Safety, Operation, Maintenance
034606 Engine Module, 2002
Used with
LT15G13
WARNING! Read and understand this
!
manual before using this machine.
G13 Engine
& Parts Manual
Safety is our #1 concern!
April 2010
rev.A-D
rev. E6.07
Form #884

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G13 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wood-mizer G13

Summary of Contents for Wood-mizer G13

  • Page 1 G13 Engine Safety, Operation, Maintenance & Parts Manual 034606 Engine Module, 2002 rev.A-D Used with rev. E6.07 LT15G13 Safety is our #1 concern! April 2010 Form #884 WARNING! Read and understand this manual before using this machine.
  • Page 2 For more information go to www.P65Warnings.ca.gov/wood. Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2022 Wood-Mizer LLC...

  • Page 3: Table Of Contents

    LT15 Rev. D4.00 - D7.00 ..........4-6 Engine Assembly ................... 4-8 LT15 Rev. A1.00 - D3.00...........4-8 Throttle/Clutch Assembly ..............4-10 LT15 G13 Rev. E1.00 - E6.09 .........4-10 ...............4-10 Throttle/Clutch Assembly ..............4-12 LT15 Rev. D4.00 - D7.00 ........4-12 Throttle/Clutch Assembly ..............4-14 LT15 Rev.

  • Page 4: Section 1 About This Manual

    Introduction SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer sawmill. Refer to the sawmill opera- ® tor’s manual and manufacturer's manual before attempting to operate this equipment.

  • Page 5: Section 2 Operation

    Operation Starting The Engine SECTION 2 OPERATION Starting The Engine DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. DANGER! Operate your engine only in well ventilated areas.

  • Page 6: Section 3 Maintenance

    Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless otherwise instructed in this manual. Fol- low the manufacturer’s recommendations for dusty conditions. This manual only provides information about additional procedures or NOTICE procedures to be performed at different time intervals than found in the manu- facturer's manuals.

  • Page 7: Fuel Filter

    Maintenance Fuel Filter Replace the pre-cleaner (element wrapper) every 2000 hours of operation. See the engine manual for further instructions. Fuel Filter Replace the fuel filter every 100 hours of operation or as required for engine performance. RPM Adjustments WARNING! Remove the blade before performing any engine service.

  • Page 8: Section 4 Replacement Parts

    014809 Filter, Kohler Air #47-083-01 014718 Pre-Cleaner, Kohler Air #52-083-01 014719 Filter, Kohler Oil #28-050-01-S 036653 Filter, Kohler Oil #52-050-02 014717 Muffler Kit, G13 Kohler 016498 Muffler, Kohler #12-068-39 016106 Gasket, Kohler Muffler #12-041-03 016494 WM doc 2/25/22 Replacement Parts...
  • Page 9 Shorter Oil Filter 036653 required for LT15G13 Rev. E4.00 and later to avoid interference with up/down assist mechanism. Either filter can be used for previous revisions. No longer available (5/16). No replacement part available from Kohler or Wood-Mizer. Replaces S21486 1/4” x 1” key. S04124 always used in production.

  • Page 10: Engine Assembly

    Engine, 13 HP Kohler #PA22519 014809 Filter, Kohler Air #47-083-01 014718 Pre-Cleaner, Kohler Air #52-083-01 014719 Filter, Kohler Oil #52-050-02 014717 Muffler Kit, G13 Kohler 016498 Muffler, Kohler #12-068-39 016106 Gasket, Kohler Muffler #12-041-03 016494 Deflector, Kohler Flat #12-755-27 016497...
  • Page 11 Bushing, QT x 1 016513 BELT, BX82 DRIVE 016505 WASHER, 3/8” SAE FLAT F05011-3 WASHER, 3/8” SPLIT LOCK F05011-4 BOLT, 3/8-16 X 1” HEX HEAD F05007-7 No longer available (5/16). No replacement part available from Kohler or Wood-Mizer. Replacement Parts WM doc 2/25/22...

