Terms & Abbreviations
You Should Know
™
Isolated Analog Output Modules
Table 1. Related Allen-Bradley documents
Allen-Bradley Doc. No.
1747-2.30
SGI-1.1
1770-4.1
1747-6.2
1747-NI001
1747-6.4
1747-6.11
1747-6.3
ABT-1747-TSG001
1747-NP002
1747-NM009
SD499
AG-7.1
To obtain a copy of any of the Allen-Bradley documents listed, contact
your local Allen-Bradley office or distributor.
You should understand the following terms and abbreviations before
using this guide. For the definitions of terms not listed here, refer to
Allen-Bradley's Industrial Automation Glossary, Publication AG-7.1
Attenuation – The reduction in magnitude of a signal as it passes
through a system. The opposite of gain.
Channel – Refers to one of the sets of signal interfaces available on a
module's terminal block.
Channel update time – For analog outputs, the time required for the
channel to convert the data received from the processor to analog output
signals at the terminals.
Chassis – See rack.
