BleBox roller gate User Manual page 2

After making sure that the device is connected in accordance with the
diagram, power on the device by connecting the power (turning on the mains
fuse or connecting the power cord to the power outlet).
2
Download the free wBox application. If you have an Android mobile device,
you will find the application in the Play Store. For iOS devices the application
is in the App Store.
By using your mobile phone or tablet, connect it to the device wireless
network. To do this, enter to your smartphone or tablet settings, then go
to setting of the WiFi network and find the network name „rollerGate-
xxxxxxxxxx" where xxxxxxxxxx is the serial number of the device. Connect
to this network.
Open the wBox application. A device will appear at the top of the screen. To
add it to the application, click on "+" on the right side of the name. To pre-
configure the controller, click on the default device name.
You can also set the configuration using the web
browser of your phone / tablet. After connecting to the
wireless network of the controller, turn on the browser
and go website www.blebox.eu
Go to "Settings" (icon in the upper right corner of the screen) to the "Door
security settings" section. Set the appropriate values in the fields "Enable
infrared sensors" and "Enable sensing edge" according to the connected
safety devices. Remember that the absence of safety devices connected to
the controller, such as infrared sensors and a sensing edge or warning signal
device, can cause damage to health and property! Save the configuration by
pressing the "Save" button.
Check the operation of the controller by pressing the up and down button
on the keyboard panel: the controller will illuminate the panel and the roller
door will begin to move. Stop the door by pressing the center button on the
keyboard panel. If the door moves in the opposite direction to the one given,
go to the configuration in the "Door" section and select "Yes" in the option
"Change the movement direction". Remember to save the configuration by
clicking on the "Save" button. Press the buttons on the keyboard panel to
check again if the door moves as expected.
If the controlled door has a motor with mechanical limit switches or with
electronic limit switches, it is recommended to calibrate the controller by
clicking on the "Automatic calibration" button in the "Calibration" section.
After confirming the procedure, the door will automatically rise to the upper
end position, then go down to the lower end position and rise to the upper
end position. Do not take any action during the calibration. To check the
work of the control to a point, go to the control screen, and then move the
horizontal scroll bar to the extreme and intermediate positions, verify that
the door moves to the position set in the animation. You can also set the
partial opening position of the door (called ventilation function). To do this,
go to the configuration of the "Door" section, select the option "Enable
partial opening" and, in the "Partial opening position" field, enter the value
from the range 0-100. By clicking on the "Test" and "Move to" buttons, the
door should move in the desired position. Save the configuration by pressing
the "Save" button. Check the functionality: go to the control screen, move
the door to the closed position and then click on the partially open door
icon (the second icon on the left). The door must be placed in the previously
set position (the door will not move if the current position is higher than the
saved position of the ventilation function).
If the controlled door has an unusual motor that does not pass the automatic
calibration procedure, set the "Time limit in seconds" to define the maximum
time the door needs to move from one end position to the other: this is the
time when the controller gives voltage to the motor. It is not recommended
to desactivate the movement time limit. In the case that the automatic
calibration has been carried out, the suggested value can be left.
Familiarize yourself with the control screen: the clicking on the door icon
located in the center will cause the following action in the diagram: raise,
stop, down, stop. If the door is calibrated, the border around it shows the
current position: the total filling with blue color means the closed position,
the total filling with grey shows the open position. Under the door icon,
will be displayed messages about the current status of the door, including
messages from the security system. Lower is the scroll bar to set the
intermediate position of the door, which is active only when the door has
been calibrated. At the bottom of the screen are the control buttons, from left
to right: close, partial open, stop and open. Under the buttons, is displayed
an additional warning for emergency situations, for example, the detection of
an object through the infrared sensor or the activation of the sensing edge.
3
Once you turn on the controller for the first time, you can proceed to its
further configuration. Being connected to the WiFi network emitted by the
device, in the control panel of the wBox application select the device, then
go to "Settings" (icon at the top-right corner of the screen).
FIRST START
ACCESS POINT AND WIFI
NETWORK SETTINGS
You can change the name of the device that is displayed in the wBox
application. In addition, you can change the name and password of its
generated WiFi network. Remember that changing the network name or
password will disconnect the device immediately after you click the "Save"
button, so re-connect to the device using the newly assigned network name
and password.
You can add the controller to your home WiFi network to control it through
this home network or from anywhere in the World. To do this, in the "Connect"
settings section, select a network name from the list and press "Connect". If
is required, enter the WiFi network password. During the connection of the
controller to your home network, the phone / tablet may disconnected from
the network. In this case, you will need to reconnect your phone / tablet to
the controller network.
Please remember that in order to control the device outside the local WiFi
network, from anyplace in the World by using the wBox application, the
option "Remote access enabled" in the controller settings must be set to
"Yes".
Once you've finished configuring the WiFi network, you can disconnect your
phone/tablet from the controller network and connect your mobile device
directly to your home WiFi network. The control from the wBox application
will work the same way as when the phone / tablet is connected to the
controller network. If the user leaves the local network, for example, leaving
home or using the mobile data, the wBox application will signal this state as
"Remote mode". In this case, the devices can be controlled, but for security
reasons settings are not available.
TECHNICAL SPECIFICATIONS
supply voltage
energy consumption
control outputs
signaling outputs
control inputs
supported switches
security entrances
power supply for safety devices
control keyboard
housing
protection level
dimensions
transmission type
communication standard
mode
230V AC
< 1W
2 x relay, push-pull, NO;
5A/1250VA
1 x realy, NO 5A/1250 VA
4 x logical, shorted to COM,
12 - 24V DC galvanically separated
monostable (push-button),
not-illuminated
1 x barrier logic input infrared NPN-
NC, input PWM rubber optical signal
pressure bar with a frequency of 1 kHz
±50% and 50% duty, 12 - 24 DC,
galvanically separated
15V DC / max. 1.2W
3 - button, capacitive (touch),
illuminated, integrated
in the front panel
surface junction box, controller covered
with a polyurethane composition not
containing halogens, self-extinguishing
for thermal class B (130 °C)
IP44
129 x 89 x 57 mm
bi-directional, encrypted
μWiFi, compatible with WiFi, 802.11g
direct connection (as Access Point),
Wi-Fi connection via a standard router,
connection with access from any loca-
tion in the world (requires only access to
the Internet)
