start of this section — the glass facing can actually be installed: Mount the lower glass attachment facing.
  • Page 32 TECElux – Fine installation Lower glass attachment facing for Duravit SensoWash Starck C (order number 9650103/...107). After the preparation phase — see assembly steps 1 to 14 at the start of this section — the glass facing can actually be installed: Mount the sound insulation strips on the ceramic.
  • Page 33 Mount the sound insulation strips on the ceramic. Guide the power and water connections through the ceramic according to the Duravit or V & B installation instructions. Mount the toilet seat according to Duravit or V & B assem- bly instructions. According to Duravit or V & B assembly instructions: (A) Install the Duravit (Durafix) concealed mounting (B) Mount the Duravit SensoWash C water cut-off valve (C) Sufficiently flush out the reinforced hose...
  • Page 34 TECElux – Fine installation Lower glass attachment facing for Geberit AquaClean Sela (order number 9650104/...108) After the preparation phase — see assembly steps 1 to 14 at the start of this section — the glass facing can actually be installed: Cut the toilet connection set to a suitable length and insert.
  • Page 35: Lower Glass Attachment Facing For Teceone

    Lower glass attachment facing for TECEone When using a TECEone with a TECElux module, a power supply is only necessary if a “sen-Touch” flush plate is used. Screw in both corner valves and screw the enclosed rein- forced hoses onto the corner valves. warm kalt cold...
  • Page 36 TECElux – Fine installation All the other assembly steps are described in detail in the instructions of the respective shower toilet manufacturers. Cut the toilet connection set to a suitable length and insert. Mount the sound insulation strips on the ceramic. Connect the reinforced hoses to the TECEone connection hoses.
  • Page 37 “m-Lift” height adjustment In the case of modules with manual “m-Lift” height adjust- ment, the adjustment is carried out by means of an easily accessible adjusting screw (A). On TECElux modules 200 and 400, it is possible to lower the height 20 mm downwards or raise it 60 mm upwards – compared with the module frame's factory settings.
  • Page 38: Upper Glass Facing With Manual Actuation Unit

    TECElux – Fine installation Upper glass facing with manual actuation unit Screw in the actuating rods – 4 mm in front of the wall surface. Sufficiently flush out the connecting pipe and screw on to the filler valve. Screw in both magnetic holders – 10 mm in front of the wall surface.
  • Page 39: Upper Glass Facing With Electronic Actuation

    Upper glass facing with electronic actuation Attach the glass facing with backup tape (hook the snap hook into the eyelet). Remove the splash guard, sufficiently flush out the con- necting pipe and screw onto the filler valve. Lift up the glass facing and carry out a function test on the flushing system.
  • Page 40 TECElux – Fine installation Insert the splash guard with the electrical actuation motor (included in the upper glass facing's scope of delivery of the ). No conversion of drain valve required. 10 mm Insert the upper flush plate into the supports and lift up. Screw in both magnetic holders –...
  • Page 41 Carry out a function test on the flushing system or program the electronics. Connect the appropriate plug-in contacts: • grey: actuation motor • black: ceramic-Air odour extraction (if there is one) • red: plug-in power pack Plug the plug-in power pack into the socket. 1-41...
  • Page 42: Programming The Sen-Touch Electronics

    TECElux – Fine installation Procedure Programming the sen-Touch electronics This is how to program the sen-Touch electronics: The sen-Touch electronics can be programmed within the first hour after connecting up to the power supply. In • Touch the large or small touch field with your hand. the event of a power failure, the last settings saved are Programming mode starts after 10 seconds with a quick retained.
  • Page 43 All data contained in the Technical Guidelines has been compiled with the utmost care. The correctness of the data presented cannot be guaranteed, however. TECE assumes no liability for damages resulting from the use of this information. Text and images are protected by copyright law.