  • Page 12: Engine Assembly

    Engine, 13 HP Kohler #PA22519 014809 Filter, Kohler Air #47-083-01 014718 Pre-Cleaner, Kohler Air #52-083-01 014719 Filter, Kohler Oil #52-050-02 014717 Muffler Kit, G13 Kohler 016498 Muffler, Kohler #12-068-39 016106 Gasket, Kohler Muffler #12-041-03 016494 Deflector, Kohler Flat #12-755-27 016497...
  • Page 13 Use muffler kit 016498 for service. Kit includes gasket, deflector and spark arrestor. Muffler 016106 no longer a sellable item (3/00). Spark arrestor 016495 replaces 016146 originally supplied prior to 3/00 (duplicate parts). No longer available (5/16). No replacement part available from Kohler or Wood-Mizer. Replacement Parts WM doc 2/25/22...

  • Page 14: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 G13Rev. E1.00 - E6.09 150098F DESCRIPTION PART # QTY. ( Indicates Parts Available In Assemblies Only) PLATE, THROTTLE CABLE BRACKET LT15G 034616 SCREW, 1/4-20 X 3/4 FT HEX HEAD F05005-1 NUT, 1/4-20 NYLON LOCK F05010-69 SPRING, EXTENSION 3/8 X 3 014818...
  • Page 15 Replacement Parts Throttle/Clutch Assembly BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 034612 PIN, 3/16 X 1 1/4 ROLL F05012-16 LINKAGE ASSEMBLY, W/BEARING 034605 Bushing, 5/8” ID x 7/8” OD x 1 1/8” Long Flanged Bronze 016486 NUT, 1/2-13 FREE HEX, ZINC F05010-35 WASHER, 1/2 SPLIT LOCK F05011-9 NUT, 1/2-13 JAM F05010-31...

  • Page 16: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 Rev. D4.00 - D7.00 11 11 150080B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. PLATE, BRAKE ACTUATOR 016470 BOLT, 5/16-24 X 1” HEX HEAD F05006-11 WASHER, 5/16” SPLIT LOCK F05011-13 NUT, 1/4-20 SWAGED F05010-21...
  • Page 17 Replacement Parts Throttle/Clutch Assembly BOLT, 3/8-16 X 3/4” HEX HEAD GRADE 2 F05007-27 SCREW, 7/16-20 X 1 1/2” SOCKET HEAD CAP F05007-55 WASHER, 7/16” SAE FLAT 15/16” OD F05011-43 BLOCK, MOTOR HANDLE PIVOT 016481 TURNBUCKLE ASSEMBLY, CLUTCH A12304 Nut, 7/16-20 Jam F05010-38 Rod End, 7/16-20 Right Hand Male P11579...

  • Page 18: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15Rev. D3.00 150058-2 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. HANDLE, THROTTLE/CLUTCH 014825 GRIP, 1/2” I.D. X 3” LONG HANDLE 014835 COLLAR, 1/2” I.D. X 7/8” O.D. LOCK 014820 BUSHING, SF1260-6 BRONZE P08060 BRACKET, THROTTLE/CLUTCH HANDLE MOUNT 014821...

  • Page 19: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Ring, 3/4” Inside Retaining F04254-34 Nut, 5/16-24 Hex F05010-28 Rod End, 5/16-24 Male Right-Hand P09814 Instruction Sheet, LT15 Clutch Turnbuckle Installation 016446-956 Instruction Sheet, LT15 Clutch Installation 016514-957 BOLT, 5/16-18 X 1” HEX HEAD GRADE 2 F05006-1 SPACER, 1.016”...
  • Page 20 Replacement Parts Throttle/Clutch Assembly BRACKET, THROTTLE/CLUTCH HANDLE PIVOT 014837 PIN, 3/16” X 5/8” ROLL F05012-22 PLATE, THROTTLE MOUNT 014813 BOLT, 5/16-18 X 1 1/4” HEX HEAD FULL THREAD F05006-18 NUT, 5/16-18 HEX NYLON LOCK F05010-58 WASHER, 3/8” SPLIT LOCK F05011-4 BOLT, 3/8-16 X 3/4”...
